118
M u c h m o r e t h a n j u s t a H i - F i r a c k .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 118 Genium Line and is the answer not in the manual?

Questions and answers

Related Manuals for FalkenOhr 118 Genium Line

Summary of Contents for FalkenOhr 118 Genium Line

  • Page 1 M u c h m o r e t h a n j u s t a H i - F i r a c k .
  • Page 2 Table of contents Overview 118 – Klangmöbel – and Klangbasen Standard and optional equipment KLANGMÖBEL GENIUM LINE und PURE LINE Genium Line Pure Line Basic models with prices Genium Line Pure Line Standard equipment Technology Equipment Sound-core and Functional-body Cladding Accessories Optional equipment Equipment Sound-core and Functional-body...

  • Page 3: Table Of Contents

    Shelves Cladding Dimensions Genium Line Pure Line KLANGBASEN BASE LINE Base Line Basic models with prices Base Line Standard equipment Technology Equipment Sound-Core and Stability-Core Cladding Accessories Optional equipment Cladding Packaging Surface finishing Shelves Cladding Dimensions Base Line Warranty Explanations...

  • Page 4: Shelves

    Overview 118 Standard and Extras WIDTH Single width ○ ○ ○ Double width ○ ○ Triple width ○ ○ DESIGN HEIGHT 118 mm ○ 700 mm ○ ○ 850 mm ○ ○ 1000 mm ○ ○ TECHNOLOGIE Compound shelves ○ ○...

  • Page 5: Genium Line

    Genium Line Designed for consummate listening enjoyment in a residential setting. The Genium Line has it all, high-quality sound, a sophisticated design – and features never before seen in audio furniture. The world of FalkenOhr for true audiophiles...
  • Page 6 1 ○ Shelf 2 ○ Stands incl. spikes and spike shoes 3 ○ Cladding 4 ● Drawer 5 ○ Installation area 6 ○ Top side cable inlet with cover and brushes 7 ○ Hinged and pluggable rear panel 8 ○ Strain relief Genium Line Equipped with a cable installation area, claddings, a rear panel, and an optional drawer.

  • Page 7: Pure Line

    Pure Line Made for purists. The focus is on sound and design. Reduced to their essence.
  • Page 8 1 ○ Shelf 2 ○ Stands incl. spikes and spike shoes 3 ○ Cladding 4 ● Drawer Pure Line Equipped with cladding and an optional drawer. ● = available as optional equipment ○ = standard equipment - = not available Explanations of the footnotes –...
  • Page 9 Shelf-width Shelves Weight List price in mm width in mm in mm in pcs in kg Euro excl. VAT 118 Genium Line 6.371,00 € single width 67,0 6.676,00 € single width 74,0 6.929,00 € 1000 single width 81,0 7.357,00 €...

  • Page 10: Standard Equipment

    The new, innovative connections of the FalkenOhr shelves to the stands are either damping or conductive. This enables the micro-vibrations generated by the audio devices in one shelf to be dissipated without disturbing the other levels.
  • Page 11 Genium Line and Pure Line ○ ○ Clear structure FalkenOhr sound furniture has a clear structural separation into three main structural components. These are independently mounted and decoupled from each other. SOUND CORE The heart of your sound furniture. Designed for an extremely clear, powerful, and spatial sound image.
  • Page 12 Standard equipment 118 Genium Line and Pure Line SOUND-CORE ○ ○ Stands incl. spikes Made of highly homogenous, cast aluminum EN AW-5083 in 4 pcs. natural E6 / C0 anodized. Raw aluminum is rather soft and therefore absorbs resonances well and can distribute and transmit them very evenly due to its ordered microstructure.
  • Page 13 Standard equipment 118 Genium Line and Pure Line ○ Cable-Installation-Area Separate, easily accessible room for your cable installation. Designed for orderly arrangement and mounting of the signal and electrical cables. Suitable for cable diameters up to 20 mm and plug diameters up to 42 mm. Completely decoupled from the sound core.

  • Page 14: Cladding

    Standard equipment 118 Genium Line and Pure Line ○ Rear-Panel The back wall can be hinged or simply removed completely. Therefore, you have complete access to the installation of your electronics. Mounted, the back wall is the perfect cover and shield for your wiring.
  • Page 15 Optional equipment 118 Genium Line and Pure Line EQUIPMENT SOUND-CORE 696,00 € ● ● Additional shelf Composite shelves with innovative integrated Single width 980,00 € 1 pc. connection technology. Double width 1.265,00 € Triple width 718,00 € ● ● Decoupled Base For each desired position a 12 mm thick aluminum plate (EN AW- 1 pc.

