- Page 1 DRX INSTALLATION MANUAL WASSP DRX INSTALLATION MANUAL V 7 .1 wassp.com Doc: DRX Installation Page 1 of 102 Version: 7.1 January 2021...
- Page 2 Fire, electrical shock, or equipment damage may occur if the transceiver comes into DOCUMENT REVISION HISTORY contact with liquid. » The DRX is rated for operation at 9-32 V DC or 18-32 V DC model dependent. REVISION DATE REASON FOR CHANGE VERSION »...
-
Page 3: Table Of Contents
5.2.7. PPS Tab 3.1. Installation Parts 5.2.8. Geoids Tab 3.2. Transducer 5.2.8.1. Configuring Height Relative to the DRX Geoid File 3.3. Locating the DRX System 5.2.8.2. Configuring Height Relative to the Internal GPS Geoid 3.4. Mounting the DRX 5.3. Commissioning Step 3: On Water Patch Tests 3.5. - Page 4 DRX Setup, PPS Tab APPENDIX E - SEA LEVEL HEIGHT USING GPS HEIGHT Figure 25. PPS Status Appendix E.1 Sea Level Height using DRX Geoid File Figure 26. GPS Time Delay Stage 1 Appendix E.2 Sea Level Height using Internal GPS Geoid Figure 27.
-
Page 5: Introduction
1 INTRODUCTION YOUR NOTES The WASSP DRX is a ‘Black Box’ smart transceiver that interfaces to devices and sensors to make up the WASSP Multibeam Sounder System. The system can be configured to operate in various modes, typically using a wide-angle sonar transducer to profile the water column and seafloor in high resolution. -
Page 6: Main Features
DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL 2 SYSTEM OVERVIEW 1.1. MAIN FEATURES The main features of DRX in a multibeam configuration will depend on the model as The WASSP multibeam sounder system requires the following components: follows: DRX; Transmit, receive, digital signal processing, display processing, License management »... -
Page 7: Complete System
NOTE: Check “Appendix B - Supported Sensors and Sentences” on page 87 for which sensors and sentences are support for input of position, heading, attitude and sound velocity. Satellite NOTE: Images show DRX-32 throughout the manual. See “8 Outline Drawings” Compass GPS / Heading on page 66 for DRX-32 and DRX-46. -
Page 8: Installation Procedures
(Section “3.3. Locating the DRX System” on page 15) 3.2. TRANSDUCER - Run cables to DRX location The DRX supports multiple transducer types and can be setup to operate in a variety of configurations. Typical setup will be multibeam wideband mode with: »... -
Page 9: Mounting The Drx
See ”Figure 4. DRX Bulkhead Mount” on page 17. Figures 4 and 5 show clearance required for cabling and forced air ventilation if DRX is in » The second option is horizontal on a hard, flat surface. -
Page 10: Connecting The Drx
RS422-B RS232 Serial RS-232 The DRX should use a clean power supply. For best performance use a DC battery supply or as a secondary alternative it is recommended to use a low noise converter. POWER CAUTION: A noisy power supply will have direct impact on system 0183 performance. -
Page 11: Connectors And Components - Back Plate
A local supplied latching switch can be connected to pins eight (Remote PWR On) and Transducer Tx nine (Remote PWR On GND) of connector AUX. When the switched is closed the DRX will power on. When the switch is open (circuit open) then the DRX will power off. -
Page 12: Display And Control Devices
DRX’ Help utility. The Ethernet link is used for all communication between the client application running on PC (or other devices) and the DRX. This link is used for control of the DRX and for the ‘FIND MY DRX’ utility can be run on any PC connected to the DRX over the Ethernet DRX to supply data for visualisation and post processing to the client device. -
Page 13: Drx Setup Webpages
DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL 3.7. ELECTRICAL ENVIRONMENT CHECK It is important to validate the electrical environment in dock after installing the DRX, connecting all the sensors and transducer. Steps to validate electrical environment: 1. Turn all electrical equipment and engines on 2. -
Page 14: Operating The Drx
To turn ON the DRX, short press the power key. » To turn OFF the DRX, press and hold the power key for more than 4 seconds. All LEDs will turn off, indicating that power has been turned off. 4.1. POWER The DRX can be powered on/off using the power button or the remote power switch. -
Page 15: System Update & Diagnostics
DRX logs in the display window. » CHECK UPGRADE STATUS can be used to confirm with an upgrade has been 3. During the update procedure the DRX system will reboot. Once completed, check the completed successfully. new software version in the System tab. »... -
Page 16: Network Configuration
Network configuration allows setting the DRX to a fixed IP address. By default DRX will be assigned an IP through Zero-configuration or by a DHCP server if there is one on the LAN. By setting a fixed IP this will override automatic assignment. - Page 17 DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL Licenses can be in one of 3 states: NOTE: IMS is not available on all DRXs. Check with WASSP Support with your ACTIVE; License is installed and active. DRX Serial Number for more information.
