Summary of Contents for Pearl River F12

  • Page 2 Safety Guideline Before playing the digital piano, please read the following content. Please put this instruction book in a safety place, in order to read it in the future. Warning In case of getting seriously injured or killed because of electric shock, short circuit, damage, fire or other dangers, please obey the following warnings.
  • Page 3 If any liquid, like water, splashes into the instrument, please cut off power and pull out the electric cable from the AC socket immediately. Then ask qualified Pearl River service staffs to examine and repair the device. Do not plug with wet hands.
  • Page 4 Ask qualified Pearl River service staffs to examine and repair the device. Attention In case that people around you and you get injured or get loss of device and property, please obey the following basic instructions.
  • Page 5 Do not connect the instrument to the socket by multiple connector, or it will lower the sound quality, or it will make socket overheat. Assemble Use Please carefully read the attachment that explains the assemble process. If assembling the instrument in a wrong order, it will damage the instrument and hurt the user.
  • Page 6 television or radio nearby. Please do not put this device on unstable place, or it may cause a sudden fall down. Before moving the device, please pull out all electric cables from the socket. When you set this device, please confirm the AC socket going to be used is reachable.

  • Page 7: Table Of Contents

    Catalogue Installation Guideline……………………………………………………… 8 Control Panel………………………………………………………………… 9 Power On\Adjust Volume\Headphone Connection ……………………… Record Function\Play/Stop\ Play Demo Song …………………………… Accompany Function\ Syn Start ………………… ………………… …… Variation … ……………………………………………………………… … … Voice Control\Teaching Function ………………………………………… 14 Voice Restoration\Metronome …………………………………………… Function Control\Chord ……………………………………………………… 16 Accompany Volume\Octave ……………………………………………...
  • Page 8 Reverb\ Chorus ………………………………………………………………… Beat\ Touch …………………………………………………… ……………… 23 …… Percussion ……………………………………………………………………… 24 Bluetooth function ………………………………………………………………… 24 Back Inserting Panel Funciton ………………………………………………… 25 USB MIDI Function\Audio Connection ………………………………………… 26 Sound List ………………………………………………………………………… 27 Rhythm List …………………………………………………………………… 27 MIDI Keyboard Percussion Check List ………………………………………… 28 Demo Song List …………………………………………………………………...

  • Page 9: Installation Guideline

    Thank you for buying Our Digital Piano. No matter you are a student, piano hobbyist or the professional, this digital piano will impress you with its perfect sound and fashion design. It can be competent with piano studying, music listening, MIDI production, which satisfies your entertainment demand. It also has grand hammer dynamics keyboard, making you express yourself easily.

  • Page 10: Control Panel

    Control Panel All the function keys are on the left side control panel of the digital piano. VOICES FUNCTION METRONOME RECORD PLAY/STOP PRELUDE/CODA A/FILL 1 START/STOP B/FILL 2 SYNC START DATA/ TEMPO DEMO/TEACHING RHYTHM VOICES...

  • Page 11: Power On\Adjust Volume\Headphone Connection

    Turn On/Off the Power 1）Press the [Power] switch to turn the power on/off. 2) The default voice is grand piano. POWER Adjust Volume Turn the Volume button on the control panel to set the volume. Volume Turn the button clockwise to raise volume. Turn the button anticlo ckwise to reduce volume Warning: Too loud sound, especially when you wear the headphone, will do damage to hearing.

  • Page 12: Record Function\Play/Stop\ Play Demo Song

    Record Function Start recording: Press [RECORD] button and the indicate light turns on, which RECORD means entering the record status. Meanwhile, the metronome starts auto- matically. It can be turned off manually if it isn't needed. (This digital piano has accompaniment track which can be recorded) End recording: Automatic Ending: During the recording process, when the storage space is full, recording will end automatically.

  • Page 13: Accompany Function\ Syn Start

    Accompany Function Select Rhythm: Press [RHYTHM] button to activate rhythm DATA/ selection. Press [DATA/ +/-] button to select rhythm TEMPO RHYTHM TEMPO within 5 seconds. (The rhythm list is in the appendix) Adjust accompaniment velocity: The [RHYTHM] indicator DEMO/TEACHING light turns off 5 seconds later after the rhythm is activated. Meanwhile, press [DATA/ +/-] button to adjust automatic TEMPO...

  • Page 14: Variation

    Variation PRELUDE/CODA: Before the automatic accompaniment starts, PRELUDE/CODA press [PRELUDE/CODA] button to start prelude and enter the main musical A status automatically; When the automatic accompani- ment is playing, press the [PRELUDE/CODA] button and the automatic accompaniment will stop automatically after playing a piece of coda. Fill in A-B: In automatic accompaniment status, press[A/FILL 1] B/FILL 2 A/FILL 1...

  • Page 15: Voice Control\Teaching Function

    Voices Control The default voice is 000 after power on. Voices select: Press [VOICES] Button to activate voices selection function. OLED will display corresponding voice number. Press [DATA/TEMPO+/-] button to select any voice within 5 seconds. DATA/ VOICES TEMPO VOICES DEMO/TEACHING Select Next Voice Teaching Function...

