HOLZKERN Sundown Manual

Movement ​ | Uhrwerk
Solar ​ | Solar
Epson VR43
Case thickness ​ | Gehäusehöhe
12 mm
Circumference ​ | Umfang
Adjustable length ​ | Größenverstellbar
Weigh ​ t ​ | Gewicht
143 g
Glass ​ | Glas
Hardened mineral crystal ​ | Mineralglas
Backplate ​ | Rückseite Gehäuse
Metal ​ | Metall
Water resistance | Wassersäule
Splash-proof ​ | Spritzwasserfest
Band width ​ | Armbandbreite
22 mm
Band ​ | Armband
Wood ​ | Holz
Clasp pi ​ n | Spangenstift
Accuracy/Month
Genauigkeit/Monat
Solar watch
Before commissioning your solar-powered
watch, it must be exposed to five hours of
sunlight. Especially during the sunless months,
it should be powered under a lamp (distance
20cm) for 60 hours (glow-lamp 30W/LED
6W/375 Lumen) to fully charge the power
reserve.
Be careful not to expose the watch to excessive
heat (bright midday sun) to prevent damage.
Battery indicator and duration:
Press the button B for more than a second to
see the battery level ​ :
*The second hand starts moving at two-second
intervals if the stored energy is on an extremely low
level. In that case, recharge the watch as already
described.
± 20 sec.
± 20 Sek.
Sundown
1​ ​ Hour ​ | Stunde
2 ​ ​ M inute ​ | Minute
3​ ​ S econd ​ | Sekunde
4​ ​ S topwatch minutes ​ | Stoppuhr Minuten
5​ ​ 2 4-hour hand ​ | 24-Stundenzeiger
6​ ​ S topwatch seconds ​ | Stoppuhr Sekunden
7​ Battery indicator | Akkuanzeige
8​ ​ D ate ​ | Datum
9​ ​ N ormal position ​ | Normalposition
10​ ​ 1 st click ​ | 1. Position
11​ ​ 2 nd click ​ | 2 Position
A​ ​ B utton A ​ | Taste A | ​ s top ​ | Start
B​ ​ B utton B ​ | Taste B |​ reset ​ | Rücksetzung
high: ​ ​ p osition: 45 sec.
= 90 days or more
middle: ​ position: 40 sec.
= 30-90 days
low: ​ position: 35 sec.
= 30 days or less
EN: ​ w ww.holzkern.com/en/faq/#siz ​ e
DE: ​ ​ w ww.holzkern.com/de/faq/#siz​ e
Running time
Laufzeit
45 mm
Instructions Band
Anleitung Armband
max. 4 Month ​ |
fully ​ ​ c harged
max. 4 Monate |
voller Akku
