TERK Technologies BMS-34 Connections & Warranty

• Supplies signal for up to
4 satellite connections
• Compatible with dual
output LNB systems
• Die-cast aluminum
construction and weather-
proof F-connectors
• Easy to install
Note: DC block should
not be used with
powered antennas
Ant./CATV
grounding
Sat. Ant./ Sat.
13V CATV 18V
screw
loc. loc. loc. loc.
1 2 3 4
To Additional Receivers
Combi.
Ant./
Sat.
CATV
DC-
Block
ANT IN
TO TV
TO TV
Satellite Receiver
Specs::
HDTV Ready
Insertion loss:
Ant: 10dB typical
Sat: 2dB typical
Frequency range: 54-2150MHz
Isolation: 25 to 35dB typical
Limited Warranty
BMS-34
TERK Technologies Corp. (TERK)
warrants this product against defects in
materials or workmanship for one (1)
year from the date of purchase. During
this warranty period, this product will be
replaced without charge. This warranty
does not cover any damage due to acts
of nature, commercial use, accident,
misuse, abuse or negligence. This
warranty is only valid in the USA.
Replacement as provided under this
warranty is the exclusive remedy of the
consumer. TERK shall not be liable for
any incidental or consequential damages
for breach of any express or implied
warranty on this product, except to the
extent that limitations of this sort are
prohibited by applicable law. THERE ARE
NO IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURCHASE EXCEPT TO THE
BDS-P1
EXTENT THAT IMPLIED WARRANTIES OF
Additional diplexer
EITHER SORT ARE REQUIRED BY
(not included)
APPLICABLE LAW, AND IN SUCH CASE,
needed at each
EACH WARRANTY IS LIMITED IN
receiver location
to separate signals
DURATION TO ONE YEAR.
back out.
TERK and TERK Technologies
are trademarks of
TERK Technologies Corp. Commack, NY
©2003 TERK Technologies Corp.
TiVo is a registered trademark of TiVo Inc.
Made in China
For additional information: Call
1.800.942.TERK (8375) or Visit
www.terk.com
SAT IN
10P016
