Summary of Contents for AudioBahn AX202P
- Page 1 M U LTI - C H A N N EL ELEC TR O N I C C R O SSO VER N ETW O R K W I TH R EM O TE C O N TR O L A X202P A X303P...
-
Page 6: Controls And Functions
Controls and Functions MAIN UNIT AX202P 2 - WAY ELECTRONIC CROSSOVER WITH REMOTE CONTROL 400H X-OVER FREQ INPUT LEVEL IN / OUT INPUT REAR FRONT 12 13 14 15 1. INPUT LEVEL CONTROL This gain control is used to adjust the sensitivity of the unit to match the radio's output. - Page 7 13. IN / OUT JACKS You can use this connection if you have another pre-amp audio source or connect two or more AX202P units together. 14. SUBWOOFER OUTPUT JACKS Connect the RCA cable to the subwoofer channel of the amplifier input.
- Page 8 Controls and Functions MAIN UNIT AX303P 3 - WAY ELECTRONIC CROSSOVER WITH REMOTE CONTROL 400H X-OVER FREQ INPUT LEVEL IN / OUT INPUT REAR FRONT 15 16 17 1. INPUT LEVEL CONTROL This gain control is used to adjust the sensitivity of the unit to match the radio's output. 2.
- Page 9 13. IN / OUT JACKS You can use this connection if you have another pre-amp audio source or connect two or more AX202P units together. 14. HIGH-PASS GAIN CONTROL By turning this control clockwise, you increase the high channel level.
-
Page 10: Remote Control Unit
22. POWER LED This blue LED light up when the unit is on. REMOTE CONTROL UNIT LEVEL AX202P 1. SUBWOOFER GAIN CONTROL This control adjusts the subwoofer gain control. 2. Q SELECT Allows independent, continuous change of the boost frequency bandwidth (Q-factor) for each band from 20 (narrow bandwidth, steep slope), to 2 (wide bandwidth, gentle slopes). -
Page 11: Signal Connections
Leave the ground wire disconnected until all components are hooked up and the stereo is ready to play. Remove the power terminal from the AX202P / AX303P before fastening the wires into the correct slots as a precaution. Make sure you are looking at the terminal with the set screws facing upwards while following the instructions. - Page 12 W i r i ng C onf i gur at i on A X202P A X202P 2 -W A Y ELEC TR O N I C C R O SSO VER W I TH R EM O TE C O N TR O L PW R 12dB 400H...
- Page 13 W i r i ng C onf i gur at i on AX303P AX303P 3 -W A Y ELEC TR O N I C C R O SSO VER W I TH R EM O TE C O N TR O L 12dB 250H B A SS B O O ST...
- Page 14 Features AX202P Blue acrylic protective cover 2-way input source and 2-way output jacks Remote power on/off be remote turn-on Remote control for Q-factor and subwoofer level control DC to DC switching power supply. Fully adjustable subwoofer and high-pass output levels...
-
Page 15: Specifications
Specifications AX202P Adjustable bass boost and bass frequency (25Hz - 250Hz) Q-factor: 20-2 (variable) Selectable crossover frequency -Subwoofer (Low-pass): 40Hz - 400Hz -High-pass: 40Hz - 8kHz Power supply: 10 - 16V DC negative ground Input impedance: 10K ohm S/N ratio: > 85dB... -
Page 17: Warning / Disclaimer
Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change without notice. For the most updated Specifications call Audiobahn, or your local Authorized Audiobahn Dealer, or check the Audiobahn website. www.audiobahninc.com...
