- Page 1 HD5212 Installation and Operation Manual MUTE MONO DISP IPOD FILE/FOLDER HD5212 READY PRESS TUNE/CH CAT/DIR AUX IN ENTER BAND READY Watts Peak Watts en Crête Vatios el Máximo 13W x 4...
-
Page 3: Table Of Contents
HD5212 TABLE OF CONTENTS Introduction ...1 Preparation ...2 Wiring ...3 Installation ...4 Front Panel Release ...7 Operation ...8 Tuner Operation ...11 Satellite Radio Operation ...13 CD Player Operation ...15 MP3/WMA Operation ...17 iPod Operation ...21 Remote Control ...23 Care and Maintenance ...24 Troubleshooting ...25... - Page 4 HD5212...
-
Page 5: Introduction
HD5212 Introduction Congratulations on your purchase of the Jensen HD5212 Mobile Receiver. It’s a good idea to read all of the instructions before beginning the installation. We recommend having your Jensen HD5212 installed by a reputable installation shop. Features •... -
Page 6: Preparation
The transport screws are clearly marked. Remove before installation. NOTE: If the HD5212 is to be installed in a car equipped with an on- board drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. -
Page 7: Wiring
HD5212 Wiring SIRIUS XM L XM R TERK XMDJEN100 cables sold separately. TERK XMD1000 Direct Tuner and antenna sold separately. SiriusConnect SC-C1 Satellite JLink iPod Cable (Included) iPod iPod Mini iPod Gen5 Antenna Connector Power Antenna (BLUE) Connect to power antenna tuner sold separately. -
Page 8: Installation
8. Carefully slide the radio into the mounting sleeve making sure it is right- side-up until it is fully seated and the spring clips lock it into place. HD5212 Hex Nut Spring Washer... - Page 9 Fuses When replacing a fuse, make sure the new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The HD5212 uses one 15 amp fuse located below the wiring connector (15 amp fast blow ATO).
- Page 10 HD5212 Removing the Radio To remove the radio after installation, remove the trim ring by pulling outward on one side and then the other. Insert the removal keys straight back, with the notches facing up, until they lock. With the removal keys engaged, pull the radio straight out.
-
Page 11: Front Panel Release
HD5212 Front Panel Release (open) button (9) releases the mechanism that holds the front panel to the chassis. Detaching the Front Panel To detach the front panel: 1. Press and hold the power button (1) to turn the unit off. -
Page 12: Operation
Press the rotary encoder repeatedly to step through the following audio: VOLUME, BASS, TREBLE, BALANCE, and FADER. The unit automatically exits audio control mode after five seconds of inactivity. MUTE MONO IPOD HD5212 PRESS TUNE/CH AUX IN ENTER BAND BASS To adjust the bass level from “-10”... -
Page 13: Menu Operation
HD5212 Menu Operation Press and hold the rotary encoder (4) to access the system menu. Repeatedly press the rotary encoder button to access menu options in the following order: • BEEP ON/OFF: The beep tone feature allows the selection of an audible beep tone to be heard each time a button is pressed on the face of the radio. -
Page 14: Reset Button
• function buttons do not operate • error symbol on the display Use a ball point pen or thin metal object to press the RESET button. This may be necessary should the unit display an error code. HD5212... -
Page 15: Tuner Operation
With multicasting, you can receive up to three additional multicast channels: HD2, HD3, HD4. With your HD5212 radio, you will receive HD Radio digital broadcasts automatically when tuned to a station that offers HD Radio technology. -
Page 16: Preset Scan
The information will scroll across the screen if longer than 8 characters. NOTE: The amount of information displayed when receiving an HD Radio signal is dependent upon what is being broadcast. Some stations broadcast their call letters (name), the artist's name, song title, and category of music. HD5212... -
Page 17: Satellite Radio Operation
HD5212 Satellite Radio Operation Listeners can subscribe to XM® Radio on the Web by visiting www.xmradio.com, or by calling (800) 967-2346. Customers should have their Radio ID ready (see “Displaying the Identification (ID) Code”). Customers can receive a limited number of free-to-air channels without activation. - Page 18 3. Press the BAND/ENTER button (3) to confirm. 4. Once a category is selected, use the TUNE/CH >> or TUNE/CH << buttons to select stations in the current category. To exit category mode, press SELECT. HD5212...
