Narrow Band Wireless Receiver with 2 x Code Hopping Remote
N517
Product Description & Features
Remote Control Function
Master Default Setting
Programming Remote Controls
Programming Wireless Detectors
Wireless Detector Supervision
Wireless Detector Low Battery & Tamper Warning
Memory Recall Function
KISS-RX
Your
is a state- of- the-art narrow band wireless receiver, designed to operate with most alarm
control panels.
Main Features include:
♦ Simple Installation.
♦ Code Hopping Remote Control Technology (remotes can not be copied by scanning or code grabbing).
♦ Remote Functions include Arm/Disarm & Panic.
♦ Ability to quickly add or erase detectors from your system.
♦ 4 Wireless Detector Zones Available.
♦ Wireless Detector Supervision Output.
♦ Low Battery Warning Output (Intelligent 1 trigger only until batteries replaced)
♦ Detector Tamper Warning Output
♦ Intelligent Detector Learning Program to prevent accidental code duplication.
♦ Memory Recall Function to identify individual detectors sending low battery or tamper codes.
Controls
C:\WINDOWS\Desktop\kisspenta.doc
Description
Proudly Made in Australia
Build Date:
Page
1
2
4
5
6
7
8
8
1
Advertisement
Related Manuals for RHINO KISS-RX-BEEP
Summary of Contents for RHINO KISS-RX-BEEP
- Page 1 Proudly Made in Australia Narrow Band Wireless Receiver with 2 x Code Hopping Remote Controls Build Date: N517 C:\WINDOWS\Desktop\kisspenta.doc Description Page Product Description & Features Remote Control Function Master Default Setting Programming Remote Controls Programming Wireless Detectors Wireless Detector Supervision Wireless Detector Low Battery &...
- Page 2 ♦ Wireless Detectors available include PIR's, Internal or External Reed Switches, Smoke Sensors & Wireless Emergency Pendants. ARM/DISARM: Press the button once. As soon as you release, the alarm will respond. PANIC: Activate by pressing & holding down the button for 3 seconds.
- Page 3 All outputs are open – collector. This means the outputs will be open circuit normally and will output ground/earth for 1 second when triggered.
- Page 4 Typically, this unit should be wired up in the following configuration on a Penta system. The Penta PGM output must be programmed as an ARMED output Address 10 Data 01 (for Penta software version 4A123) Exit delay should be programmed to 0 seconds Address 08 Data 00 (for Penta software version 4A123) The Tamper zone must be programmed as an ARM/DISARM zone...
-
Page 5: In This Manual
All LED's on the receiver will flash once together to confirm that the receiver has been defaulted. Return all dip switches back to the OFF position. IF YOU ENCOUNTER ANY PROBLEMS WITH YOUR KISS OR REQUIRE ADDITIONAL TECHNICAL INFORMATION NOT CONTAINED IN THIS MANUAL PLEASE CONTACT YOUR RHINO DEALER... - Page 6 TO ADD A REMOTE CONTROL 1. On Bank 1, set dipswitch Number 8 only to ON. The yellow Program LED will come on. (If the LED flashes, check that, you don't have more than one dipswitch set to on). NOTE WHEN PROGRAMMING REMOTES OR WIRELESS DETECTORS Bank 1...
-
Page 7: Important Note
4. Return dip switch 8 to the OFF position. The yellow Program light will turn off. IMPORTANT NOTE: When installing any wireless device, make sure that it is at least 5 METRES AWAY from the receiver. - Page 8 Wireless PIR, Wireless Reed Switch, Wireless Smoke Sensor, or Wireless Emergency Button) TO ADD A DETECTOR 1. On Bank 1, select the Zone (1-4) that you wish to program a detector into. The yellow Program LED will come on. (If E.g.
- Page 9 Valid LED no longer illuminates on your receiver when the detector transmits, and also by watching that the Zone LED no longer illuminates on your RHINO Keypad. 4. Return all dip switches back to the OFF position. The yellow program light will turn off.
- Page 10 All of your individual wireless detectors (i.e. Wireless PIR, Wireless Reed, or Wireless Smoke Detectors) can send a supervision report to your receiver to confirm that they are fully functional. If supervision mode is enabled, the receiver will be expecting to receive the individual supervision code from each detector approximately every 2.4 hours i.e.
- Page 11 4. Supervision Reporting has now been de-activated for all zones. 5. Return all dip switches back to the OFF position. The yellow program LED will turn off & the green run LED will begin to flash at 0.5Hz. KISS - RX Your detectors will automatically transmit a low battery report to your receiver when the batteries are nearly flat.
- Page 12 c) For Tamper press the User Code button. User Code 3. The zones that are sending the respective signal to your receiver will be illuminated on your alarm panel keypad for only 20 seconds. The memory is then automatically erased, so make sure you make careful note of the zones, as you will not get a second chance!
