Summary of Contents for Samyung ENC SI-30A

  • Page 1 Class Class A A A A AIS Transponder Class Class AIS Transponder AIS Transponder AIS Transponder SI-30A Manual Instruction SAMYUNGENC CO.,LTD.
  • Page 3 Instruction * The following settings can be modified only the dealer. 1. How to set MMSI IMO & Name, Call sign 1-1 SETTING MENU key→ 2.INIT SETUP → ENT → 2.SET STATIC DATA → ENT → Password → ENT 1-2 Choose setting with arrow keys and then input the data. (After input, press ENT key) 1-2-1 .
  • Page 4 3. How to set Port transmission ratio 3-1 SETTING MENU key → 3.SYSTEM SETUP → ENT → 1.SET I/O PORT → ENT → Password → ENT 3-2 Definition of Each Port 3-2-1. LONG : Long Range Port(38400/4800) 3-2-2. External Display(38400/4800) 3-2-3.
  • Page 5 To prevent the unit from damaging due to electrostatic, operator should seek suitable preventive measure before operating. Handling circuit related working should be carried out by technicians who specialize for the electronic device sensitive. Dismantling SI-30A is restricted to the person who is authorized by Manufacturer.
  • Page 6: Table Of Contents

    NTENNA AND ECEIVER ......................5 2-8 E NVIRONMENT ........................... 6 2-9 C OMPOSITION ............................ 7 2-9-1 SI-30A Basic Specification ...................... 7 2-9-2 SI-30A Optional Specification ....................7 3. HOW TO USE SI-30AM(MKD)......................8 3-1 O PERATION ............................8 3-1-1 Button description ........................
  • Page 7 3-4-4 Indication of letter’s information ..................16 3-4-5 Display of Range Ring ......................16 3-4-6 Display of chart ........................17 3-4-7 Transfer of cart ........................17 3-4-8 Use of cursor ........................... 18 3-4-9 Changing screen / Data view ....................19 3-5 OWN SHIP DATA DISPLAY ......................
  • Page 8 3-10-7 PROGRAM DOWNLOAD ..................... 38 3-10-8 PROGRAM UPLOAD ......................38 3-11 T AIS ....................39 HE EXPLANATION SIGNS OF 4. THE INSTALLATION METHOD AND EXPLANATION EQUIPMENT .......... 40 4-1 T HE EXPLANATION METHOD ......................40 4-1-1 Front side ..........................40 4-1-2 Back Side ..........................
  • Page 9 6-6 D RAWINGS ............................65 6-6-1 External Connection ......................... 65 6-6-2 Port Connection ........................66 6-6-3 SI-30A OUTLINE DRAWING ....................67 6-6-4 SI-30AM OUTLINE DRAWING ....................68 6-6-5 SAN-150 ANTENNA OUTLINE DRAWING ................69 6-6-6 SAN-60 ANTENNA OUTLINE DRAWING ................70...
  • Page 11: Automatic Identification System

    1. Automatic Identification System 1-1 AIS OUTLINE AIS is a very developed equipment which provides information of the vessel in real time. This equipment is prevent for collision and this is duty by IMO. AIS make you enable to recognize position of another vessel and it’s moving during radar isn’t working properly, to recognize name, position and speed of another vessel so that it prevents for collision.
  • Page 12: Interval Of Renewal Ais Data For Each Class

    1-4 Interval of renewal AIS data for each class Status of vessel(A Class) Interval Under 3knot during anchorage or mooring 3 min Over 3knot during anchorage or mooring 10 sec Sailing under at 14knot 10 sec Changing course during sailing under 14knot 3⅓...
  • Page 13 Dynamic Information - Universal Time Coordinated(UTC) - Ship’s position - Course over Ground (COG) - Speed of Ground (SOG) - Heading - Ratio of turn - Navigation Status - Ship’s condition Message - Alarm - Safety When you input the static information for radio station, please download the software from ‘product information’...
  • Page 14: Product Specification

    2. PRODUCT SPECIFICATION 2-1 Designed to meet the following standards IEC61993-2 ..........IEC standard, Class A shipborne equipment IEC60945 Edn 4.0 ........ IEC standard, environmental requirements ITU-RM.1371-4 ........Universal AIS Technical Characteristics IEC61162-1/2 Edn. 2.0 ......IEC standards, digital interfaces IEC61108-1 ..........
  • Page 15: Ais Receivers

