HPW 100 EASY
OPERATION
The operator must use the unit in accordance with
f
the regulations. He/she must take local conditions
into account and be aware of other people, espe-
cially children, when operating the unit.
The unit may only be used by authorized persons
f
who have received training or have demonstrated
their ability to operate the unit. The unit must not
be operated by children or juveniles (danger of ac-
cidents due to incorrect use of the unit).
Never allow children, persons with physical, senso-
f
ry or mental limitations or a lack of experience and/
or knowledge and/or people unfamiliar with these
instructions to use the machine. Local regulations
may restrict the age of the operator.
Children should be supervised to ensure that they
f
do not play with the machine.
The unit must never be left unsupervised while the
f
unit is switched on.
The water jet from the high-pressure nozzle pro-
f
duces a recoil on the gun. You should therefore
hold the gun and spray lance firmly with both
hands.
Never use a roto nozzle or pencil jet to clean motor
f
vehicles.
ELECTRICAL SAFETY
WARNING! Switch off, remove plug from
mains before adjusting, cleaning or if cable
is cut, damaged or entangled. Your machine
is double insulated for safety and requires no earth
connection. The operating voltage is 230 V AC, 50 Hz
(for non-EU countries 220 V, 240 V as applicable). For
increased electrical safety use a Residual Current De-
vice (RCD) with a tripping current of not more than
30 mA. Always check your RCD every time you use
it. The supply cables must be inspected for signs of
damage at regular intervals and may only be used if
in perfect condition. If the replacement of the supply
cord is necessary, this has to be done by an autho-
rized service agent in order to avoid a safety hazard.
Only use approved extension cables.
WARNING! Inadequate extension cables
can be dangerous. Extension cable, plug
and socket must be of watertight construc-
tion and intended for outdoor use.
Extension cords, cables, leads, reels should only be
used if they comply with EN 61242/IEC 61242 or IEC
60884-2-7. If you want to use an extension cable
when operating your product, only the following
cable dimensions should be used:
Nominal Conductor Area of 1,5mm
length of 20m for a Cord Extension Set.
The connections (plugs and sockets) should be
kept dry and off the ground. It is recommended
that this is accomplished by means of a cord reel
which keeps the socket at least 60 mm above the
ground.
Note: If an extension cable is used it must be earthed
and connected through the plug to the earth cable
of your supply network in accordance with pre-
scribed safety regulations. Refer to the instruction
manual of the extension cord, lead, reel manufactur-
er and your local wiring regulations.
MAINTENANCE
Switch off the unit prior to all cleaning and mainte-
f
nance work and before replacing components. Pull
out the mains plug if the unit is mains-operated.
Repairs may only be carried out by authorized
f
FFFGROUP Service Centers.
ACCESSORIES AND SPARE PARTS
Accessories and spare parts which have been ap-
f
proved by FF GROUP must be used. Original accesso-
ries and spare parts guarantee that the unit can be
operated safety and without any breakdowns.
INTENDED USE
The product is intended for cleaning areas and objects
outside the house, tools, vehicles and boats, if the ap-
propriate accessories and cleaning agents approved
by FF GROUP are used. Intended use is related to oper-
ation within 0°C and 40°C ambient temperature. This
product should not be used for professional use.
TECHNICAL DATA
Article number
Model
Rated voltage
Rated power input
Protection Class
Degree of protection
Pump Material
Max Pressure
Rated Pressure
Rated Flow
Auto Stop System
Weight
Sound emission values determined according to
EN 60335-1, EN 60335-2, EN 62233
Typically the A-weighted noise levels of the product are:
Sound pressure level
Sound power level
Uncertainty K
Vibration total values a
and uncertainty K determined according to EN
60335-1, EN 60335-2, EN 62233
to a max. cable
2
Vibration level max:
a
h
K
IDENTIFICATION
1. Handle
2. Power cord hook
3. Switch ON/OFF
4. Power cord
5. Water outlet
6. Wheel
7. High-pressure hose hook
8. High-pressure hose
English |
43413
HPW 100 EASY
V 220-240
Hz 50
W 1400
IPX5
Aluminum
bar 100
bar 70
l/h 330
kg 5,8
dB(A) 88
dB(A) 92
dB
(triax vector sum)
h
m/s 1,8
2
m/s 0,05
2
www.ffgroup-tools.com
