Leadtek GPS LR9553D Manual

Bluetooth data logger & receiver
Hide thumbs Also See for GPS LR9553D:
Table of Contents

Advertisement

Quick Links

Download this manual
Leadtek GPS LR9553D Bluetooth Data logger & Receiver
Leadtek GPS LR9553D
Bluetooth Data Logger & Receiver
Product ID: Leadtek GPS LR9553D
Leadtek GPS LR9553D Bluetooth Data logger & Receiver
Version A
August 2007
Headquarters of Leadtek Research Inc.
18F, 166 Chien-Yi Rd., Chung Ho City, Taipei County 23511, Taiwan
TEL: +886(0)2 8226 5800
FAX: +886(0)2 8226 3087
http://www.leadtek.com
E-mail:
service_gps@leadtek.com
©2007 Leadtek Research Inc. All rights reserved.
©2007 Leadtek Research Inc. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPS LR9553D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Leadtek GPS LR9553D

Summary of Contents for Leadtek GPS LR9553D

  • Page 1 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Leadtek GPS LR9553D Bluetooth Data Logger & Receiver Product ID: Leadtek GPS LR9553D Leadtek GPS LR9553D Bluetooth Data logger & Receiver Version A August 2007 Headquarters of Leadtek Research Inc. 18F, 166 Chien-Yi Rd., Chung Ho City, Taipei County 23511, Taiwan...

  • Page 2: Table Of Contents

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver TABLE OF CONTENTS Introduction......................3 Features........................4 Hardware ......................5 Package Contents....................6 Install Leadtek Navigator ...................7 Test Leadtek GPS LR9553D................15 How to change cycle time ................29 Install the USB Driver ..................31 Appendix A: Limited Warranty.................34 10.

  • Page 3: Introduction

    *The application software, locr, enclosed in the Leadtek GPS LR9553D CD-ROM is a very complete and easy-to-use tool for you to integrate your photos and the GPS data. Please register on line now! If you want to open your GPS file via Google earth or Google map directly, please make use of the converter program in the CD and refer to the instruction.

  • Page 4: Features

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 2. Features 20-channel all-in-view tracking Cold/Warm/Hot Start: 42/35/1 sec. respectively Reacquisition time: 0.1 sec. Built-in rechargeable and power-saving battery Operation time: 10~12 hours, in continuous mode Built-in high WAAS for accurate navigation...

  • Page 5: Hardware

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 3. Hardware 1.USB connector (Charging & GPS data downloading) 2.LED indicator LED 1 (GPS)-Green Always on Quick blinking Slowly blinking State Memory full to stop 3D fixed GPS signal acquisition Description LED 2...

  • Page 6: Package Contents

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 4. Package Contents Leadtek GPS LR9553D Bluetooth data logger and receiver x 1 Leadtek Navigator & Locr PC client CD ROM x 1 Warranty Card x 1 Quick Guide x 1 Neck eyelet strap x 1...

  • Page 7: Install Leadtek Navigator

    5. Install Leadtek Navigator Install in PC Step 1 Before installing Leadtek Navigator, make sure that you have installed Microsoft ActiveSync to your PC. Insert the software CD-ROM into the CD-ROM drive. The following screen should appear automatically. If not, run “install.exe”.
  • Page 8 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 2 The installation dialog box and the copyright statement appear. Click “Next”. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 9 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 3 The dialog box of Destination Location appears, showing the default destination folder. To change it, click Browse to select a different folder for installation. If you do not wish to change the destination folder, click "Next".
  • Page 10 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 5 Installation is in progress. Step 6 Once the installation is complete, check your PC screen to see if additional steps are required to complete the installation. Click "Finish". ©2007 Leadtek Research Inc. All rights reserved.
  • Page 11 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Install in PDA Step 1 Before installing Leadtek Navigator CE, make sure that you have installed Microsoft ActiveSync to your PDA. Insert the software CD-ROM into the CD-ROM drive. The following screen should appear automatically. If not, run “install.exe”.
  • Page 12 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 2 The installation dialog box appears. Click "Next". Step 3 The dialog box of Destination Location appears, showing the default destination folder. To change it, click Browse to select a different folder for installation. If you do not wish to change the destination folder, click "Next".
  • Page 13 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 4 You are now ready to install the software. Click "Next” to begin the installation. Step 5 Installation is in progress. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 14 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 6 Once the installation is complete, check your PDA screen to see if additional steps are required to complete the installation. Click "OK". ©2007 Leadtek Research Inc. All rights reserved.