    2-4 AIS Receivers Sensitivity ..........(PER) < 20% at –107 dBm Channel spacing ........25 kHz Modulation..........GMSK Data rate............ 9600 bits/s Frequency stability........ <±1 ppm Co-Channel ..........10dB Adjacent Channel ........70dB IMD .............. 65dB Blocking ............. 84dB 2-5 DSC Receivers Sensitivity ..........
  • Page 16: Environment

    2-8 Environment Operation temperature ...... -15°C to +55°C Storage temperature......-25°C to +75°C Relative humidity........95% at 40°C (without dew condensation) Vibration ............ IEC 60945...
  • Page 17: Composition

    2-9 Composition 2-9-1 SI-30A Basic Specification Item Standard Quantity Remark Transponder SI-30A E02-3000-00 Equip. for install SI-30A-A-K 1SET SI-30AM E02-4000-01 VHF Antenna SAN-150 542-1400-0D Bracket Bracket 35 Ass'y 1SET 575-0006-01 Cable Ass'y PL259-30M(RG8)-PL259 1SET 574-0155-24 GPS Antenna SAN60-30M(RG58)-TNC 1SET 574-9999-02...
  • Page 18: How To Use Si-30Am(Mkd)

    3. How to use SI-30AM(MKD) - DC 12V (Warning) A version of programme could be adjusted without notice. 3-1 Operation 3-1-1 Button description It shows alphanumeric and symbol input buttons. To input alphabet and various buttons, press the assigned button until the wanted button is displayed. S I - 3 0 A...
  • Page 19 Display information of the vessel what you choose. <([@ <([@ Display of geographical name & Depth. Display range of ring. Display map. To move map moving or to choose another vessel. To check vessel’s position or to make cursor in the centre of display. To move cursor.
  • Page 20: Led

    Length and width, Type of ship and Position of GPS antenna. Safety related information should be reported on request. SI-30A should be power on while navigation or at anchor. However, ship’s master may decide power off when he judged that ship’s safety and security might be threatened due to constant operation of AIS.
  • Page 21: List Display

    3-3 List Display 3-3-1 List Display description Home screen is displayed as below and each section means as following. < Target data display > 1. Distance from vessel to target 2. MMSI (Maritime Mobile Service Identity) 3. Vessel’s position, speed and information of azimuth 4.
  • Page 22: How To Set Ship's Name And Mmsi

    3-3-2 How to set ship’s name and MMSI You can see all list of vessels which shares information with AIS and see the detailed information additionally. When you press MMSI(F1), it displays MMSI number or ship’s name. After choosing a vessel with arrow keys and Enter key, you can see the information what you selected.
  • Page 23: Message Icon

    3-3-4 Message icon There are 4 icons in the right and below corner which is for message sending and receiving. Icon Description Remark There is a message received. There is no message received or means it’s been read already. Alarm from transponder Each status from transponder Displays safety or other message received Displays message concerned with long range...
  • Page 24: Plotter (Graphic) Screen

    3-4 Plotter (Graphic) screen 3-4-1 Explanation of plotter screen If PLOT(F2) key is pressed, the unit displays plotter screen. < Plotter screen configuration > 1. The information of selected vessel 2. The selected vessel 3. The other vessels received information 4.
  • Page 25: Chat Direction / Distance Settings

    3-4-2 Chat direction / Distance settings Available for displaying North-up and Heading-up using N-UP/H-UP(F4)key. North-Up Heading-Up No. 8 key, No. 9 key and up/down key on keyboard accept to adjust nautical mile. The unit can display from 0.25nm to 64nm. The distance information is on the bottom of left side of the screen And the unit accepts to search the information of other vessels using direction key (right/left) After 10 minutes from plotter screen mode, the part of subject (The indication of [TARGET...
  • Page 26: Indication Of Letter's Information

    3-4-4 Indication of letter’s information If No.2 key is pressed, user can display or delete information of letter’s information (name of place, depth & etc). Display of information No information 3-4-5 Display of Range Ring If No.3 key is pressed, user can display or delete Range Ring. Display of information No information...
  • Page 27: Display Of Chart

    3-4-6 Display of chart If No. 4 key is pressed, user can display or delete the chart on the screen. Display of chart No chart on the screen 3-4-7 Transfer of cart If No.5 key is pressed, the “ZOOM” on the bottom is changed to “MOVE” in red. User can move the chart using direction keys.
  • Page 28: Use Of Cursor

