AVANT A21000 Operator's Manual For Attachment

Silage dispenser
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English
Silage dispenser 2016 1
Operator's Manual for Attachment
Silage dispenser
Product number:
A21000
www.avanttecno.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A21000 and is the answer not in the manual?

Questions and answers

Related Manuals for AVANT A21000

Summary of Contents for AVANT A21000

  • Page 1 English Silage dispenser 2016 1 Operator's Manual for Attachment Silage dispenser Product number: A21000 www.avanttecno.com...
  • Page 2 Silage dispenser 2016 1...

  • Page 3: Table Of Contents

    Silage dispenser 2016 1 CONTENTS 1. FOREWORD ............................4 2. DESIGNED PURPOSE OF USE......................5 3. SAFETY INSTRUCTIONS FOR USING THE BUCKET ..............6 4. TECHNICAL SPECIFICATIONS ....................... 10 Safety labels and main components of the attachment ..................10 Safety labels and main components of the attachment ..................10 5.

  • Page 4: Foreword

    If you sell or transfer the equipment, be sure to hand over this manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant dealer or from the manufacturer.

  • Page 5: Designed Purpose Of Use

    5 (26) 2. Designed purpose of use The AVANT Silage Dispenser is an attachment suitable for use with AVANT multi purpose loaders shown in Table 1. The attachment is intended for dispensing precision chopped silage and feeding stuffs made with feed mixers.

  • Page 6: Safety Instructions For Using The Bucket

    6 (26) 3. Safety instructions for using the bucket Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly powerful and improper or careless use or maintenance may cause serious personal injury or property damage.
  • Page 7 7 (26)  Carrying heavy loads can shift the centre of gravity of the loader and lead to tipping over of the loader. Always transport the load as low and close to the machine as possible with the telescopic boom completely retracted to keep the centre of gravity low and for the best stability.
  • Page 8 8 (26) Remember to wear proper protective clothing:  The noise level at the driver's seat may exceed 85 dB(A). Wear hearing protection while working with the loader.  Wear protective gloves.  Wear safety boots whenever working with the loader. ...
  • Page 9 9 (26) Safe stopping of the attachment, before going near the attachment: WARNING: Always stop the attachment following safe stopping procedure before leaving the driver's seat. Safe stopping procedure prevents all unintentional movements of the attachment. Note that the loader boom can move down even if the engine of the loader is turned off.

  • Page 10: Technical Specifications

    30-40 l/min Maximum input of hydraulic energy: 60 l/min, 22,5 MPa (225 bar) Suitable Avant loaders: See Table 1 4.1 Safety labels and main components of the attachment Listed below are the labels and markings, which must be visible on the equipment. Replace the warning labels, if they have become unclear or if they have detached completely.
  • Page 11 A418220 Attachment identification plate Table 4 - Main components of the Silage dispenser Frame with Avant quick attach brackets Multiconnector and holder for multiconnector Discharge conveyor Spring loaded discharge opening (on both sides of the machine)

  • Page 12: Attaching The Attachment

    Do not stay in the area between the attachment and the loader. Mount the attachment only on level surface. Never move or lift an attachment that has not been locked. Avant quick coupling system: Step 1: ...

  • Page 13: Connecting And Disconnecting Hydraulic Hoses

    5.1 Connecting and disconnecting hydraulic hoses On Avant loaders the hydraulic hoses are connected using the multi connector system. If you have an Avant 300-700 series loader with the conventional quick couplers and wish to change to the multi connector system, contact your Avant dealer or service point for instructions or installation services.
  • Page 14 14 (26) Connecting the multi connector system: 1. Align the pins of the attachment connector with corresponding holes of the loader connector. The multi connector will not connect if the attachment connector is upside down. 2. Connect and lock the multi connector by turning the lever towards the loader.

  • Page 15: Storage

    15 (26) 5.2 Storage Uncouple and store the attachment on level ground, but avoid leaving the attachment laying directly on against the ground. Place it on blocks of wood or on a pallet, for example. The best way to store the attachment is a place where it is protected from direct sunlight, rain, and extreme temperatures.

  • Page 16: Using The Bucket

    16 (26) 6. Using the bucket Practise the use of the attachment and its controls in an open and safe area. If you are unfamiliar with the loader in use, it is recommended to practice its use without any attachments. DANGER: Risk of entanglement - Always stop the attachment before leaving the driver’s seat.

  • Page 17: Checks Before Use

    17 (26) 6.1 Checks before use  Ceck that the dispenser bucket is intact and that the feeding conveyor can move freely. Remove any foreign objects that could damage the dispensing system from the bucket.  Drive carefully on uneven terrain and note the effect of heavy load at the front of the loader to the stability and handling of the loader.
  • Page 18 18 (26) WARNING: Risk of tipping over - Avoid overload and keep heavy load close to the machine. Always wear seat belt. Pay attention that a heavy load or long distance between the loader and the centre of gravity of the load will affect the balance and handling of the loader.

  • Page 19: Operating On Inclined Terrain

    19 (26) 6.2.1 Operating on inclined terrain Extra caution is needed when using the equipment on inclined terrains and slopes. Drive slowly especially on inclined, uneven, or slippery surfaces, and avoid sudden changes in speed or direction. Operate the controls of the loader with careful and smooth movements.
  • Page 20 20 (26)  Drive slowly, using moderate to high engine rpm.  Once the tip of the bucket is in the pile, begin to tilt the bucket.  Scoop the bucket full by simultaneous driving forward, tilting, and lifting the bucket. ...

  • Page 21: Maintenance And Service

    Finding any fault means that the hydraulic hose or component must be replaced and the equipment must not be used until it is repaired. Spare parts are available from your nearest AVANT retailer or authorised service point. Leave the repair work to professional service technicians, if you don’t have adequate knowledge and...

  • Page 22: Inspections, Maintenance And Service

    22 (26) 7.2 Inspections, maintenance and service It is recommended to empty the bucket completely right after using it. Do not store the bucket directly against the ground; place it on blocks of wood or on a pallet, for example. Leave the attachment to a position where water will not stay in the attachment.

  • Page 23: Warranty Terms

    23 (26) 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows:  Work costs are covered, if the repair is not performed at the factory.
  • Page 24 Hydraulisk skovl; redskab til Avant Minilæssere A21000 Hydraulic bucket; attachment for Avant loaders Hydraulische Schaufel; Anbaugerät für Avant Radlader Godet à commande hydraulique destinée à être utilisée avec les chargeuses Avant 26.10.2016 Ylöjärvi, Finland Risto Käkelä, Toimitusjohtaja / Verkställande direktör / Administrerende direktør /...
