- Page 1 Ultimate Aquarium DC - Pump Professional DC Pump 3000 , 5500 , 8000 ,10000 , 15000 , 20000 User Manual...
- Page 2 Thank you for purchasing the ZOOX Ultimate Aquarium DC Pump. This product can be used as a circulation pump in both freshwater and seawater environments. This manual supports DC3000, DC5500, DC8000, DC10000 ,DC15000, DC20000L. Please read this instruction manual carefully and understand the usage and structure before use.
-
Page 3: Safety Guide
SAFETY GUIDE HANDLING OF POWER PLUG, POWER CORD & SOCKET WARNING Unplug the power adapter when When pulling out the power putting your hands in the aquarium adapter from the outlet, hold or performing maintenance the power adapter first, then It may cause electic shock. - Page 4 3000 4000 5000 6000 Flow Flow DC8000 1000 2000 3000 4000 5000 6000 7000 8000 9000 Flow ※The total head is the length of the pipe (hose) and varies depending on the pipe friction and the resistance when connecting equipment.
- Page 5 ●Content Remove the main unit and all attached parts from the box and check that if there any damage during transportation.In particular, make sure that the cord is not damaged. If any damage is found, do not use it and contact your dealer. Drain Hose Connector Adapter...
- Page 6 2. Connect the joint between the pump and controller referring to the following connection method. How to Connect Tighten the connection cover Align the protrusions and insert 3. Connect the adapter to the controller. 4. Connect the power cord to the adapter. ※Before connecting, make sure that the power is not connected to the outlet.
- Page 7 Precautions for Piping Excessive drainage resistance results in reduced flow, abnormal pump noise and malfunction Please observe the following precautions. ● Do not use a right-angle elbow pipe at the end of the water intake pipe or the dra If necessary, use a pipe with a smooth angle. 45°...
- Page 8 ●How to use the controller ※Each button is a touch panel type, so do not push it strongly, as it will be the cause of the failure. ※The number (RPM) displayed in the center indicates the rotation speed of the impeller.Increasing the flow rate by increases the RPM (rotational speed), as well as decreasing it.In addition, when resistance is applied to the drainage, the RPM (rotational speed) increases to maintain the set flow rate.
- Page 9 ●Maintenance For safety use, please do the maintenance (cleaning) to remove dirt and calcium components regularly (at least once a month). Also, remove dust and dirt from the power cord connection and the outlet. ※Be sure to disconnect the power plug from the outlet and make sure that the power is not turned on before doing the maintenance.
- Page 10 4. Use a soft-bristle toothbrush to remove any dirt from each part. ※If lime algae or calcium components are stuck, remove them using a special cleaner or Hydrochloric Acid. 5. Check the impeller if there any damage. 6. Check the O-ring if there any damage. ※Even small scratches can cause water leaks and malfunctions, so if you find them, replace them immediately.
- Page 11 ●Error Code Solution Error Code Cause Solution Check that the water level at the pump location is not low. Er01 Run idle Add water if necessary. Check that if it is connected to the genuine dedicated adapter. If used with heaters, coolers, lighting fixtures, and octopus wiring, the voltage may be constant.
- Page 12 ZOOX AQUARIUM LTD. Email: info@zooxaquarium.com Web:http://www.zooxaquarium.com 180402...
