Summary of Contents for AirMed PLUS ADS clinic
- Page 1 Bedienungsanleitung Mode d‘emploi Wechseldrucksystem Système anti-escarre...
-
Page 2: Table Of Contents
Content Content Product description Product images Product images Explanation of the symbols Operation the device Operational location Turning on the device Choice of operating mode Nursey mode Pressure relief position Security key Set the interval time Set the weight of the patient Display of operating hours Turning off the device The alarm... -
Page 3: Product Description
For this purpose the ADS clinic is linked to a special type of matress from AirMedPLUS. The ADS clinic is microprocessor controlled device, equip-... -
Page 4: Product Images
Product images Front view 3. 4. Rear view page 4 of 22 Version 1.4 – June 2015 - ADS_Clinic Operator Manual _V1_4_Mai 2015_Software 1_20_ENG.doc... - Page 5 Top view 20 . Display 23. 24. 23. 27. 25. page 5 of 22 Version 1.4 – June 2015 - ADS_Clinic Operator Manual _V1_4_Mai 2015_Software 1_20_ENG.doc...
- Page 6 Patient’s mattress 36. 37. page 6 of 22 Version 1.4 – June 2015 - ADS_Clinic Operator Manual _V1_4_Mai 2015_Software 1_20_ENG.doc...
-
Page 7: Explanation Of The Symbols
Explanation of the symbols Front view: Button „ON“ Button „OFF“ Buttons for operating mode „Static“ Buttons for operating mode „Alternating pressure“ Icon of the selected operating mode „Alternating mode“ Selected cycle time in operating mode „Alternating mode“ Buttons to acknowledge the alarms Buttons to display the number of operating hours Buttons to activate / deactivate locking Button to set more (+) or less (-) weight of the patient... -
Page 8: Operation The Device
Operation the device Connecting the device to the power supply. The ADS clinic must connect to a power strip of 230 V/50Hz to operate. Other voltages or frequencies are not allowed, it can lead to damage of the device. Connecting an AirMed PLUS mattress to the device For the operating of the ADS clinic, an AirMedPLUS patient’s mattress must be connected. - Page 9 Otherwise, there is danger that the maneuvarability of the bed and even the functionality of bed will be limited. In addition there is a danger of damage to the bed and/or the ADS clinic system. Please note: You have to depend on the bed and mattress, the content of the so called “Bed...
- Page 10 If the electricity supply system has been switched off or has failed and the ADS clinic was temporarily switched off, you have to turn the ADS clinic on again to make sure, that the alarming system of the ADS clinic will work fine.
-
Page 11: Operational Location
Operational location The device's operational location is perpendicular to the foot end of the bed on the ground or for setting up and operating the device briefly hanging on the foot of bed - only and exclusively to operate the device and not during the use. On behalf of security reasons it should be established, that no humidity can run inside the device! These locations are featured as construction vibrations and vibrations of some patients can be experienced as disturbing. -
Page 12: Turning On The Device
Once you see a number in the display, which corresponds to one of the digits “1”, “2”, or “3”, the ADS clinic is ready to be set. Mutiple settings shown in the display, after the device has been turned on, are based on it’s last usage and before the last turning off. - Page 13 Jersey-upholstery. The tracing consists of Polyurethane stretch at the top and a Jersey- layer at the bottom. After the selection of the type of mattress, the ADS clinic starts filling the connected mattress. In doing so, the microprocessor of the ADS getting a pressure control to de- termine, when the correct pressure for the selected patient's weight is reached.
-
Page 14: Choice Of Operating Mode
Static mode The symbol identification in the display of the mode: By pressing button (3) the function “Static mode” of the ADS clinic is selected and the operating will start. In this function, the ADS clinic works like a therapeutically static function. -
Page 15: Pressure Relief Position
Pressure relief position In pressure relief position of particular body parts, in operating mode ‘Static’, cells can be removed individually. To do this, you have to remove the cover of the mattress, pull out the push buttons from the cells to be removed, left and right from the base mattress. Tear the connection hose of the cell, to the hose system in the mattress base loose. -
Page 16: Display Of Operating Hours
The power-off function will take precedence over the security key. The alarm The ADS clinic is equipped with an optical and visible alarm. Early warning is monitored by the microcontroller. The optical alarm in case of device issues, will be shown in the display as a ‚clock‘. -
Page 17: Cleaning / Disinfection
If the electricity supply system has been switched off or has failed and the ADS clinic was temporarily switched off, you have to turn the ADS clinic on again to make sure, that the alarming system of the ADS clinic will work fine. -
Page 18: Filter
Filter The ADS clinic features a dust filter (14) on the back of the device. The dust filter must be changed at least once a month, depending on the environment even several times. For example: at the latest if the filter is brown or green colored. You buy the dust filter as a set of 10 pieces at the Service Center of AirMedPLUS (item number 99-1129). -
Page 19: Certificate Of Conformity
Product name: ADS clinic Meets the requirements of the European directive for medical products 93/42/EWG and 2007/47/EC. The ADS clinic is consistent with risk class 1 based on annex IX rule 1 of the directives 93/42/EWG and 2007/47/EC. Applied standaards:... -
Page 20: Information Manufacturer And Technical Details20
Information manufacturer and technical details page 20 of 22 Version 1.4 – June 2015 - ADS_Clinic Operator Manual _V1_4_Mai 2015_Software 1_20_ENG.doc... - Page 21 Dimensions of the AD-mattress type 1 in operational condition, inflated: 200 cm x 90 cm x 12,5 cm ADS clinic AD-mattress type 1: minimum weight patient : 20 Kg – 11,7 mmHg; Maximum weight patient: 180 Kg – 38,2 mmHg, pressure range 11,7-38,2 mmHG, maximum fill pressure 38,2 mmHg Number of cells:18, length of the cells: ca.
- Page 22 Kuhn und Bieri AG Rehaprodukte und Dienstleistungen für Heime, Spitäler und Spitex Produits réha et services pour homes, hôpitaux et organismes de soins à domicile Sägestrasse 75, CH-3098 Köniz Telefon 0848 10 20 40, Fax 031 970 0171, info @ kuhnbieri.ch kuhnbieri.ch...
