- Page 1 CONQUEST PB120LPG FLOOR SWEEPER OPERATOR MANUAL T: 1800 826 789 E: support@conquestequipment.com.au W: conquestequipment.com.au...
-
Page 2: Environmental Protection
Please read and comply with General notes ... . . EN Symbols in the operating these original instructions prior Environmental protection instructions to the initial operation of your appliance and Warranty . -
Page 3: Proper Use
Children should be supervised to pre- Proper use Safety instructions vent them from playing with the appli- Use this sweeper only as directed in these Safety instructions concerning the ance. operating instructions. CAUTION operation – This sweeper has been designed to Risk of damage! Do not sweep up straps, ... -
Page 4: Appliances With Combustion Engine
– First close the cylinder valve before – Close all cylinder and main valves be- Maintenance by expert loosening the pipe or tube connection. fore working in repair workshops and – Propellant-operated units are to be Unscrew and loosen the connection nut protect the gas cylinders against effect checked at regular intervals, at least of the gas cylinder slowly because oth-... - Page 5 Unloading tips Devices with overhead guard NOTICE DANGER The overhead guard (optional) protects the Risk of personal injury or damage! driver against larger falling objects. Howev- Observe the weight of the appliance er, it does not provide rollover protection! when you load it! ...
-
Page 6: Operating And Functional Elements
Operating and Functional Elements 7 Horn switch Illustration of sweeper Operating field 8 Fuses Illustration Illustration 9 Ignition lock 1 Nameplate 1 Roller brush and side brush control le- Position 0: Switch off engine 2 Seat (with seat contact switch) Position 1: Ignition on 3 Steering wheel Lever forwards: Switches the roller... -
Page 7: Before Startup
Indicator lamps and display Illustration 1 Operating hour counter 2 Charge warning lamp 3 Oil pressure warning lamp 4 Cooling water temperature warning lamp 5 Motor suction air 6 Warning light parking brake operated 7 Forward travel direction 8 Direction of travel reverse 9 Indicator light parking light/low beam 1 Gas cylinder (option) -
Page 8: Operation
Sit on the driver's seat. Driving over obstacles Inspection and maintenance work Lock parking brake (11). Driving over fixed obstacles which are 70 Daily before starting operations Push motor speed adjustment (10) 1/3 mm high or less: ... -
Page 9: Emptying Waste Container
Sweeping dry floors Transport DANGER Transport damage! Observe the net weight (transport weight) of the device during transport on trailers or vehicles. When transporting in vehicles, secure the appliance according to the guide- lines from slipping and tipping over. ... -
Page 10: Care And Maintenance
Check the pad for wear, replace if re- Care and maintenance Observe the directions on the quired. battery, in the instructions for Check the container lid and lubricate it. General notes use and in the vehicle operat- Maintenance following wear: ing instructions! ATTENTION ... - Page 11 Note Installing and connecting the battery The filling level has to be between Min. Normally, the machine is equipped with a and Max. maintenance-free battery. If necessary, refill DOT brake fluid cur- rently commercially available. Check engine oil level and top up, if required DANGER Risk of burns!
- Page 12 Check hydraulic unit Replacing roller brush NOTICE Maintenance of the hydraulic system is only to be carried out by ISAL Customer Service. Lock parking brake. Start the motor. Check all hydraulic hoses and connec- tions and ensure that they are leak- proof.
- Page 13 Screw in the holding plates. Check and adjust roller brush sweeping Repeat the procedure on the other side track of the appliance. Note: The sweeping track is factory-set to Manually clean the dust filter 80 mm; it is steplessly adjustable if the brush roller wears down.
- Page 14 Unscrew the wing nut from the centrifu- gal separator. Clean the centrifugal separator. Replacing fuses 1 Cross struts 2 Dust filter Check the dust filter, clean or replace if necessary. Note 1 Lock nut Exchanging the dust filter may only be 2 Cover fuse box done by the ISAL Customer Service.
-
Page 15: Troubleshooting
Troubleshooting Fault Remedy Appliance cannot be started Sit on the driver seat, the seat contact switch gets activated. Press the brake pedal in order to start the engine. Charging or replacing battery Gas bottle empty - replace gas bottle. Gas removal valve closed - open the valve by turning it in anti-clockwise direction. Gas valve iced - please read the description of the gas bottle replacement procedure. -
Page 16: Technical Specifications
Technical specifications 120 GPL Machine data Drive speed, forward km/h Drive speed, reverse km/h Climbing capability (max.) Surface cleaning performance without side brushes 8100 Surface output with side-brush 10800 Working width without side brushes Working width with side-brush 1200 Protection type, drip-proof IPX 3 Working time with a full gas bottle Engine... -
Page 17: Eu Declaration Of Conformity
120 GPL Solid rubber tyres Size, front 15-4.5x8 Size, rear 15-4.5x8 Brake Front wheels mechanical Rear wheel hydrostatic Filter and vacuum system Type Pocket filter Speed 1/min 2800 Filter surface area, fine dust filter Nominal vacuum, suction system mbar 15,5 Nominal volume flow, suction system Vibrator system Electric motor...