-
Page 19: Cd Player Operation
HD5212 CD Player Operation CDP mode can only be accessed when a disc is inserted. If a disc is already in place, press the SRC button (2) to access CDP mode and begin playback automatically. Insert CD Press the open button (9) - Page 20 1-800-323-4815 for further assistance. Electronic Shock Protection (ESP) This unit is equipped with electronic shock protection as follows: • 20 seconds for CDDA (CDA) • 120 seconds for MP3 recorded at 44.1kHz, 128kbps • 200 seconds for WMA recorded at 44.1kHz, 128kbps HD5212...
-
Page 21: Mp3/Wma Operation
HD5212 MP3/WMA Operation MP3 and WMA (Windows Media Audio) music files are digital audio files that are compressed to allow more files on a single CD. This unit can play MP3/WMA directly from files contained on a CD-R/RW, SD card or USB device using the buttons on the receiver (or optional remote control) as described below. - Page 22 Microsoft are supported. WARNING: Do not remove the device when USB PLAY mode is active. Press SRC (2) to change to another mode before removing the device. MUTE MONO IPOD HD5212 PRESS TUNE/CH AUX IN ENTER BAND...
-
Page 23: Track Select
HD5212 Pause Press the 1/>/|| button (13) to suspend disc play. Press the play/pause button again to resume play. Track Select Press the TUNE/CH >> (10) or TUNE/CH << (11) button for less than one second to advance to the next track on the disc, or press and hold to fast forward or fast reverse through the disc. -
Page 24: Display Information
Select (‘ ‘ ) to return to the previous file level and select a different • directory or file. Display Information Press the DISP button (7) to display the clock or available ID3 information, as follows: song title, directory name, artist name, etc. HD5212... -
Page 25: Ipod Operation
SRC button (2) on the front panel or remote control until “IPO” appears on the display. NOTE: The HD5212 will not select video files regardless of whether or not a video file was the last file playing when the iPod was plugged into the radio. -
Page 26: Category Search Mode
4. Turn the rotary encoder (4) to browse songs or folders in the current category. 5. Press the BAND/ENTER button (3) within 5 seconds to select a category/song. 6. Repeat steps 4 and 5 until the desired song is played. HD5212... -
Page 27: Remote Control
HD5212 Remote Control The remote control will allow you to control the basic functions of the HD5212. The remote control sensor is at the top left below the SELECT button (5). Table 2: Remote Control Functions Tuner CD Player Power On/Off... -
Page 28: Care And Maintenance
3. Discs should be kept in their storage cases when not in use. 4. Do not expose discs to direct sunlight, high temperatures or high humidity for long periods. 5. Do not stick paper, tape or CD labels on disc surfaces, as internal damage may occur. or NERO burning HD5212... -
Page 29: Troubleshooting
HD5212 Troubleshooting Problem Cause Does not operate No power to yellow wire; Check connection with test light; (display does not no power to red wire check vehicle fuse with test light light) Fuse blown Replace fuse Front panel not installed... -
Page 30: Specifications
DIN chassis dimensions ..... 7" X 7" X 2" (178mm x 178mm x 50mm) Specifications subject to change without notice. HD5212... -
Page 31: Limited Warranty
Who is covered? The Company extends this warranty to the original retail purchaser of products purchased through an authorized Audiovox retailer in the U.S.A., Puerto Rico or Canada. This warranty is not transferable or assignable. Proof of purchase is required in the form of an original sales receipt. - Page 32 Audiovox Electronics Corporation Hauppauge, NY 11788 Technical Assistance: 1-800-323-4815 www.jensen.com © 2007 Audiovox Ver. 091807 Printed in China...