  • Page 15: Test Leadtek Gps Lr9553D

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 6. Test Leadtek GPS LR9553D How to connect via Bluetooth (PDA) The device model is ACER N300, and the BT GPS model is Leadtek 9553. Each PDA has its different menu, so this just an example. Step 1 Click “ADD NEW DEVICE”...
  • Page 16 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 3 Leadtek 9553 has shown on the screen, click it and NEXT, see below. Step 4 The service field shows ZV-SPP, click it and NEXT, see below. PS. Security Connect is not necessary, if enabling it; you need the passkey “0000” to connect 9553.
  • Page 17 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 5 Successfully add 9553, see below. Step 6 Click the 9553 logo and choose connect, and see below. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 18 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 7 You can see the status in active connection, and see below. Step 8 Now, turn to START SETTING- SYSTEM, click GPS setting, and see below. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 19 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 9 GPS setting HAREWARE, choose a com port (example is COM6), Baud rate is 57600 (Only for 9553 Series), see below. Step 10 The map program’s com port and baud rate must be the same as Step 9, see below.
  • Page 20 Leadtek GPS LR9553D Bluetooth Data logger & Receiver How to connect via Bluetooth (PC) System ： Windows XP Pro sp2 GPS： Leadtek Bluetooth GPS Receiver Step 1 Select Bluetooth Device of “Control Panel” ©2007 Leadtek Research Inc. All rights reserved.
  • Page 21 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 2 Select “Add” in Device sheet. Step 3 Tick “My device is ready t be detected” ©2007 Leadtek Research Inc. All rights reserved.
  • Page 22 PC will find your Bluetooth GPS device-> Select-> click Next Step 5 PIN CODE ： Choose the 3 one “ I will choose pin code by myself and key in “0000” (All pin codes of Leadtek’s Bluetooth GPS device are 0000) ©2007 Leadtek Research Inc. All rights reserved.
  • Page 23 Start to test 9553D and data logging (PC) Step 1 Before testing Leadtek GPS 9553D, make sure that you have charged for 3 hours till the red light is off and installed "Leadtek Navigator” to your computer. Turn on LR9553D, and once connected, follow the instruction as below for testing.
  • Page 24 Leadtek GPS LR9553D Bluetooth Data logger & Receiver *Output comport will auto-distribute by your laptop when you added a bluetooth GPS as your device. After OK, there are many data flows appear in the Development Data View. If not, it means there is something wrong.
  • Page 25 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Reset to default. After connecting, click the HW Reset and choose the Factory, then click OK. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 26 Start to test 9553D and data logging (PDA) Step 1 Before testing Leadtek GPS 9553D, make sure that you have charged for 3 hours till the red light is off and installed "Leadtek Navigator” to your computer. Turn on LR9553D, and once connected, follow the instruction as below for testing.
  • Page 27 Leadtek GPS LR9553D Bluetooth Data logger & Receiver 3. After click “OK” in step 2, now it is in connecting. See below. COLD START choose Reset GPS from the Command, see below. ： 5. Choose Cold Start and click OK, see below.
  • Page 28 Leadtek GPS LR9553D Bluetooth Data logger & Receiver 6. If Cold Start doesn’t work, try to set to default, choose factory and click OK, see below. Step 2 Turn on the power switch, you can choose the mode of navigation and log both or the mode of log only for more operation time.

  • Page 29: How To Change Cycle Time

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 7. How to change cycle time Step 1 Open the program of “Cycle Time Setting”, this program will automatically detect if LR9553D and your computer are connected. If not, the status will show “No 9553D Device”, see Figure 1; If yes, the status will show “9553D Device is Ready, see Figure 2.
  • Page 30 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 2 When 9553D and the computer are precisely connected; now you can choose your preference for the recording interval. The intervals include 5 sec, 10 sec, 15 sec, and 60 sec. After you have selected your preference, press “Set Time”...