    3-4-8 Use of cursor If No.7 key is pressed, cursor will appear. Users can move chart and select other vessels using cursor. Chart is on the center of screen Chart is moved User can move cursor using direction key. If the cursor is get out of screen, the place cursor was located is moved to the center of screen.
  • Page 29: Changing Screen / Data View

    3-4-9 Changing screen / Data view Press LIST(F1) key for changing to the screen of objects list mode of initial screen. Information on the plotter screen is the standard information for the objects. For more detailed information, press INFO(F2) to display information as below pictures. Using direction key, user can 3 separated pictures.
  • Page 30: Own Ship Data Display

    3-5 OWN SHIP DATA DISPLAY Press OWN(F4) to see information related own ship and navigation. PAGE 1 PAGE 2 PAGE 3 Ship name, MMSI number, IMO number, call sign, ship type, ETA, destination & etc are shown on page 1. Longitude, latitude, CDG(Course Over Ground), SOG(Speed Over Ground), heading information, ROT(Rate of Turn), Navigation status &...
  • Page 31: Composition & Usage Of Menu

    3-6 COMPOSITION & USAGE OF MENU 3-6-1 Composition of menu [ MESSAGE & LOG ] 1. NEW MESSAGE 2. FAVORITE MESSAGE 3. LONG RANGE MESSAGE LIST 4. RxD MESSAGE LIST 5. TxD MESSAGE LIST 6. ALARM LIST 7. STATUS LIST [ INIT SETUP ] [ MENU ] 1.
  • Page 32: Message Setup

    3-7 MESSAGE SETUP Massage TX, massage RX, alarm & alarm status from system are displayed. 3-7-1 NEW MESSAGE Press“MENU” → “1.MESSAGE & LOG” → “1. NEW MESSAGE” to display the below picture. Send the written massage to other party. NEW MESSAGE screen DESTINATION : Select broadcast, MMSI number &...
  • Page 33: Favorite Messages

    3-7-2 FAVORITE MESSAGES Press“MENU” → “1.MESSAGE & LOG” → “2. FAVORITE MESSAGE” to display the below screen. This function is used to make new message and send the selected data using saved messages. FAVORITE MESSAGES screen Press SELECT(F2) to change to [New Message] screen. Press DELETE(F3) to display the screen for selecting to delete massage or not.
  • Page 34: Rxd Message

    3-7-4 RxD MESSAGE Press “MENU” → “1.MESSAGE & LOG” → “4.RxD MESSAGE LIST” to display the below screen. RxD Message show reception date, type (broadcast, individual cases), time, sender and received message. RxD MESSAGE LIST screen EX) In the above pictures, Message type is broadcast, MMSI no. of sender is 123456789, time is September 15, 09:00, message contents is “@@TEST”.
  • Page 35: Alarm Message

    number of the ship received message. “PREV(F1)” : To return to initial screen. “FRWD(F2)” : To send messages to other parties. “DELETE(F4)” : To delete data. 3-7-6 ALARM MESSAGE Press“MENU” → “1.MESSAGE & LOG” → “6. ALARM LIST” to display the below screen.
  • Page 36: Status Message

    3-7-7 STATUS MESSAGE Press“MENU” → “1.MESSAGE & LOG” → “7. STATUS LIST” to display the below screen. User can see the information regarding the status of the unit in real time. STATUS LIST screen The below is the explanation about above status message screen 09-16 00:19 : AIS: Heading valid : Information for heading is correct.
  • Page 37: Initial Setup

    3-8 INITIAL SETUP The initial setup display is divided into 5 (five) sub-items as follows; It includes SET VOYAGE DATA, SET STATIC DATA, SET REGIONAL AREAS, SET LONG RANGE, SET GNSS ANTENNA POSITION etc. Order to do the initial setup, must input password. 3-8-1 VOYAGE DATA From “MENU”...
  • Page 38: Static Data

    3-8-2 STATIC DATA From “MENU” button, go to “2. INIT SETUP” and go to “2. SET STATIC DATA”, then a following screen will appear. This screen is for inputting the static data on vessels that are in use. Ship name means the name of the ship (Max.
  • Page 39: Long Range Mode

    regional operation. REGIONAL AREAS CREATE SCREEN For any changes or corrections, use button(up and down arrow) or # key button to move the wanted item. 3-8-4 LONG RANGE MODE From “MENU” button, go to “2. INIT SETUP” and go to “4. SET LONG RANGE”, then a following screen will appear.
  • Page 40: Gnss Antenna Position

