Rockwell Automation IP 65 Instructions

Installing the Gasket
IP 65 (NEMA Type 4) Enclosure
Gasket Installation
This publication will guide you through the steps needed to install a
gasket on IP 65 (NEMA Type 4) enclosures. Installation of the gasket
allows additional protection for your enclosure. Two kits are available
for the following:
• A1-A3 Frame Enclosures
• A4-B1 Frame Enclosures
Each kit consists of three (3) gasket sections.
ATTENTION: To avoid a shock hazard, assure that all
!
power to the drive has been removed before proceeding.
Refer to Figure 1 for component identification and locations.
1. Remove and lock-out all incoming power to the drive.
2. Remove the enclosure door by pulling the two (2) hinge pins out.
3. Locate the Top Gasket and check for proper fit. The gasket should
rest against the top enclosure flange and the gasket tab should
touch the left enclosure flange. Remove the protective backing
from the gasket and press in place.
4. Locate the Right Gasket. Check for proper fit by placing the
gasket against the right enclosure flange. The top edge will meet
with the Top Gasket. Remove the protective backing from the
gasket and press in place.
5. Locate the Bottom Gasket and check for proper fit. The right end
of the gasket should touch the Right Gasket. The top of the gasket
must rest against the enclosure flange. Remove the protective
backing from the gasket and press in place.
6. Replace enclosure door - installation is complete.
