Leadtek LR9553D Instruction Manual

Gps bluetooth data logger & receiver
Hide thumbs Also See for LR9553D:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Manual
Leadtek GPS LR9553D Bluetooth Data logger & Receiver
Leadtek GPS LR9553D
Bluetooth Data Logger & Receiver
Product ID: Leadtek GPS LR9553D
Leadtek GPS LR9553D Bluetooth Data logger & Receiver
Version A
June 2007
Headquarters of Leadtek Research Inc.
18F, 166 Chien-Yi Rd., Chung Ho City, Taipei County 23511, Taiwan
TEL: +886(0)2 8226 5800
FAX: +886(0)2 8226 3087
http://www.leadtek.com
E-mail:
service_gps@leadtek.com
©2007 Leadtek Research Inc. All rights reserved.
©2007 Leadtek Research Inc. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LR9553D and is the answer not in the manual?

Questions and answers

Related Manuals for Leadtek LR9553D

Summary of Contents for Leadtek LR9553D

  • Page 1 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Leadtek GPS LR9553D Bluetooth Data Logger & Receiver Product ID: Leadtek GPS LR9553D Leadtek GPS LR9553D Bluetooth Data logger & Receiver Version A June 2007 Headquarters of Leadtek Research Inc. 18F, 166 Chien-Yi Rd., Chung Ho City, Taipei County 23511, Taiwan...

  • Page 2: Table Of Contents

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver TABLE OF CONTENTS Introduction......................3 Features........................4 Hardware ......................5 Package Contents....................6 Install Leadtek Navigator (PC) ................7 Test Leadtek GPS LR9553D................11 Install the USB Driver ..................16 Appendix A: Limited Warranty.................19 Appendix B: Specifications ................20 10. Appendix C: Safety Information ..............23 11.

  • Page 3: Introduction

    GPS position, date and time- up to 240 hrs in the continuous mode. It is not necessary to export the data until the memory is full. LR9553D also comes equipped with mini USB interface both for easy charging and for users to be able to export their recorded points to Google earth and Google Maps without a hitch.

  • Page 4: Features

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 2. Features 20-channel all-in-view tracking Cold/Warm/Hot Start: 42/35/1 sec. respectively Reacquisition time: 0.1 sec. Built-in rechargeable and power-saving battery Operation time: 10~12 hours, in continuous mode Built-in high WAAS for accurate navigation...

  • Page 5: Hardware

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 3. Hardware 1.USB connector (Charging & GPS data downloading) 2.LED indicator LED 1 (GPS)-Green State Always on Quick blinking Slowly blinking Description Memory full to stop 3D fixed GPS signal acquisition LED 2...

  • Page 6: Package Contents

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 4. Package Contents Leadtek GPS LR9553D Bluetooth data logger and receiver x 1 Leadtek Navigator & Locr PC client CD ROM x 1 Warranty Card x 1 Quick Guide x 1 Neck eyelet strap x 1...

  • Page 7: Install Leadtek Navigator (Pc)

    5. Install Leadtek Navigator (PC) Step 1 Before installing Leadtek Navigator, make sure that you have installed Microsoft ActiveSync to your PC. Insert the software CD-ROM into the CD-ROM drive. The following screen should appear automatically. If not, run “install.exe”.
  • Page 8 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 2 The installation dialog box and the copyright statement appear. Click “Next”. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 9 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 3 The dialog box of Destination Location appears, showing the default destination folder. To change it, click Browse to select a different folder for installation. If you do not wish to change the destination folder, click "Next".
  • Page 10 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 5 Installation is in progress. Step 6 Once the installation is complete, check your PC screen to see if additional steps are required to complete the installation. Click "Finish". ©2007 Leadtek Research Inc. All rights reserved.