  • Page 31: Install The Usb Driver

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 8. Install the USB Driver <Note> Install the USB driver before connecting the USB cable. Step 1 Insert the CD-ROM into the CD-ROM drive. Click “USB Driver” to proceed. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 32 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 2 The screen will display the following options. Click to select the option you desire. Click Next to continue. Step 3 Click “Finish” to finish the installation. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 33 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 4 Reboot the computer and then connect the USB cable. You will see the file as below. You can install locr to synchronize your photos and this GPS file. ©2007 Leadtek Research Inc. All rights reserved.

  • Page 34: Appendix A: Limited Warranty

    Leadtek. Transportation charges to Leadtek are not covered by this Limited Warranty. To be eligible for warranty service, a defective product must be sent to and received by Leadtek within fifteen (15) months of the date of sale, together with proof of purchase. Leadtek does not warrant that this product will meet your requirements;...

  • Page 35: Appendix B: Specifications

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 10. Appendix B: Specifications Technical Performance Feature Item Description GSW3 SiRFStarIII LP technology Chipset Frequency L1, 1575.42 MHz General C/A code 1.023 MHz chip rate Channels Position 10 meters, 2-D RMS Accuracy 5 meters 2-D RMS, WAAS corrected <5meters, 2-D RMS, DGPS corrected...
  • Page 36 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Interface Specifications Items Description Mini-USB connector Power Recharge & GPS data download Bluetooth 2.4GHz ISM Band Frequency Bluetooth Specification v 1.2 Compliant Series Port Profile (SPP) Compliant Profile 10 M Bluetooth Operation Range Electrical 5±5%(10%)V DC input...
  • Page 37 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Environmental Characteristics Items Description -10 deg. C to +50deg. C Operating temperature range -20 deg. C to +65 deg. C Storage temperature range Physical Characteristics Items Description 60.2 mm (2.37 in) Length 33.0 mm (1.30 in)

  • Page 38: Appendix C: Safety Information

    GPS is operated by the US government, which is solely responsible for the system’s accuracy and maintenance. Although Leadtek GPS LR9553D is a high precision electronic NAVAID, it may still become unsafe under the circumstances of misuse or inaccurate reading. Hence there is a certain degree of risks involving the use of these products.

  • Page 39: Appendix D: Gps Faq

    After using Navigator for positioning, why can’t I find the GPS antenna on the electronic map? Navigator is an application developed by Leadtek to test GPS navigation. After launching Navigator, if you press x or go to the map without disconnecting the program, it will occupy the GPS antenna’s COM port.
  • Page 40 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Especially because it usually takes longer to navigate when you use GPS for the first time, make sure that you are in an outdoor place with good signal reception. When do I need to run Cold Start? We suggest that you run Cold Start in the following situations: (1) it has been two weeks since your previous navigation;...
  • Page 41 Leadtek GPS LR9553D Bluetooth Data logger & Receiver How many data can GPS 9553D record? It can record up to 60,000 points and 240 hours in maximum. It depends on real circumstances. After I switch on, how long does it take to start working? Within 44-55 seconds.
  • Page 42 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Useful maps/ display mode will differ from place to place. Can I collocate it with my photos in mobile phones? We don’t guarantee it. The mobile phone should built-in the time information of when the photos are taken.
  • Page 43 Leadtek GPS LR9553D Bluetooth Data logger & Receiver What operation system will locr GPS Photo be compatible with? Windows XP and Vista。 How accurate is GPS? It depends on the conditions of the signals received. Under the best conditions, the accuracy can be within 2 meters.
  • Page 44 Leadtek GPS LR9553D Bluetooth Data logger & Receiver How can I test that Locr Symbian s60 is connected with my GPS device? You can just enter http://www.mobiletopsoft.com/symbian/freeware/tag/gps for elated download links. Do you have more information about locr? Please go to http://www.locr.com/help.php.

  • Page 45: Appendix E: Regulatory Notices

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 13. Appendix E: Regulatory notices This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
