SmartFOAM
Electronic Foam Proportioning Systems
Models:
Class A only – 1.7AHP, 2.1A
Class A/B – 3.3, 5.0, 6.5
FOAM SETUP
GUIDE
FSG-MNL-00177
HALE PRODUCTS, INC / CLASS 1
607 NW 27th Avenue ● Ocala, FL 34475
U.S.A. Telephone: 352-629-5020
FAX: 800-533-3569
GODIVA LTD.
Charles Street ● Warwick, England CV34 5LR
Phone: 44-1-926-623600
Advertisement
Related Manuals for Godiva Hale SmartFOAM 1.7AHP
Summary of Contents for Godiva Hale SmartFOAM 1.7AHP
- Page 1 Class A/B – 3.3, 5.0, 6.5 FOAM SETUP GUIDE FSG-MNL-00177 HALE PRODUCTS, INC / CLASS 1 607 NW 27th Avenue ● Ocala, FL 34475 U.S.A. Telephone: 352-629-5020 FAX: 800-533-3569 GODIVA LTD. Charles Street ● Warwick, England CV34 5LR Phone: 44-1-926-623600...
-
Page 2: Apparatus Information
SmartFOAM Page 1 APPARATUS INFORMATION Hale SmartFOAM System Serial Number In Service Date Fire Department Engine Number Calibration Factors: Water Flow – high calibration point Water flow Pulses Water flow Pulses Water Flow – low calibration point Class A Foam Factor NOTICE! Hale Products does not assume responsibility for product failure resulting from improper maintenance or operation. - Page 3 SmartFOAM Page 2 NOTES...
- Page 4 SmartFOAM Page 3 operate the system when these guards are SAFETY removed. ❑ Make sure all access/service panels and covers are installed, closed and latched tight, where IMPORTANT! applicable. ❑ DO NOT remove or alter any hydraulic or pneumatic connections, electrical devices, etc. THE HALE SMARTFOAM MODELS 2.1A AND DO NOT tamper with or disconnect safety 1.7AHP CLASS “A”...
- Page 5 SmartFOAM Page 4 ❑ ❑ Do not operate system at pressures higher than the Always position the check valve/injector fitting at maximum rated pressure. a horizontal or higher angle to allow water to drain away from the fitting. This avoids the ❑...
-
Page 6: Initial System Check
SmartFOAM Page 5 SYSTEM INSTALLER START-UP On initial power-up of the Hale SmartFOAM system at the installer facility, the following procedures must be followed. INITIAL SYSTEM POWER CHECK Watch the display on the controller unit as the apparatus electrical system is turned ON. Check the controller unit readout for: ❑... - Page 7 SmartFOAM Page 6 Upon initial power-up with the foam tanks empty, the display on the controller unit will display a warning bar indicating that the foam tank is low. Figure 2: Low Foam Tank Warning 1. Fill the foam concentrate tank with WATER. The “low foam tank”...
- Page 8 SmartFOAM Page 7 Figure 4: SmartFOAM Buttons and Indicators 4. Set the foam injection rate to 1.0% by pressing the INCR or DECR arrow buttons. 5. Press the ON/OFF button to energize the Hale SmartFOAM system. a. The Pump Speed bar graph will increase to indicate the motor is running.
- Page 9 SmartFOAM Page 8 System Setup: Enter the OEM screen 1. Press the MENU button to go to the system menu. 2. Press the Calibration/Configuration button on the system menu screen. 3. Use the touch screen keypad to enter the password 2314. a.
- Page 10 SmartFOAM Page 9 1. Use the touch screen keypad to enter the password 2314. a. Press the “Enter” touch screen button to submit the password. b. Press the “Delete last digit” touch screen button to erase the last digit entered. c.
- Page 11 SmartFOAM Page 10 The preset and operation screens: The SmartFOAM controller will show the PRESET screen after a power cycle. This allows the user to select a preset with which to start operation. Pressing a preset button will automatically change the view to the OPERATION screen. The OPERATION screen shows the operational information for the foam system including the buttons and indicators used to control the system.
- Page 12 SmartFOAM Page 11 To place the system in simulated flow mode: 1. Press the MENU button. 2. In the menu select the “simulated water flow” button. 3. In the simulated water flow screen press the ON/OFF button to toggle simulated water flow. The icon indicates the current state.
- Page 13 SmartFOAM Page 12 Foam calibration: Enter the foam calibration screen 3. Press the MENU button to go to the system menu. 4. Press the Calibration/Configuration button on the system menu screen. 5. Use the touch screen keypad to enter the password 1560.
-
Page 14: Installation
SmartFOAM Page 13 INSTALLATION AND DELIVERY CHECKLIST After the Hale SmartFOAM system is installed, use the following check list to verify installation and ensure proper system setup when the apparatus is delivered to the end user. INSTALLATION Date Initials Checklist item ❑... - Page 15 SmartFOAM Page 14 SmartFOAM passwords Menus 1849 - User menu 2314 - OEM menu 57643 - Factory menu Set-up 1023 - Preset configuration 6679 - Water calibration (primary paddlewheel) 9766 - Direct water calibration (primary paddlewheel) 6681 - Water calibration (secondary paddlewheel) 1866 - Direct water calibration (secondary paddlewheel) 1560...