    3-8-5 GNSS ANTENNA POSITION From “MENU” button, go to “2. INIT SETUP” and go to “4. SET GNSS ANTENNA POSITION”, then a following screen will appear. The function is to set a position of internal GPS antenna and external GPS antenna. GNSS ANTENNA POSITION SCREEN The internal means a position of internal GNSS antenna and the external on right side means a position of external GNSS antenna.
  • Page 41: System Setup

    3-9 SYSTEM SETUP As of SI-30A’s a function to set a definition of baud rate (SET I/O PORT) with MKD, transponder or external equipment, and a definition of luminosity and brightness adjustment (SET DISPLAY) alarm of MKD display, and a noise out of keypad (SET BUZZER) and to set alteration of password (SET PASSWORD), and to set initialization of system (INITIALIZE SYSTEM).
  • Page 42: Brightness Adjustment

    3-9-2 BRIGHTNESS ADJUSTMENT From “MENU” button, go to “3. SYSTEM SETUP” and go to “2. SET DISPLAY”, then a following screen will appear. It is available to adjust and modify LCD brightness, LED brightness of Keypad as a composition of moving to left / light on a screen. SET DISPLAY SCREEN Adjust for LED of Keypad is available by using button on LD BRIGHTNESS, and...
  • Page 43: Set Password

    occurs when various buttons of MKD pad are pushed. Alarm Buzzer: a function enabling users to set up the occurrence of various alarm signals delivered from transponder under systems operation. The buzzer/on creates sound while the buzzer/off eliminates sound. 3-9-4 SET PASSWORD From “MENU”...
  • Page 44 before receiving a position of a ship’s value on a plotter screen. Reset TP when Boot: When MKD starts, transponder will be restart. Use Standard Sym.: use of standard shape of symbol for the target. Show Alarm Message: it can be setup as warning with alarm message. LANGUAGE MODE: Choose one of following language (in ENGLISH, KOREAN, and/or CHINESE) CPA/TCPA ALARM: it can be select as warning with alarm between current distance...
  • Page 45: Maintenance

    3-10 MAINTENANCE System maintenance is a function to test and keep main functions of system and the users can test the functions by using the function of maintenance anytime. Main function is PROGRAM VERSION, KEY TEST, LCD TEST, COM MONITORING between transponder and MKD, SECURITY LOG and so on.
  • Page 46: Lcd Test

    3-10-3 LCD TEST From “MENU” button, go to “4. MAINTENANCE” and go to “3. LCD TEST”, then a following screen will appear. For test method, when press “ENT” button, it turns to five different type of colors. BEFORE LCD TEST SCREEN AFTER TEST SCREEN CHANGES COLOR 3-10-4 COM MONITORING From “MENU”...
  • Page 47: Security Log

    3-10-5 SECURITY LOG From “MENU” button, go to “4. MAINTENANCE” and go to “4. SECRUITY LOG”, then a following screen will appear. It is a function to record the occurrence took place like System ON/OFF record, VSWR error and System Alarm. Power off 0000:21 on 10 Jun 05 01:30...
  • Page 48: Program Download

    3-10-7 PROGRAM DOWNLOAD From “MENU” button, go to “4. MAINTENANCE” and go to “7. PROGRAM DOWNLOAD”, then a following screen will appear. PROGRAM DOWNLOAD is for executing upgrade for software. This function is to delete a previous program as a downloading into MKD connecting to external PC and reinstall a new program.
  • Page 49: The Explanation Signs Of Ais

    PROGRAM UPLOAD SCREEN 3-11 The explanation signs of AIS This equipment of AIS shows 4 different signs and each sign has functions as below. : The sign for the pausing ship : The sign for the moving ship : The sign when you choose a ship. : The sign for the ship which is in danger The meaning of signs show as below COG/SOG : It means Course of ground, Speed of Ground.
  • Page 50: The Installation Method And Explanation Equipment

    4. The Installation method and explanation equipment 4-1 The explanation method 4-1-1 Front side ON Status Error SI-30A Class A AIS T ransponder Function Remark The LED light is on when the power is connected. Red LED Status LED light is on when the Transponder receives UTC Sync...
  • Page 51: Back Side

    4-1-2 Back Side RS-422 INTERFACE FUSE(7A) GNSS MKD INTERFACE POWER 12V DC 1. VHF – ANT Receiving the signal of VHF . 2. MKD INTERFACE And Power (RS-422) The port for the communication with MKD, it communicates with the form of NMEA0183 DATA.
  • Page 52: The Method Of Installation

