Pentair Pool Products INTELLITOUCH Instructions

INTRODUCTION

The Service Panel may be used to make updates to an installed IntelliTouch system at the control
pad without the need to access the indoor control panel.
To perform this service properly these instructions must be followed exactly. Be sure to read
and understand all instructions before performing any work on the job-site. Not following these
instructions can lead to incorrect system configuration, wasted time and effort due to multiple
job-site visits, confusing operation by the customer.

EQUIPMENT

The service panel consists of a specialized indoor control panel. Emerging from the back of the
unit is a four conductor cable pre-wired for attachment to the IntelliTouch system.
This unit is NOT weather protected. Do NOT put unit in water or allow it to get wet.
Do NOT leave unit in direct sunlight. If screen goes dark, do NOT attempt to adjust the contrast.
Allow screen to cool until contrast returns to normal.
Be sure interface cable is plugged in with correct orientation. Wires should NOT be hanging off
the edge of the PCB. They should be oriented to pass over the PCB.
Take care not to damage the connector leads. Do NOT disconnect or change the order of any
conductors of the interface cable.
The unit will receive power from the system when it is plugged in.
Pentair Water Pool and Spa, Inc.
1620 Hawkins Ave., Sanford, NC 27330 • (919) 566-8000
10951 West Los Angeles Ave., Moorpark, CA 93021 • (805) 523-2400
Visit us on the Internet at: www.pentairpool.com
PN: 520397 Rev. B
INTELLITOUCH
SERVICE PANEL INSTRUCTIONS
®
