HPC WS-100C Instructions

Instructions
IMPORTANT NOTE: Your new safe arrives with the vault door open. Please follow the combination changing
instructions and test with the vault door open. If, by any chance you find that the vault door is closed before
you have had the chance to change the combination, please refer to the framed "Unlock on Factory Setting"
directions on the next page.
OPERATING & CHANGING INSTRUCTIONS
Before operating the lock or changing the combination, READ THESE INSTRUCTIONS THOROUGHLY.
At the top of the dial ring an index is provided for normal dialing and opening. At the side of the opening
index, a changing index is provided for use only when setting a new combination.
This is a precision lock, therefore, extreme care must be used to align the combination numbers with the index.
Turn the dial slowly and steadily. If, after turning the correct number of revolutions, any number is turned beyond
the index, the entire series of combination numbers must be re-dialed. DO NOT TURN BACK TO REGAIN A
PROPER ALIGNMENT WITH THE NUMBERS. Each time a selected number is aligned with the opening index,
a revolution is counted.
Torque Adjusting Gear
032112
©2012 • HPC, Inc. • Schiller Park, IL • 60176 • USA • www.hpcworld.com

Wall Safe Combination Changing

Torque Adjusting
Instructions
With cover removed
insert a 3/32 allen wrench
into adjusting screw (see diagram).
Turn clockwise to tighten or
counter-clockwise to loosen.
WS-100C
WS-200C
(continued)
0
Fig. 1.
35WSI-000-00
1
