PEDICURE SPA USERMANUAL
Before Operating the unit, please read this manual thoroughly and retain it for future reference
RECEIVING AND INSPECTION:
PLEASE TAKE NOTE! Thoroughly inspect each shipment immediately upon arrival. It is
important that you notify the driver and insist on a notation of the damage. Make
this notation directly on the freight company's waybill or bill of lading. Failure to note
damage on the waybill or bill of lading may impede and/or prevent any claims that
you may have against the freight carrier.
If missing parts or damage is found. Please notify the carrier at once and request an
inspection. DO NOT DISCARD THE SHIPPING BOX. If you give the carrier a clear
receipt for goods that have been damaged in transit, you do so at your own risk and
expense.
TRADEMARK DISCLAIMER
CADI, BELLO, CELIO, BENILLI, MARLO, PORADA, ELO, and LUXE is the registered trademarks of
Spatech, Inc. Reproduction or reuse of part or all of trademarks are expressly prohibited without
written permission from Spatech, Inc. Due to limitation of the printing process, product colors shown
might look different from actual colors. Spatech will not be responsible for any misprint of this
advertisement. Spatech's footspa specification and prices may change without prior notice.
Pedicure Spas are intended for professional used only, always follow your State Board's sanitation
and disinfectant guideline.
Advertisement
Related Manuals for Spatech CADI
Summary of Contents for Spatech CADI
- Page 1 Spatech, Inc. Due to limitation of the printing process, product colors shown might look different from actual colors. Spatech will not be responsible for any misprint of this advertisement. Spatech’s footspa specification and prices may change without prior notice.
-
Page 2: Safety Precautions
If a crack in the GLASS BOWL occurs, DO NOT handle unless the proper attire Warning and equipment is used. Discontinue use of the bowl until proper equipment is replaced. You may be held accountable for any injury that may occur. Spatech, Inc. is not liable for any injury that may occur. STATES’ NOTICE In the common wealth of most of the States, all pedicure spas shall be installed for Commercial usage in the states, are required to have backflow preventer. - Page 3 Connect drain with power drain (pump) or gravity drain (no pump) Using ¾” schedule 40 PVC (Power Drain) or 1 ¼” flex tube (Gravity Drain) and appropriate P- Traps connect drain to meet local plumbing codes. Rubber connection to the drain should be removable for easy service and should not be permanent to prevent damages.
- Page 4 Plumbing Flow Pattern for Gravity Drain: *** Extra 1 ¼” Flex-hose is supplied for fast connecting to underground 1 ½” connector Hot and cold water supply lines Before water line connections, please follow below: Determine if your spa chair is used for a new construction of a salon or a replacement spa chair.
- Page 8 Reduced Pressure Back Flow (RPBP) for each hot & cold water supply line. Please check with your local plumbing code requirements. Spatech recommends Watts 909 RPBP for each main supply line (see figure 2). Installation must be done by a licensed plumber, and installation...
- Page 9 Connect drain with power drain (pump) or gravity drain (no pump) Using ¾” schedule 40 PVC (Power Drain) or 1 ¼” flex tube (Gravity Drain) and appropriate P- Traps connect drain to meet local plumbing codes. Rubber connection to the drain should be removable for easy service and should not be permanent to prevent damages.
-
Page 11: Electrical And Pedicure Spa Component Specifications
Power needed per spa chair = 6 Amp 2 Air Switches For control, turn Whirlpool Jet and Drain Plug & Play Installation Installation should be made with connection at the external interface parts. Please consult with your local plumber Safety Spatech® is UL listed. - Page 12 In-line Check Valve. Complied with ASME A112.18.3M & IAPMO CERTIFIED FILE# 4374 SPATECH A112.18.3M BACK FLOW PREVENTER External o-ring seal provides sealing between the Exlernol seal check valve cartridge and the mating cavity into EPDM which it is inserted. Housing...
-
Page 13: Operation And Care Instructions
OPERATION AND CARE INSTRUCTIONS Manual Operation (For Non-Auto-Fill / Drain Models): Filling Close the Drain Stopper by turning the Drain Knob counterclockwise. Utilizing the single lever hot/ cold mixer faucet located on the front of the Pedicure Spa, fill the tub to the water level above the whirlpool jet at least 1 inch. - Page 14 WHIRPOOL JET INSTALLATION NOTE: 1. To avoid water leakage, it is essential to align lips from electric motor perfectly with slots on housing. 2. When installing motor, first apply moderate pressure to motor to engage motor lips (4) with housing slots (4), then twist motor counterclockwise until secured.
- Page 15 IDENTIFYING SPATECH’S PEDICURE SPA PARTS 1. Pillow Head Rest 2. Main PVC Board 3. Massage System 4. Electrical Outlet Box 5. Hot Water Hose ½ 6. Cold Water Hose ½ 7. Check Valve ¾ inch 8. PVC Pipe ¾ 9. Drain Pump 10.
-
Page 16: Massage System & Remote Controller
MASSAGE SYSTEM & REMOTE CONTROLLER: Press Auto Button to start Auto mode. Press again to turn off massage. Auto and Manual mode will run for duration of 20mins. 2. Press any button (Rolling/Spot, Kneading, Tapping, and Combine) to enter Manual mode. 3.
