OTHER PARTS
15 Temperature probe and level sensor
16 Water return from the pump
17 Pipe waste
18 Fuse carrier
19 Power supply
20 Drainage valve
21 Safety thermostat
22 Thermostat bulb
23 Heating element
23 22 16 17
15
18
19
20
21
J