  • Page 11: Test Leadtek Gps Lr9553D

    6. Test Leadtek GPS LR9553D Step 1 Before testing Leadtek GPS 9553D, make sure that you have charged for 3 hours till the red light is off and installed "Leadtek Navigator” to your computer. Turn on LR9553D, and use the USB cable to connect your computer and LR9553D.
  • Page 12 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Close/Exit Close WinFast Navigator. Help Software manual. Minimize Minimize WinFast Navigator. Close/Exit Close WinFast Navigator. (2) GPS information and signals When the device and the computer are correctly connected, the received GPS data will be shown on the window of “Development Data View”.
  • Page 13 Leadtek GPS LR9553D Bluetooth Data logger & Receiver This number represents for the code of the satellite, and the color display can be referred to part a. 3. Connection information This part explains the status of the speed and direction while navigating and the connection between the device and the computer.
  • Page 14 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Data transmission display When there is data flow, it will blink. COM Port Used It shows the number of the Com Port Used. Baud Rate It shows the transmission rate. 4. Positioning information The longitude at that the user is.
  • Page 15 Leadtek GPS LR9553D Bluetooth Data logger & Receiver continue. If the red light is quickly blinking while logging, which means the power is low, you should immediately charge for the continuous data logging. ©2007 Leadtek Research Inc. All rights reserved.

  • Page 16: Install The Usb Driver

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 7. Install the USB Driver <Note> Install the USB driver before connecting the USB cable. Step 1 Insert the CD-ROM into the CD-ROM drive. Click “USB Driver” to proceed. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 17 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 2 The screen will display the following options. Click to select the option you desire. Click Next to continue. Step 3 Click “Finish” to finish the installation. ©2007 Leadtek Research Inc. All rights reserved.
  • Page 18 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Step 4 Reboot the computer and then connect the USB cable. ©2007 Leadtek Research Inc. All rights reserved.

  • Page 19: Appendix A: Limited Warranty

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver 8. Appendix A: Limited Warranty Leadtek warrants to the original purchaser of this product that it shall be free of defects resulting from workmanship or components for a period of one (1) year from the date of sale (The region of Europe is exceptional, see the warranty card enclosed for the validity).

  • Page 20: Appendix B: Specifications

    Leadtek GPS LR9553D Bluetooth Data logger & Receiver Appendix B: Specifications Technical Performance Feature Item Description Chipset GSW3 SiRFStarIII LP technology General Frequency L1, 1575.42 MHz C/A code 1.023 MHz chip rate Channels Accuracy Position 10 meters, 2-D RMS 5 meters 2-D RMS, WAAS corrected <5meters, 2-D RMS, DGPS corrected...
  • Page 21 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Interface Specifications Items Description Mini-USB connector Power Recharge & GPS data download Bluetooth Frequency 2.4GHz ISM Band Compliant Bluetooth Specification v 1.2 Compliant Profile Series Port Profile (SPP) Bluetooth Operation Range 10 M...
  • Page 22 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Environmental Characteristics Items Description Operating temperature range -10 deg. C to +50deg. C Storage temperature range -20 deg. C to +65 deg. C Physical Characteristics Items Description 60.2 mm (2.37 in) Length Width 33.0 mm (1.30 in)

  • Page 23: Appendix C: Safety Information

    Hence there is a certain degree of risks involving the use of these products. In order to reduce the risks, please read carefully all the documentation regarding technical specifications before using Leadtek GPS LR9553D. When in use, compare carefully the GPS results with all navigation information available, including that from other NAVAID, naked eye view, routes, etc.

  • Page 24: Appendix D: Gps Faq

    After using Navigator for positioning, why can’t I find the GPS antenna on the electronic map? Navigator is an application developed by Leadtek to test GPS navigation. After launching Navigator, if you press x or go to the map without disconnecting the program, it will occupy the GPS antenna’s COM port.
  • Page 25 Leadtek GPS LR9553D Bluetooth Data logger & Receiver Why can’t I use GPS at home or near the window? GPS is for outdoor navigation only, so your device cannot receive GPS signals at home. Especially because it usually takes longer to navigate when you use GPS for the first time, make sure that you are in an outdoor place with good signal reception.
  • Page 26 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