-
Page 18: Sensor Configuration
These measurements must be as accurate as possible and should be measured to cm level accuracy. The accuracy of these measurements have a direct impact on the WASSP Multibeam performance. Position to measure from on the transducer, GPS antenna and... -
Page 19: Commissioning Step 2: Sensor Configuration
NOTE: Sensor Offsets still need to be manually setup. NOTE: Only upload presets that were downloaded from the DRX. NOTE: Available Presets will consist of defaults loaded into the DRX and any custom presets applied by the user. 5.2.2. Port Setup Tab... -
Page 20: Sensor Tab
Figure 18. DRX Setup, Port Setup Table The following options need to be set up for each of the DRX ports being used: » Enabled; Marks a port as active or not active. -
Page 21: Corrections Tab
COMMIT button to save any changes. Other data types that can be setup include: 3. The indicator beside the check box shows the status of the DRX. If the indicator is » WATER TEMPERATURE; Used to calculate sound velocity which is required for green the correction is enabled in the DRX. -
Page 22: Key Pulse Tab
COMMIT button to save any changes. The indicator beside the check box shows the status of the DRX. If the indicator is green the correction is inverted in the DRX. If the indicator is red the correction is not inverted in the DRX. -
Page 23: Configuring Key Pulse Master
5.2.6.2. Configuring Key Pulse Master using the BLANK MASTER mode the DRX will transmit a key pulse signal based off the time of the DRX ENABLE selections. transmit pulse. Equipment connected to DRX as slaves will transmit relative to this key pulse. -
Page 24: Pps Tab
Tx/Rx cycle. » IDLE KP MUTE: If KEY PULSE OUTPUT is enabled and DRX is not pinging, on timeout key pulse will be output at 250Hz allowing slaved devices to continue running. IDLE KP MUTE selection will disable this... -
Page 25: Geoids Tab
5.2.8. Geoids Tab and select LOAD. This will To use GPS height for calculating sea level in the DRX the GPS should be configured to become the supply an accurate height fix using Differential or RTK. GGA field 6, GPS Quality Indicator current Geoid needs to be at 2 or above. -
Page 26: Configuring Height Relative To The Internal Gps Geoid
To perform this test, find a distinct feature such as a big rock, sharp slope or cable. The internal GPS Geoid can be used if a DRX Geoid file is not available for your area. 1. Run over the distinct object at SOG (e.g. 5kts). -
Page 27: Roll Offset
Sound Speed settings to get things in the correct ballpark. Configure the mapping width to be at the maximum 120° for best results. The WASSP Patch Test Utility, shipped with CDX, can be used to automatically calculate and apply Roll Offset. Alternatively, Roll Offset can be manually calculated. -
Page 28: Pitch Offset
DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL 5.3.3. Pitch Offset 5. Measure the entire width of the swath at the point you have measured the displacement. This value is (73.229m in this case). If GPS time delay can be completed using variable speed, See ‘Test 2 For use with DGPS’... -
Page 29: Patch Test Validation
6.2. ACQUISITION SOFTWARE CONNECTION SETUP Instead of connecting the user interface / Acquisition software to the DRX, connect the user interface to DataManager RPM through the IP addresses listed. 127.0.0.1:55555 is the most common connection if the User Interface is running on the same PC as DataManager. -
Page 30: Rpm Setup Examples
DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL 6.2.1. RPM Setup examples 6.2.4. Qinsy (QPS) 6.2.1.1. CDX 6.2.2. NavAQ (BeamworX) 6.2.5. Hypack 6.2.3. Naviscan (Eiva) wassp.com wassp.com Page 58 of 102 Doc: DRX Installation Doc: DRX Installation Page 59 of 102 Version: 7.1 January 2021... -
Page 31: Control And Display Application Support
WASSP Ltd. 7.1. CONNECTING THE WASSP CDX TO THE DRX WASSP CDX ships free with DRX and can be installed directly from the USB Flash Drive. 1. After installing WASSP CDX on your PC, start the DRX and run WASSP CDX. -
Page 32: Connecting Maxsea Timezero Plot To The Drx
DRX as the primary source. Connection’. 4. Enter in the IP address of the DRX and the TCP port (default is 55555). NOTE: If you don’t know the IP address of the DRX, use the ‘Find My DRX’... -
Page 33: Connecting Hypack To The Drx
HYSWEEP TOOLS menu. NOTE: All GPS and sensor data should be connected to the DRX. DRX supplies all required data to HYPACK over the ethernet link. NOTE: Refer to Knowledge Base for guidelines on system configuration with HYPACK. -
Page 34: Outline Drawings
DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL 8 OUTLINE DRAWINGS 8.1. DRX-32 OUTLINE DRAWINGS 20.50 Figure 32. DRX-32 Dimensions Figure 33. DRX-32 Front Plate Dimensions wassp.com wassp.com Page 66 of 102 Doc: DRX Installation Doc: DRX Installation Page 67 of 102 Version: 7.1 January 2021... -
Page 35: Outline Drawings
DRX INSTALLATION MANUAL 8.2. DRX-46 OUTLINE DRAWINGS 132.50 20.50 265.00 377.00 Figure 35. DRX-46 Assembly Figure 34. DRX-32 Back Plate Dimensions wassp.com wassp.com Page 68 of 102 Doc: DRX Installation Doc: DRX Installation Page 69 of 102 Version: 7.1 January 2021... - Page 36 DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL Figure 37. DRX-46 Back Plate Dimensions Figure 36. DRX-46 Front Plate Dimensions wassp.com wassp.com Page 70 of 102 Doc: DRX Installation Doc: DRX Installation Page 71 of 102 Version: 7.1 January 2021 Version: 7.1 January 2021...
