TS-KS-W1019-0
To:
Specification Document
Water Leakage Detector
AD–AS–1CM
(RoHS-directive-compatible)
Date：(
)
<Manufacturer >
System Equipment Division
Electronic Materials & System Equipment Group
TATSUTA Electric Wire & Cable Co., Ltd.
System Equipment Division
Approved by:
Checked by:
Prepared by:
Advertisement
Related Manuals for Tatsuta Electric Wire & Cable AD–AS–1CM
Summary of Contents for Tatsuta Electric Wire & Cable AD–AS–1CM
- Page 1 TS-KS-W1019-0 Specification Document Water Leakage Detector AD–AS–1CM (RoHS-directive-compatible) Date：( <Manufacturer > System Equipment Division Electronic Materials & System Equipment Group TATSUTA Electric Wire & Cable Co., Ltd. System Equipment Division Approved by: Checked by: Prepared by:...
- Page 2 <<<Important safety instructions>>> Warning Erroneous operation of this water leakage detector not complying with the warning labels or the following warnings may lead to fatal accident, serious injury, electric shock, fire, or detector failure. Warnings Strict Prohibitions Never modify or disassemble the detector. ...
-
Page 3: Table Of Contents
Table of contents Page 1. Scope of application ...................... 1 2. Construction ........................ 1 3. Specifications ......................2 4. External Connection ....................2 4–1 Connection of power supply and sensor ............... 2 4–2 Connection of non-voltage output ................. 2 5. Movement chart ......................3 ... -
Page 4: Scope Of Application
Page;1 1. Scope of application This specifications covers Water leakage detector AD-AS-1CM that was developed to incorporate in some equipment. 2.Construction ○ ○ ○ ○ 100V ○ ・IJ ・WPC＆ ○ ○ 200V ○ SENSOR ○ SENSOR ○ P ：Power(AC100/200V 50/60Hz) RC ：Rectifier Circuit F ：Fuse OPC：Output Circuit... -
Page 5: Specifications
Page;2 3.Specifications Item Specification Power supply AC100V or AC200V Frequency 50/60Hz Power consumption Not more than 2VA Non-voltage output terminal AC125V 0.3A contact capacity DC 30V 1.0A Non-voltage output terminal 1c(COM-NO,COM-NC) construction 1a(COM-NO) Voltage across sensor AC5V Ambient temperature - 10～50 (Don’t freeze.) Ambient humidity 35～85%RH(There must be no dew condensations.) Number of sensor circuit... -
Page 6: Movement Chart
Page;3 5.Movement Chart POWER ON Water detect Recover POWER LED(Red) ↓ ↓ ↓ (Lighting) Water-leakage Alarm LED(Red) (Flicker) Non-voltage contact output... - Page 7 Attached Fig.1 付図 －１ Ｎｏ． 40506030 Sensitivity setting switch ADAS1CM 200V 100V 2-Installation hole φ5.5 Approved Checked Drawn Scale 名 ＡＤ－ＡＳ－１ＣＭ Unit Outward Form size 称 Drawn 2007.7 図 ＴＴＳ－ＫＳ－Ｗ３１３１－１ TATSUTA Electric Wire & Cable Co., Ltd. 番...
