Specification
Electrical Specification
a. Power Consumption: (Include Inverter and LCD Panel)
Operation mode
Power Consumption : 32'' 150 Watt(Max)
Audio AMP : 9 +/-1Watt (Reference : Speaker 9W×2)
Power Saving mode (STB) : ≦1 Watt
b. Power Supply
Input for Main board : +12/5Vdc
Output for LCD Panel :32'' 12Vdc
c. Environment
Operation Temperature : 0° ~ 45°
Storage Temperature : -20° ~ 70°
Operation Humidity : 0%~80% (non-Condensing)
Storage Humidity : 0%~90%
d. Output Data Type
LDVS mode : 8bit data output.(single LVDS output)
e. Input Refresh Rates :
Power Board Specification
a. AC Input Requirements
Normal Voltage : 100 to 240 Vrms
Voltage Range : 90 to 264 Vrms
b. Frequency
Normal Frequency : 50 to 60 Hz
Frequency Range : 45 to 65 Hz
NO.
9,10
6,7
4,5,8,11,12
1
2,3
NO.
1,2
3
4
5,6
Sep. 30th, 2010 (Version 1.3)
fH: 30~60KHz, fV: 60~75Hz
Pin-CON15 Connection to main board
PIN Connection
+12V
+5V
GND
ON/OFF
+5VSB
Pin-CON3 for inverter PUB
PIN Connection
GND
ADJ
ON/OFF
+12 (out put)
Function
For tuner power and amp
For scaler power and decoder power
+12/5Vdc return
Work / standby mode （H working, L standby）
MCU +5V, in standby power
Function
For tuner power and amp
Adjuct backlight
Cut on/off panel backlight
For inverter power