  • Page 16: Cladding

    Optional equipment 118 Genium Line and Pure Line CLADDING 432,00 € ● ● Design element incl. Plugged design element for covering the spikes and the spike- decoupling shoes. Made of aluminum (EN AW-5083, natural E0 / C6 anodized). • Decoupled from the sound core without design element PACKAGING 260,00 €...

  • Page 17: Shelves

    Surface finishing 118 Genium Line and Pure Line SHELVES Lacquered finishes □ matt G30, slightly structured 0,00 € 0,00 € 0,00 € ○ ○ Black □ semi-gloss G70 22,00 € 33,00 € 44,00 € ● ● □ high gloss G100 Black ●...

  • Page 18: Cladding

    Surface finishing 118 Genium Line and Pure Line CLADDING Lacquered finishes □ matt G30 - soft touch 0,00 € ○ ○ Black □ semi-gloss G70 130,00 € ● ● □ high gloss G100 Black □ high gloss G100, polished 1.070,00 € ●...
  • Page 19 Dimensions 118 Single width Double width Triple width 118 Genium Line Design height 700 mm Usable height 566 mm. The shelves can be adjusted in height in a grid of 25 mm. Shelf-thickness 34 mm. Max. 4 shelf levels. Design height 850 mm Usable height 716 mm.
  • Page 20 Single width Double width Triple width Design height 1000 mm Usable height 866 mm. The shelves can be adjusted in height in a grid of 25 mm. Shelf-thickness 34 mm. Max. 5 shelf levels. 118 Pure Line Design height 700 mm Usable height 566 mm.
  • Page 21 Single width Double width Triple width Design height 850 mm Usable height 716 mm. The shelves can be adjusted in height in a grid of 25 mm. Shelf-thickness 34 mm. Max. 5 shelf levels. Design height 1000 mm Usable height 866 mm. The shelves can be adjusted in height in a grid of 25 mm.

  • Page 22: Base Line

    Base Line The base for your power amps and/or speakers. Created as an ideal complement to Pure Line and Genium Line. ○ Shelf ○ Stands incl. spikes and spike shoes ○ Cladding ○ Stability core with damping concrete ○ 3D/IO Technology ●...
  • Page 23 Basic models 118 Base Line Height Width Usable width Depth Usable depth Weight List price in mm in mm in mm in mm in mm in kg Euro excl. VAT 118 Base Line 2.910,00 € 35,0 3.066,00 € 44,0 3.365,00 € 54,0 3.664,00 €...
  • Page 24 The new, innovative connections of the FalkenOhr shelves to the stands are all conductive for the bases. This enables the micro- vibrations generated in the shelf by the audio component to be dissipated quickly and specifically.
  • Page 25 Standard equipment 118 Base Line ○ Sound adjustment - Adjustment of the sound image to your acoustic preferences and analytic/warm conditions by adjustable damping of the spike shoes. Stone floors, certain audio components, or living room conditions can create a too hard, rigid, or even over-analytical sound.
  • Page 26 Standard equipment 118 Base Line STABILITY-CORE ○ Stainless steel tub with Stainless steel tub filled with highly damping concrete. damping concrete Weight approx. 25 kg. Serves for a highly efficient reduction of external 1 pc. vibrations. CLADDING ○ Cladding incl. Made of damping MDF.
  • Page 27 Optional equipment 118 Base Line CLADDING 432,00 € ● Design element incl. Plugged design element for covering the spikes and Base Line 528 ● 520,00 € decoupling the spike-shoes. Made of aluminum (EN AW-5083, Base Line 800 natural E0 / C6 anodized). •...
  • Page 28 Surface finishing 118 Base Line SHELVES Lacquered finishes □ matt G30, with a light-structure 0,00 € ○● Black □ semi-gloss G70 22,00 € □ high gloss G100 Black □ high gloss G100, polished 630,00 € ● □ matt G30, with a light-structure 0,00 €...
  • Page 29 Surface finishing 118 Base Line CLADDING Lacquered finishes □ matt G30 - soft touch 0,00 € ○ Black □ semi-gloss G70 44,00 € ● □ high gloss G100 Black □ high gloss G100, polished 499,00 € ● □ matt G30 – soft touch 0,00 €...
  • Page 30 Dimensions 118 400 width 560 width 118 Base Line Depth 528 mm Depth 800 mm...

  • Page 31: Warranty

    FalkenOhr is in no way responsible for consequential or indirect damage or liability resulting from the use of the product discussed here or from a violation of this warranty or any implicit warranty in relation to the said product.

  • Page 32: Explanations

    Explanations Klangmöbel is a term used by FalkenOhr for HiFi racks Klangbase is a term used by FalkenOhr for Amp-Stands The information single wide, double wide and triple wide refer to electronics in 19 '' design. I.e. for devices narrower than 482.6 mm, one, two, or three can be positioned side by side.
