Direction 2233080, Rev 3
2-4 INSTALLING THE NEW MOD DRIVE (CONTINUED)
The SCSI device ID is set with jumpers on the jumper block (J7), pins 1 to 6 (refer to Illustration 2-5). See the
table below.
SIGNAL
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
TERMPWR
TERMPWR
AC Eject
PwrDnReq
AC Error
AC Reset
GROUND

Table 2-2: MaxOptix T5-2600P Jumper Block Pin Assignments

SCSI ID PIN 1-2
OUT
0
IN
1
OUT
2
IN
3
OUT
4
IN
5
OUT
6
IN
7

Table 2-1: SCSI Device ID Jumper Settings

PIN NUMBER
1 2 SCSI ID Bit 0
3 4 SCSI ID Bit 1
5 6 SCSI ID Bit 2
7 8 DEC
9 10 Disable Auto Spin Up *
11 12 Disable SCSI Bus Parity *
13 14 Enable Apple® Macintosh™ Mode **
15 16 Disable Removable Media Report *
17 18 Disable Optical Device Type Report *
19 20 Enable ECC Verify after Write **
21 22 Disable Write Cache *
23 24 Disable Read Cache *
25 26 Enable Active Termination **
27 28 Enable Internal Term Power Supply **
29 30 Enable External Term Power Supply **
31 32 LED Pipe
33 34 PwrDnAck
35 36 Cart_in_Drive
37 38 Cart_Loaded
39 40 Stand Alone/AC
*Install Jumper to Disable
High Capacity MOD Option Installation Manual
PIN 3-4 PIN 5-6
OUT OUT
OUT OUT
IN OUT
IN OUT
OUT IN
OUT IN
IN IN
IN IN
SIGNAL NAME
TM TM
MicroVAX Mode**
**Install Jumper to Enable
13
SETTING
Installed
Installed
Removed
Removed
Removed
Removed
Removed
Removed
Removed
Removed
Removed
Removed
Removed
Installed
Installed
Removed
Removed
Removed
Removed
Removed
