Summary of Contents for Atlas IED AL-MAGPIE
- Page 1 AL-MAGPIE Wireless Infrared Microphone 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 1 –...
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions ................3 Introduction ......................7 Features ........................ 7 Applications ......................7 AL-MAGPIE Wireless Microphone Description ............. 8 AL-MAGPIE-NEST Charging Station Description ..........10 Functions ......................11 Specifications ..................... 12 Warranty ......................14 1601 JACK MCKAY BLVD. -
Page 3: Important Safety Instructions
AL-MAGPIE Owner’s Manual Important Safety Instructions The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage “ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 4 AL-MAGPIE Owner’s Manual Important Safety Instructions 14. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 5 AL-MAGPIE Owner’s Manual WARNING - When The Device Is In Use • WARNING: For the terminals marked with symbol of may be of sufficient magnitude to constitute a risk of electric shock. The external wiring connected to the terminals requires installation by an instructed person or the used of ready-made leads or cords.
- Page 6 AL-MAGPIE Owner’s Manual • Do not modify, kink, or cut the power cord. Do not place the power cord in close proximity to heaters and do not place heavy objects on the power cord, including the product itself, doing so may result in fire or electrical shock.
-
Page 7: Introduction
AL-MAGPIE Owner’s Manual Introduction Congratulations and thank you for purchasing the AtlasIED AL-MAGPIE wireless infrared microphone. This innovative, professional grade microphone has been designed to include unique features and excellent performance that is required for delivering clear and concise audio through voice amplification. -
Page 8: Al-Magpie Wireless Microphone Description
Also referred to as “Student Mode” . 6. Power Button When the AL-MAGPIE is off, holding this button for 3 seconds will turn the unit on. When on, holding this button for 3 seconds will turn the unit off. - Page 9 AL-MAGPIE Owner’s Manual 8. Panic Button When both red buttons are pressed simultaneously, a VOLUME signal is sent to the AL2450 amplifier / receiver to close the “Panic” relay that sends a message to an external source, like a school’s paging system.
-
Page 10: Al-Magpie-Nest Charging Station Description
These LEDs indicate the current charging status of each receptacle: Red = Microphone is charging Green = Microphone is charged Note: The AL-MAGPIE must be charged for 12 hours before being used. VOLUME 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com... -
Page 11: Functions
AL-HSM headset. Each AL-MAGPIE has a switch located under the battery door used to set its IR Channel to either A or B. One AL-MAGPIE must be set to Channel A and the other AL-MAGPIE must be set to Channel B. The system will not function properly if there are two AL-MAGPIEs set to the same IR channel. -
Page 12: Specifications
1.15" x 1" x 3.8" (29mm x 25mm x 97mm) Weight with Battery 0.14lb (65g) Weight without Battery 0.08lb (36g) AL-MAGPIE-NEST Charging Station Specifications AL-MAGPIE Charging Ports Charge Indicator LEDs PSU Type 100VAC – 240VAC, 50/60Hz, 0.2A, 5VDC, 1A Dimensions 1.5 x 1"... - Page 13 AL-MAGPIE Owner’s Manual Notes 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 13 –...
-
Page 14: Warranty
AL-MAGPIE Owner’s Manual Limited Warranty All products manufactured by AtlasIED are warranted to the original dealer / installer, industrial or commercial purchaser to be free from defects in material and workmanship and to be in compliance with our published specifications, if any. This warranty shall extend from the date of purchase for a period of three years on all AtlasIED products, except as follows: one year on electronics and control systems;... - Page 15 AL-MAGPIE Owner’s Manual Limited Warranty (Continued) EXCEPT TO THE EXTENT THAT APPLICABLE LAW PREVENTS THE LIMITATION OF CONSEQUENTIAL DAMAGES FOR PERSONAL INJURY, ATLASIED SHALL NOT BE LIABLE IN TORT OR CONTRACT FOR ANY DIRECT, CONSEQUENTIAL OR INCIDENTAL LOSS OR DAMAGE ARISING OUT OF THE INSTALLATION, USE OR INABILITY TO USE THE PRODUCTS.
- Page 16 Service Should your AL-MAGPIE Wireless Infrared Microphone require service, please contact the AtlasIED warranty department through the online warranty claim process. Online Warranty Claim Processes Warranty submissions are accepted at: https://www.atlasied.com/warranty_statement where the type of return Warranty or Stock return can be selected.