    4-2 The method of installation SI-30A is designed for installing to the existing bridge easily, it shows the occupation of general system on outer wiring diagram in Annex. We suggest that all components such as VHF antenna, Plotter, MKD should be installed According to the instruction as manufacturer provides.
  • Page 53: How To Setup Antenna

    4-3-1 How to setup Antenna VHF Antenna is for keeping TX/RX in good performance, please kindly refer below instructions when you install VHF Antenna. Generally, VHF Antenna should be installed in high position as far away from other equipment. And it should be away at least 2M from the conductivity materials. Further, it should not be installed in near by vertical material and secured a 360 view.
  • Page 54: When You Install Vhf Antenna, Please Check Bellows

    4-3-2 When you install VHF Antenna, please check bellows. The position of bracket. The bracket should be substantial spot. Put the antenna on Antenna’s mount. Use RG-8U (coaxial cables) cables and keep shortened cables if possible. Leave some length of cables to the terminal. Put the connector at either ends of coaxial cables.
  • Page 55: Maintenance And Troubleshooting

    5. Maintenance and Troubleshooting 5-1 Maintenance and Troubleshooting of System It is quite necessary to do periodical maintenance and troubleshooting for keeping performance of unit in good order. It means periodical unit test, and software upgraded if necessary but which following items should be included. ITEM CONTENT Connector/Terminal...
  • Page 56: Appendix

    6. Appendix 6-1 NMEA sentences used The ports on the SI-30A transponder accept and output different combinations of NMEA sentences as follows: Port Input sentences Output sentences Main, Display and Aux ACA, ABM, BBM, ACK, AIR, ABK, ACA, ACS, ALR, LRI, LRF, LR1, (“Presentation ports”)
  • Page 57 Transceiver connection lost This message indicates that the SI-30A display unit can no longer communicate with the SI- 30A transponder. This may indicate a problem with the connections, or may indicate that the transponder is no longer operating correctly. This fault should be investigated immediately. It is important to note that there is a safety timer in the transponder which causes it to shut down automatically if the transmitter should remain on for too long.
  • Page 58 SI-30A transponder unit. Such messages should be investigated immediately.
  • Page 59 Rate of Turn indicator in use Other ROT source in use The first of these messages indicates that the SI-30A transponder is using Rate of Turn information from an on-board device which directly calculates the rate of turn - such as a gyro compass.
  • Page 60: Decoded Sentences

    6-2-1 Decoded Sentences The sentence types listed in the table below are decoded by the Transponder. Formatter Source Primary function Optional function Comment VDL Ack Addressed binary message Broadcast binary message Interrogation Channel assignment Sensor Rate of turn Sensor Heading Heading Sensor GNSS...
  • Page 61: Message Structures

    6-3 Message structures Message structures are shown in the format used in IEC 61162-1 6-3-1 ABK - AIS addressed and binary broadcast acknowledgement The ABK sentence is output by the transponder on the presentation ports in response to the receipt of an ABM, AIR or BBM sentence. Its purpose is to inform the requesting device about the success or failure of its request.
  • Page 62: Ack - Acknowledge Alarm

    ⑮ time of “in use” change The ACA sentence is used both to send channel management information to the transponder and to obtain channel management information from it. 6-3-4 ACK – Acknowledge alarm This sentence is used to acknowledge an alarm condition. $--ACK ,xxx *hh<CR><LF>...
  • Page 63: Alr - Alarm Condition And Status

    6-3-7 ALR – Alarm condition and status This sentence is sent by the transponder to all presentation ports order to report an alarm condition on a device. It identifies the source of the alarm, whether it has been acknowledged or not and the time at which the condition changed. $--ALR ,hhmmss.ss ,xxx ,A ,A ,c--c *hh<CR><LF>...
  • Page 64: Gbs - Gns Satellite Fault Detection

    ⑤ Altitude offset, m ⑥ Reference datum Note that the only datum supported by AIS is WGS84. The DTM sentence must be sent to the transponder at a frequency of more than once every 30 seconds otherwise any positional information sentences (eg GLL, GNS. RMC and GGA) will be ignored. 6-3-10 GBS –...
  • Page 65: Gns - Gnss Fix Data