-
Page 37: Drx Interconnection
TD_N RD_P RD_N RS422-A Figure 38. IP67 DRX Dimensions BROWN PPS (AUX) For installation instructions please see “Appendix B - Assembly Procedure for IP67 DRX BLUE RxD B POWER (connection to Transducer)” on page 88 WHITE RxD A DC +VE... -
Page 38: Interconnection
+40°C 93 % relative humidity - Vibration DRX-32, WSP-603-20X; “IEC60945 Sweep 2 Hz – 13,2 Hz at ± 1 mm, 13,2 Hz – 100 Hz at 7 m/s2 and for 2 h on each resonance, otherwise 2 h at 30 Hz in all three axes”... -
Page 39: Appendix
APPENDIX A - CABLE DRAWINGS not damaged due to strain from the transducer cable. Ensure that when mounted there is still room to remove the cables from the DRX for servicing. APPENDIX A.1 TRANSDUCER RX The CAT5E cables used in the... - Page 40 RS-232 Connector Transmitter Cable Socket Assembly If the transmitter cable socket needs to be disassembled, use the locking ring tightening tool (supplied with the DRX) to loosen the locking ring. To assemble the 3-pin sealed Function plug: RS-232_Tx Push the following RS-232_Rx Marker identifies pin 1.
- Page 41 NOTE: Depending on equipment, Rx / Tx polarity may be labelled B and A or + and -. This polarity must be maintained as per the example. RS422B Internal DRX wiring of reserved pins is as follows: RS422B Pin RS422A pin...
- Page 42 NMEA0183 OUT B KP2_in View: Looking into the socket on the View: Looking into the socket on the DRX. Wiring view of cable side on plug. DRX. Wiring view of cable side on plug. NMEA0183 OUT A KP2_in_GND GND (Shield)
- Page 43 APPENDIX A.10 KP1 OUT Connector Connector A Key Pulse (KP) can be connected to/from the sensor port of the DRX connection plate. Input can detect a short circuit in addition to a voltage ranging from 0 - 15 V. See “KP (Key Function Pulse) Settings”...
- Page 44 DRX WSP-603-250; DRX-46 Peak current at 24V is 12A Depending on DRX Model, an optional FAN can be added to assist cooling the DRX Recommended 15A Breaker in high temperature environments. The fan connector has two 12V outputs that are switched on when the DRX is turned on/off.
- Page 45 Discharge Module. Connection will result in the ceramics discharging through the module. 4. Adjust the cable NOTE: IP67 DRX units do not have a built in discharge port as that port is used cover to mate for Transmission)
- Page 46 NOTE: The lines will only be flat as shown if there is no electrical or acoustic noise present during the test. 7. Once the boat is in the water, test RJ45 connections by using DRX diagnostic program to verify all channels are at the same level.
- Page 47 DRX INSTALLATION MANUAL APPENDIX C - SUPPORTED SENSORS AND SENTENCES NMEA 0183 sentences output by DRX. Sentences are output from the NMEA 0183 port at The following tables show sensors and sentences currently supported by DRX. This is not 1Hz.
- Page 48 RTK Tide = » Distance from side of transducer; Central (y) AW + DRX GEOID FILE - GPS Z - XDCR Z + XDCR DRAFT + GEOID OFFSET » Distance from transducer face (wet side); 0.007m APPENDIX E.2 SEA LEVEL HEIGHT USING INTERNAL GPS GEOID APPENDIX D.2 GPS ANTENNA MEASUREMENT LOCATION...
- Page 49 DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL APPENDIX F - AUTO CONTROL IN CDX APPENDIX E.3 ENABLING GPS HEIGHT FOR SEA LEVEL HEIGHT AUTO can be turned on in under PROCESSING. tide mode can be enabled in CDX under the TIDE CONTROL.
- Page 50 A WASSP Application usually installed along with WASSP CDX. This application RS-422, RS-422, RS-422, RS-422, RS-422, DATAMANAGER allows recording and playback of DRX data packets (free) and has a number of RS422-A PPS, DC PPS, PPS, other licensed features. 9-32V...
- Page 51 AND RESOURCES WARRANTY DRX products are covered with a one year limited warranty. In order to be covered by the warranty, the WASSP DRX must be registered with WASSP Ltd. The product warranty registration form can be filled in online by going to: http://wassp.com/product-warranty-registration/...
- Page 52 DRX INSTALLATION MANUAL wassp.com Page 102 of 102 Doc: DRX Installation Version: 7.1 January 2021...
