Summary of Contents for AudioBahn AX303P
- Page 1 QUALITY, RLIABILITY, & PURE BLISS MULTI-CHANNEL ELECTRONIC CROSSOVER NETWORK WITH REMOTE CONTROL AX303P OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE...
-
Page 3: Table Of Contents
Table of Contents Table of Contents INTRODUCTION UNIT INTRODUCTION / INSTALLATION CONTROLS AND FUNCTIONS SIGNAL CONNECTIONS WIRE CONFIGURATION FEATURES ADJUSTMENTS AND TROUBLESHOOTING WARNING / DISCLAIMER WARRANTY 13-14... -
Page 5: Unit Introduction / Installation
The AX303P is an electronic crossover network. With this you can install various types of multi-channel amplifier systems into your ehicle. By putting the AX303P in the center of your multi-channel amplifier car stereo system, the unit will provide you with ultimate sound reproduction and distribution. The AX303P crossover unit has built in line drivers which will help you adjust your level settings to match your source unit and amplifiers. -
Page 6: Controls And Functions
Controls and Functions MAIN UNIT AX303P 3 - WAY ELECTRONIC CROSSOVER WITH REMOTE CONTROL 400H X-OVER FREQ INPUT LEVEL IN / OUT INPUT REAR FRONT 15 16 17 1. INPUT LEVEL CONTROL This gain control is used to adjust the sensitivity of the unit to match the radio's output. -
Page 8: Remote Control Unit
17. IN / OUT JACKS You can use this connection if you have another pre-amp audio source or connect two or more AX303P units together. 18. SUBWOOFER OUTPUT JACKS Connect the RCA cable to the subwoofer channel of the amplifier input. -
Page 9: Signal Connections
GROUND: The second slot from the left is the ground or B- terminal. To ground your AX303P, locate a solid metal area close to the crossover that is a good source of ground (preferable the floor). Your best ground will come from a grounding point attached directly to the frame of the vehicle. -
Page 10: Wiring Configuration
Wiring Configuration AX303P AX303P 3 - WAY ELECTRONIC CROSSOVER WITH REMOTE CONTROL 12dB 250H BASS BOOST BASS FREQ 400H X-OVER FREQ HIGH PASS X-OVER FREQ NORMAL BAND PASS INPUT LEVEL REVERSE HIGH PASS PHASE IN / OUT STEREO MONO MODE... -
Page 11: Specifications
Features AX303P Blue acrylic protective cover 2-way input source and 3-way output ports Remote power on/off by remote turn-on Remote control for Q-factor and subwoofer level control DC to DC switching power supply. Fully adjustable subwoofer mid, and high-pass output levels... -
Page 13: Warning / Disclaimer
Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change with out notice. For the most updated Specifications call Audiobahn, or your local Authorized Audiobahn Dealer, or check the Audiobahn website. www.audiobahninc.com...