    Note that DTM sentences must be received by the transponder at least once every 30 seconds in order for the GLL sentence to be accepted. 6-3-13 GNS – GNSS fix data The transponder may receive this sentence from other sensors and uses the information in its own calculations of the ship’s current position.
  • Page 66: Lr3 - Ais Long-Range Reply 3

    ① sequence number ② MMSI of responder ③ date ④ UTC time of position ⑤ latitude, N/S ⑥ longitude, E/W ⑦ True ⑧ speed over ground, Knots course over ground, deg 6-3-17 LR3 - AIS long-range reply 3 The LR3 sentence contains further information items that can be requested in an LRF sentence.
  • Page 67: Osd - Own Ship Data

    ① sequence number ② control flag ③ MMSI of requestor ④ MMSI of destination ⑤ latitude, N/S (NE co-ordinate) ⑥ longitude, E/W (NE co-ordinate) ⑦ latitude, N/S (SW coordinate) ⑧ longitude, E/W (SW coordinate) 6-3-20 OSD – Own ship data Heading, course, speed, set and drift summary.
  • Page 68: Rot - Rate Of Turn

    ⑦ date ⑧ magnetic variation ⑨ mode indicator (‘A’, ‘D’, ‘E’, ‘M’ -> used; ‘N’ -> invalid) Note that RMC has priority over VTG. 6-3-22 ROT – rate of turn This sentence provides the rate and direction of turn. $--ROT ,x.x ,A *hh<CR><LF> ①...
  • Page 69: Txt - Text Transmission

    6-3-25 TXT – text transmission This sentence is used for transmitting text messages such as alarm messages from a sensor or the transponder to any presentation display device such as the SI-30A Display unit. $--TXT ,xx ,xx ,xx ,c--c *hh<CR><LF>...
  • Page 70: Vsd - Ais Voyage Static Data

    !--VDO ,x ,x ,x ,a ,s—s ,x *hh<CR><LF> ① ② ③ ④ ⑤ ⑥ ① total number of sentences needed to transfer message ② sentence number ③ sequential message identifier ④ AIS Channel (‘A’ or ‘B’) ⑤ encapsulated ITU-R M.1371 radio message ⑥...
  • Page 71: Abbreviations

    6-4 Abbreviations : Ship-to-Ship & Ship-to-Shore : Automatic Identification System : Alarm : Antenna ARPA : Automatic Radar Plotting Aid : Automatic Tracking Aid AtoN : Aid to Navigation : Auxiliary AUTO : Automatic BI IT : Built-In Integrity Test : Battery BRILL : Display Brilliance...
  • Page 72 : Navigation : Nautical Mile : Not Under Command : Officer Of the Watch : Own Ship : Output : Presentation Interface POSN : Position : Portable Pilot Unit : Power RAIM : Receiver Autonomous Integrity Monitoring : Range RORO : Roll On, Roll Off : Rate Of Turn : Range Rings...
  • Page 73: Packing List

    6-5 PACKING LIST SI-30A Item External Feature Standard Q’ty Remark SI-30A Transponder CODE NO. E02-3000-00 S I - 3 0 A SI-30AM CODE NO. E02-4000-01 DSUB25-7M-DSUB25 Cable Ass'y A-03 OPT. 10M CODE NO. 574-0166-01 SCN3-3M-02 Cable Ass'y Cable Ass'y A-05 CODE NO.
  • Page 74 CODE NO. 527-2010-1Q 01-3M-D01 Cable Ass'y 5.5SQ Cable Ass'y B-03 OTYPE CODE NO. 574-0102-01 Stain Truss Piece 4X16 Screw CODE NO. 904-0446-01 SI-30A OPTION GYRO CONVERTER Item External Feature Standard Q’ty CHK Remark GYRO SAD-30DC Option CONVERTER CODE NO. SIS-5-26...
  • Page 75: Drawings

    6-6 Drawings 6-6-1 External Connection...
  • Page 76: Port Connection

    6-6-2 Port Connection...
  • Page 77: 30A Outline Drawing

    6-6-3 SI-30A OUTLINE DRAWING...
  • Page 78: 30Am Outline Drawing

    6-6-4 SI-30AM OUTLINE DRAWING...
  • Page 79: San-150 Antenna Outline Drawing

    6-6-5 SAN-150 ANTENNA OUTLINE DRAWING 1380...
  • Page 80: San-60 Antenna Outline Drawing

    6-6-6 SAN-60 ANTENNA OUTLINE DRAWING...