  • Page 16: Voice Restoration\Metronome

    Voice Restoration No matter in what playing status, long press [VOICES] button twice VOICES and the digital piano will return to original status. The default voice is Grand piano. Metronome 1) Press [METRONOME] button on control panel to start metronome and the indicator light will flash.

  • Page 17: Function Control\Chord

    Function Control As a user-friendly instrument, all functions in this digital piano can be activated easily. Every function is corresponding to a key. (The name of each function is printed under the key for reference.) DUALVOICE SPLIT SPLITPIANO SPLIT POINT EFFECT EFFECTOFF REVERB...

  • Page 18: Accompany Volume\Octave

    2) Press [FUNCTION] button, indicator light turns on. Press [CHORD OFF] button within 5 seconds to turn off automatic chord function. Accompany Volume 1) Press [FUNCTION] button, indicator light turns on. FUNCTION Press [ACCOMPANIMENT VOLUME+/-] button within 5 seconds to adjust accompaniment volume. 2) Press [FUNCTION] button again or wait for 5 seconds ACCOMPA- CHORD...

  • Page 19: Transposition\Soundboard Resonance

    Transposition This function can transpose a note to +/-12 semitone in a range of octachord. 1) Press [FUNCTION] button and indicator light turns on. FUNCTION Press [TRANSPOSITION +/-] button within 5 seconds to adjust pitch. Adjusting range: -12 to +12. 2) Press [FUNCTION] button again or wait for 5 seconds ACCOMPA- CHORD...

  • Page 20: Dual Voices

    Dual Voices 1) Press [FUNCTION] button, indicator light turns on. FUNCTION Press [DUAL VOICE] button within 5 seconds toenter dual voices status. DUALVOICE SPLIT SPLITPIANO SOUNDBOARD KEYBOARD FUNCTION RESONANCE 2) Select 2nd voice by [DATA/TEMPO+/-] button. 1st voice should be adjusted before pressing [DUAL VOICE] button.

  • Page 21: Split

    Split This function can divide the keyboard into two individual playing zones. Right Keyboard Left Keyboard Before pressing [SPLIT] button, select voice for the left keyboard; Press [FUNCTION] button,the indicator light turns on, press [SPLIT] button within 5 seconds to enter split status. The keyboard is divided into two individual zones.

  • Page 22: Keyboard Split Point Setting\Effect

    Keyboard Split Point Setting Press [FUNCTION] button and the indicator light turns on. Press [SPLIT POINT] button within 5 seconds to enter split point setting status. Now press a key to set the split point; Press [FUNCTION] button again or wait for 5 seconds without controlling until the indicator light turns off, the split point is set.

  • Page 23: Reverb\ Chorus

    Reverb 1) Press [FUNCTION] button and the indicator light turns on. FUNCTION Press [REVERB] button within 5 seconds to activate rev- erb function and sound will have reverb effect. 2) Press [FUNCTION] button and the indicator light turns on. EFFECT EFFECTOFF REVERB REVERBOFF...

  • Page 24: Beat\ Touch

    Beat This digital piano has six kinds of beats, which are 1,2,3, FUNCTION 4,5,6. Press [FUNCTION] button and the indicator light turns on. Press corresponding beat key within 5 seconds to set. Press [FUNCTION] button again or wait for 5 seconds without SOFT STANDARD HARD...

  • Page 25: Percussion

    Percussion 1) Press [FUNCTION] button and the indicator light turns on. Press [PERCUSSION ON] button within 5 seconds to activate percussion. Press [DATA/TEMPO+/-] button to select percussion from 00 to 09. 2) Press [FUNCTION] button and the indicator light turns on. Press [PERCUSSION OFF] button within 5 seconds to turn off percussion function.

  • Page 26: Back Inserting Panel Funciton

    Back Inserting Panel Funciton LINE LINE (1) Line Out Stereo output, connect the digital piano to a peripheral speaker system (2) Line In Stereo Input, connect the digital piano to a built-in speaker system (3) USB USB MIDI Jack (4) Power Connect power adapter...

  • Page 27: Usb Midi Function\Audio Connection

    USB MIDI Function Connect the computer to the USB MIDI Jack in the back inserting plate to get MIDI ● Production Function. USB TO HOST Connection Digital Piano Back Inserting Plate USB Jack Audio Connection Line In: Connect the musical instrument to the built-in speaker system, regarding the digital piano as speaker.

  • Page 28: Sound List

    Voices List Number Instrument Number Instrument PIANO GRD HAMND ORG PIANO BRITE CHURCH ORG HONKY-TONK GTR NYLON E PIANO1 ACOU BASS E PIANO2 STR PIZZ HARPSCRD HARP MARIMBA STRINGS 2 Drum Standard Drums Rhythm List Rhythm name Number Rhythm name Number Electro Pop Ballad 8 Beat 1...

