INSTRUCTION MANUAL FOR
Modular Remote Control Car Alarm
with Engine Immobilisation

TO ARM/DISARM ALARM

The alarm is activated by pressing the button on the remote control transmitter once. The blinkers
will flash once, and the siren will beep once. The dash LED-light will stay on for 20 seconds then flash,
THE ALARM IS NOW ON.
To deactivate the alarm, press the button again. The blinkers will flash twice and the siren will beep
twice. THE ALARM IS NOW OFF.
If the siren is sounding, and you wish to disarm, the first press will cancel the siren - the system will
then return to an armed state. A second press is required to fully turn the alarm off. The blinkers will flash twice and
the siren will beep twice. THE ALARM IS NOW OFF.
Note: If power is removed from the alarm system, i.e. when replacing your car battery, the alarm will automatically
enter armed mode when power is restored.

ALARM TRIGGER

When triggered, the siren will sound for 30 seconds and then will automatically rearm. If the alarm has been triggered
in your absence, the dash LED will be flashing twice as fast as normal when you return to your vehicle.

EMERGENCY PANIC BUTTON

The panic feature is activated by pressing & holding the button on the remote control transmitter for 3 seconds. The
system will arm or disarm first depending on what state it was in. The siren will then sound & the blinkers will flash for
30 seconds. To cancel "panic", follow disarm procedure as desribed above.
NOTE: Panic does not work when the ignition is on by requirement of Australian Law (EPA-Environmental Protection
Authority).

PROGRAMMABLE FEATURES:

AUTOMATIC RE-ARM : This feature prevents accidental disarming by the owner ie. the owner turns the alarm off but
is then distracted and forgets that they have deactivated the system. If a door is not opened, or the ignition is not
turned on within 30 seconds from when the system is turned off by the remote, the system will re-arm, and if central
locking is connected, it will re-lock the vehicle.
SILENT OPERATION : This feature when turned on, stops the siren from beeping for arm & disarm confirmation, and
from sounding on alarm trigger i.e. only the blinkers will flash.
LEARNING REMOTES
Before entering this mode,make sure you have all remotes present that you wish yo utilise with this alarm system, as
the alarm automatically erases all remotes when you enter this mode.
A.
While the system is disarmed, open and close your drivers door & sit in the vehicle.
B.
Now, turn the car ignition key from the off position to the ignition on position 5 times within 15 seconds.
C.
5 seconds later, the siren will sound briefly to confirm that you have entered the remote learning mode. Repeat
steps A & B if you do not hear the confirmation.
D.
Now press the button on the first remote you wish to learn in. The siren will sound briefly to confirm this code has
been learnt. Now press your second remote. The siren will sound briefly again to confirm this code has also been
learnt. Repeat this step for up to six remotes.
E.
The system exits learning mode once it has received 6 remote codes - press one of your learnt remotes
repeatedly to fill up all coding locations if you do not have 6 remotes. The system will exit to disarmed mode.
A.C.N 001 621 610
(Up to 6 remotes can be used with this alarm system)
SYDNEY / AUSTRALIA
Build Date:
1
