SUPPLIED MATERIAL
Allen key / Ll a ve allen / Inbusschlüssel
1
2
Template / Plantilla / Schablone
Lamp structure / Estructura luminaria / Leuchten-Struktur
3
TECHNICAL SPECIFICATIONS
Suite
Design by Jordi Vilardell & Meritxell Vidal
ASSEMBLY INSTRUCTIONS
INSTRUCCIONES DE MONTAJE
MONTAGEANLEITUNG
MATERIAL SUMINISTRADO
ESPECIFICACIONES TÉCNICAS
GELIEFERTES MATERIAL
1.
2.
6025
6030
1 un.
1 un.
1 un.
1 un.
1 un.
1 un.
3.
6025.
6030.
TECHNISCHE DATEN
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VIBIA Suite 6025
Summary of Contents for VIBIA Suite 6025
- Page 1 Suite Design by Jordi Vilardell & Meritxell Vidal ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE MONTAJE MONTAGEANLEITUNG SUPPLIED MATERIAL MATERIAL SUMINISTRADO GELIEFERTES MATERIAL 6025. 6030. 6025 6030 1 un. 1 un. Allen key / Ll a ve allen / Inbusschlüssel 1 un. 1 un. Template / Plantilla / Schablone 1 un.
- Page 2 ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE MONTAJE MONTAGEANLEITUNG IMPORTANT NOTICE: Switch of the mains before installing the lamp. 1. Take the template supplied and lay it against the wall, making sure it is parallel to the floor. Next, mark the points indicated for your product reference on the wall.
- Page 3 ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE MONTAJE MONTAGEANLEITUNG 4. Fix the strips (B) using suitable screws and plugs (not supplied). IMPORTANT: Before tightening the screws, use a spirit level to make sure the strips are exactly horizontal. 5. Mount the structure on the strips (B) and tighten the screws (A) with the allen key.
- Page 4 ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE MONTAJE MONTAGEANLEITUNG 6. There is an adjustable foot (C) which is supplied tightened up. If required, this can be screwed up or down so that the structure stands properly on the floor. 7. One of the trays has a USB charging port, supplying 5V / 0.5A.
- Page 5 IMPORTANT : UNPACKING INSTRUCTIONS IMPORTANTE: INSTRUCCIONES PARA DESEMBALAR WICHTIG: AUSPACKEN ANLEITUNG...
- Page 7 Suite Design by Jordi Vilardell & Meritxell Vidal UNPACKING...