  • Page 29: Midi Keyboard Percussion Check List

    MIDI Keyboard Percussion Check List 3Electri note# note Ostand set 1Room set 2Power set 4Synth set Syn Sound Syn Sound Syn Sound Syn Sound Syn Sound Slap Slap Slap Slap Slap Scratch1 Scratch1 Scratch1 Slap Scratch1 Scratch2 Scratch2 Scratch2 Scratch2 Scratch2 Sticks Sticks...
  • Page 30 Snare 1 Low Tom2 Power Low Power Low Eleotry Low Synth Low Tom2 Tom2 Tom2 Tom2 Closed Hi-Hat Closed Hi-Hat Closed Hi-Hat Closed Hi-Hat Synth Closed Hi-Hat Low Tom1 Power Low Power Low Eleotry Low Synth Low Tom1 Tom1 Tom1 Tom1 Pedal Hi-Hat Low Tom1 Pedal Hi-Hat Pedal Hi-Hat Synth Pedal...
  • Page 31 Tambourine Tambourine Tambourine Tambourine Tambourine Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal Cowbell Cowbell Cowbell Cowbell Cowbell Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 High bomgo High bomgo High bomgo...
  • Page 32 Short Hi Short Hi Short Hi Short Hi Short Hi Whistle Whistle Whistle Whistle Whistle Long low Long low Long low Long low Long low whistle whistle whistle whistle whistle ShortGuiro ShortGuiro ShortGuiro ShortGuiro ShortGuiro logn Guiro logn Guiro logn Guiro logn Guiro logn Guiro Claves...

  • Page 33: Demo Song List

    Demo Song List Number Name Number Name Number Name Chopin Fi Love Romance Chopin No.6 Rock Four Cygnets Menuett Puppy Wlatz MarciaAT Fountain Bach Piano CpnEtude Chopin Night Minuet Bach Turkey March Piano Ballad Technical Specification Sound source: DSP sound source, grand piano sound sample Keyboard: Italian 88 Grand-Response Key trends with hammer action &...
  • Page 34 Sound Control: Grand piano tone, Dual voice, Double keyboard, Split mode, Split point. Dual voice: Dual voice can be set when playing. Keyboard Split: Double piano, Piano duet, String ensemble, Wind orchestra, It can make different setting. Volume control: Master volume, Accompany volume (0-32), adjustable volume control when playing at night.

  • Page 35: Trouble Shooting

    Trouble Shooting Trouble Possible Reason/Solution The digital piano will puff Don't worry. This is normal when it is switched on. Please confirm whether the master volume button is set Pressing key makes no properly or confirm whether the headphone jack is linked sound after the power is on to other devices, which will automatically cut off the built-in speaker system.
  • Page 36 The pitch doesn't match Maybe the double keyboard function or transposition function with key actual place is turned on. Turn off double keyboard or reset transposition while playing. to zero can solve the problem. The sound can not be Maybe the double keyboard function is turned on and the split changed while playing.
  • Page 37 Note: This device has been tested and is qualified with safety regulations of the state, EMC and other regulations. Radio communication may jam this device. On the other hand, this device may have effect on radio or television signal. Users should take one of the following or more methods to solve the problem.
  • Page 38 Ｐｒｅｓｅｎｔｅｄ　ｂｙ Ｇｕａｎｇｚｈｏｕ　ｐｅａｒｌ　Ｒｉｖｅｒ　Ｐｉａｎｏ　Ｇｒｏｕｐ　Ｃｏ．，Ｌｔｄ Ｍａｎｕｆａｃｔｕｒｅｄ　ｂｙ Ｇａｎｇｚｈｏｕ　Ｐｅａｒｌ　Ｒｉｖｅｒ　Ａｍａｓｏｎ　Ｄｉｇｉｔａｌ　Ｍｕｓｉｃａｌ　Ｉｎｓｔｒｕｍｅｎｔ　Ｃｏ．，Ｌｔｄ Ａｄｄ：Ｎｏ．３８．Ｘｉａｎｇｓｈａｎ　Ａｖｅ，Ｚｅｎｇｃｈｅｎｇ　Ｅｃｏｎｏｍｉｃ　ａｎｄ　Ｔｅｃｈｎｏｌｏｇｉｃａｌ　 Ｄｅｖｅｌｏｐｍｅｎｔ　Ｚｏｎｅ，Ｇｕａｎｇｚｈｏｕ　Ｃｈｉｎａ Ｔｅｌ：＋８６－２０－３６５７４６１８ Ｆａｘ：＋８６－２０－８１５０２６４９ Ｅｍａｉｌ：ｗｍｋ＠ｐｅａｒｌｒｉｖｅｒｐｉａｎｏ．ｃｏｍ Ｗｅｂｓｉｔｅ：ｈｔｔｐ：／／ｗｗｗ．ａｍａｓｏｎｍｕｓｉｃ．ｃｎ ２Ｂ０１０４４９...
