powerstick POWERTRIP Quick Start Quide

How It Works
Charge it.
Power up your mobile device.
CHARGES YOUR TABLET, MOBILE PHONE AND PORTABLE DEVICES
ON THE GO.
Features
Three different methods of charging: AC wall charging, USB and solar panel
Efficient, highly engineered and micro-controlled universal charging system
Real-time, accurate read-out LCD displays for battery
Lithium polymer power cell with three layers of built-in stability and safety protection
Optional
4, 8, or 16 GB, Hi-Speed USB 2.0/1.1 interface, quick and flexible data storage
Compatible with Windows ME, 2000, XP, Vista, 7, 8, Linux Kernel 2.4 and Mac OSX
Operating Instructions
Charge PowerTrip by flipping down AC wall charging prongs and plugging it into a
supported outlet, using the provided micro-USB cable to connect to a computer, or leaving
the PowerTrip solar panel side-up in direct sunlight
LCD turns on when charging begins
PowerTrip is fully charged when the display shows 8 bars.
Disconnect the charger
Use the appropriate USB cables to plug your device into the PowerTrip to charge
Press the Power Button to start charging your device
USB memory stick is Plug & Play, compatible with any multimedia and data storage
Warranty
Powerstick.com warrants its PowerSeries products against defects for life
if the item has been purchased from an authorized distributor and proof of payment can
be verified. The defective product must be mailed postage paid to:
Powerstick.com, 29 Camelot Drive, Ottawa, Ontario, K2G 5W6, CANADA
Upon receipt, Powerstick.com will either correct any problems with the unit and
restore it to working condition, or replace the unit, at its discretion. This warranty will not
apply to units that have been purchased from non-authorized sources or ones damaged
through improper use.
PowerTrip is a trademark of Powerstick.com Inc. All rights reserved.
powerstick.com
Powerstick.com Inc.
29 Camelot Drive
Tel - 1.877.230.4840
Fax - 1.613.230.2188
POWERTRIP
by powerstick.com
PORTABLE CHARGER
CHARGEUR PORTATIF
CARGADOR PORTATIL
NOTE: In case of problems with your unit, press the power button for 5 seconds to reset
it. If the LCD is not displaying any bars, an overnight charge may be required to restore
power to the LCD display.
Specifications
Battery Type Lithium Polymer
Output Voltage DC 5V max
Output Current 1.0 A max
Operating Temperature 0 to 45 C/32 to 113 F
Storage & Transportation Temperature -10 to 70 C/14 to 158 F
Dimensions 4.1" x 2.4" x 1"
Weight 7 oz.
Cycle Life 1,000+
Charge Input Voltage 4.5 - 5.5V
Charge Input Current 10 - 500 mA
Battery Capacity 6,000 mAH
Memory Capacity 4, 8, or 16 GB (Optional)
†Charging capability and time is based on the power capability of the computer's USB port/hub.
Safety
Do not operate in wet conditions or submerge in water.
Do not charge the PowerTrip above 40 C/100 F or below 0 C/32 F.
Do not charge your tablet, cellphone, or portable device above 40 C/100 F or below
-15 C/5 F. This device complies with Part 15 of FCC rules. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
Ottawa, Ontario
K2G 5W6
CANADA
C C US US
The Triple Powered Charger
POWERTRIP
2011 CES AWARD WINNING SOLAR-POWERED CHARGER WITH FLASH MEMORY
Printed in Canada.
TM
