  • Page 1 WD50 Installation Guide Operating Instructions Warranty...

  • Page 2: Table Of Contents

    Product warranty Information in this installation guide may be subject to change without notice. Please ensure you have the current version before beginning installation. If you have any queries, please contact ‘The Fire Dept.’ on 0800 888 550 Version: April 2021...

  • Page 3: Step 1: Unpack And Ensure All Components Are Correct And Undamaged

    Flue kit. • Pizza paddle. • Baffle hook. • WD50 technical specifications (to be read in conjunction with this installation guide). • BBQ Grill/Hotplate (optional). • Heat barrier (optional – required for installation onto combustible surface). • Tread plate aluminium hearth (optional – required for installation onto combustible surface).

  • Page 4: Step 2: Pre-Installation Checklist

    Step 2: Pre-installation checklist • Ensure clearances are correct – refer to technical specifications. • Ensure hearth dimensions are correct – refer to technical specifications. • Plan flue path. • Ensure the base is strong enough to support the fireplace. The starting point.

  • Page 5: Step 3A: Crane Fireplace Into Position

    Step 3A: Crane fireplace into position The best installation option is to crane the fully assembled fireplace into position. If this is not possible, follow the instructions in step 3B. Important Safety Note: It is the installer’s responsibility to ensure that the crane, operator and equipment are suitably certified to lift the fireplace.

  • Page 6: Step 3B: Disassemble Then Reassemble Fireplace Into Position

    Step 3B: Disassemble then reassemble fireplace into position If the fireplace cannot be craned into position, it needs to be disassembled then reassembled into position. Important Safety Note: It may be necessary to manually handle heavy components (greater than 25kg). It is the installer’s responsibility to ensure appropriate manual-handling techniques are employed.
  • Page 7 3. Remove the top panel (11 x 5mm 4. Remove the rear top panel and then the countersunk cap screws). Rear lower panel (4 x 5mm countersunk cap screws each panel). Lift Support 5. Lift from under the firebox until the side panels are free from the ground and support the fire.
  • Page 8 5mm fixing nuts and bolts 10mm fixing bolts 6. Remove the bolts that hold the side panels to the fire 7. Remove the nuts and bolts that hold the side panels to box (3 x 10mm bolts at each side of the firebox). the front top panel.
  • Page 9 11. Fix the gather (with the front top panel 10. Carry the firebox into position. Requires 4 x people one at each corner. attached) to the firebox (2 x 10mm bolts at each side of the firebox). Requires 4 x Caution: Take care not to jamb fingers when lifting or people one at each corner.
  • Page 10 10mm fixing bolts 14. Replace the bolts that hold the side panels to the fire 15. Remove the supports and lower the firebox until box (3 x 10mm bolts at each side of the firebox). its level and the side panels are on the ground and in position.
  • Page 11 NOTE: Loosely fit all the cap crews before NOTE: Loosely fit all the cap crews before tightening. tightening. This link will take you to our YouTube video where we explain how to install the WD50 Version: April 2021...

  • Page 12: Step 4: Fix Fireplace Into Position

    Step 4: Fix fireplace into position 1. Fix the fireplace into position • Position the fireplace and ensure that it complies with the minimum clearances required (100mm on all sides) to the surrounding enclosure. • In order to provide maximum positioning flexibility, the base has two 30mm long slots in each side panel.

  • Page 13: Step 5: Fit Hearth (Optional)

    Step 5: Fit hearth (optional) Heat barrier and hearth will be required if the fireplace is positioned onto combustible materials. 1. Fix the heat barrier supporting slips into 2. Fix heat barrier panel on top of supporting position in accordance with technical slips in accordance with technical specifications.

  • Page 14: Step 6: Fit Flue

    Step 6: Fit flue Note: A safe working platform is required to fit the flue. Each flue joint must have a minimum of 4 x stainless steel rivets.
 1065 mm 1. Run the 2 x flues. The crimped end 2. Run the first casing. The 3.

  • Page 15: Step 7: Fit Oven Tile, Door, Fire Bricks And Grate

    Step 7: Fit oven tile, door, fire bricks and grate Oven tile Door Fire bricks Grate Replace the fire bricks. Refer to the photo you took earlier for the correct set-up. Fit the oven tile. Fit the door by reversing the door removal process described earlier. Place the grate in the centre of the fire cavity.

  • Page 16: Step 8: How To Operate Fireplace

    Step 8: How to operate fireplace • Following the Operating Instructions on the next page, show the owner how to operate the baffle. • If the owner is not available, leave this manual by the fireplace. Version: April 2021...

  • Page 17: Operating Instructions

    OPERATING INSTRUCTIONS The WD50 has an integrated baffle, which controls the amount of heat and smoke that enters the cooking area. Baffle Hook Pizza Paddle Push baffle back to allow heat and smoke to Pull the baffle forwards to stop/adjust heat enter the cooking area.

  • Page 18: Product Warranty

    5 (five) years. Beyond normal heat-induced staining, tarnishing and mild warping , if a firebox, outer skin or support frame defect occurs, contact ‘The Fire Dept.’ and the defect will be repaired or replaced at our discretion with all costs covered.
