- Page 1 GD14 Installation Guide Operating Instructions Warranty...
-
Page 2: Table Of Contents
Under no circumstances should any combustibles such as paper, wood or coal be used in this appliance. It is recommended that you have this appliance serviced annually by a qualified technician. Warranty repairs must be carried out by a ‘The Fire Dept.’ authorised technician. This appliance must ALWAYS terminate/flue outdoors. -
Page 3: Step 1: Unpack And Ensure All Components Are Correct And Undamaged
Step 1: Unpack and ensure all components are correct and undamaged • Brazier • Box of firebed mediums Step 2: Install plinth (if required) • If the appliance is to sit on a plinth, ensure it is capable of supporting a 250kg load. •... -
Page 4: Burner Removal Process
Burner Removal Process Burner removal • Remove the 4 x screws. • The pilot end of the burner aligns with the seam in the outer brazier panel. • Remove the burner and place in a suitable location to avoid damage. Version: August 2020... -
Page 5: Burner Installation Process
Burner Installation Process Burner installation • Lower the burner into the Brazier. GD14 700 & 1000 • Take care not to bend the gas supply pipe Input 50- 65 MJ/h Four gas injectors at the end of each burner tube (both LPG and NG) •... -
Page 6: Weather Housing
Weather Housing • The gas supply pipe will need to be run into the weather housing under the burner, as this is where the copper tube with the gas supply connects to the GD14 burner. • The electrical supply cable will need to be run into the weather housing (must be a minimum of 1.0mm 4 core cable), ensure 1000mm of cable is at the centre of the cavity, as this is where it will connect to the GD14 burner. - Page 7 • Fix appliance into position and ensure that it complies with the minimum clearances required to the surrounding enclosure. The exception to these minimum clearances is the base panels of the appliance, the base can safely sit directly upon combustible (e.g. timber) and non-combustible (e.g. concrete) materials, refer to the appropriate appliance specification for the correct clearance requirements.
-
Page 8: Step 4: Connect And Test Electrical Supply
Step 4: Connect and test electrical supply • All electrical connections must meet the requirements of AS/NZS 3000 standards and be installed and certified by a suitably qualified person. • In order to access the electricals, it is necessary to first remove the burner and weather housing cover. •... - Page 9 Version: August 2020...
-
Page 10: Step 5: Connect Gas Supply And Commission
• In the unlikely event that the rating plate is not attached, Do Not commission the appliance and contact The Fire Dept immediately. • Switch the appliance OFF. • Install the burner and weather housing cover by following the ‘Burner Removal Process’ and ‘Weather Housing’... -
Page 11: Step 6: Lay The Firebed
Step 6: Lay the firebed • The GD14 has one firebed option: Forest Logs. • Particular care should be taken when placing the firebed mediums onto the burner tubes. Failure to place the medium correctly may result in the appliance performing inefficiently. •... -
Page 12: How To Lay Forest Logs Firebed - Gd14
How to lay Forest Logs Firebed - GD14 700 • Lay logs and rocks first, in these positions. 2. Pilot side 1. Pilot side 4. Pilot side 3. Pilot side 5. Non-Pilot side Version: August 2020... - Page 13 Switch the appliance ON at ‘HIGH’ setting to check how flame looks. The flame will take 10-30 seconds to • light fully. • IMPORTANT: The flame effect should look natural and non-uniform, running the around each of the logs. • Common flame effect issues are: •...
- Page 14 How to lay Forest Logs Firebed - GD14 1000 • Lay logs and rocks first, in these positions. 7. Pilot side 6. Pilot side 9. Pilot side 8. Pilot side Non-Pilot side Version: August 2020...
- Page 15 Switch the appliance ON at ‘HIGH’ setting to check how flame looks. The flame will take 10-30 seconds to • light fully. • IMPORTANT: The flame effect should look natural and non-uniform, running the around each of the logs. • Common flame effect issues are: •...
-
Page 16: Step 7: Show Owner How To Operate Appliance
Step 7: Show owner how to operate appliance Following the GD14 Operating Instructions on the next page, show the owner how to switch the appliance • ON and OFF, and how to switch between HIGH and LOW settings. • If the owner is not available, leave this manual by the appliance. NOTES: Version: August 2020... -
Page 17: Gd14 Operating Instructions
GD14 OPERATING INSTRUCTIONS The GD14 appliance has been designed to be simple to use. It is controlled by a wall switch, which must be installed by a qualified electrician To start appliance: • Press the On/Off switch to the ON position. •... -
Page 18: Product Warranty
(G) The product contains fire bricks and has not been subjected to the recommended first start-up and run-in procedure. (H) Used in conjunction with any equipment or parts or as part of a system not manufactured or supplied by ‘The Fire Dept.’.
