Bledsoe JET Application Instructions page 2

2
1.
Unfasten Straps:
Open the 4 straps on the back
side by pulling the strap tabs
through the D-Ring. Then
loosen the front strap.
2.
Positioning the Brace:
While seated with the knee
slightly bent, place the brace on
the leg, and line up the center
of the hinge slightly above the
middle of the kneecap.
3a
3b
3.
Securing the Brace:
a. Upper Calf Strap: Wrap the strap around the top part of the calf Insert the end of the strap through
the D-ring. Pull the tab until a snug and comfortable t is achieved.
b. Lower Calf strap: Follow the same instructions in step 3a to fasten the lower calf strap.
c. Back Thigh Straps: Follow the same instructions in step 3a to fasten the back thigh straps.
d. Adjust Front Tibia Strap: Tighten the front strap until it is snug but comfortable. Over-tightening will
cause the hinges to pull forward past the midline of the leg.
JE T
APPLICATION INSTRUCTIONS
3c
4a
4b
3d
4c
Adjusted
strap
4.
To Adjust Strap Length:
a. Remove the strap pad.
b. Undo the straps and
adjust the length of each
by using the hook and pile
fastener.
c. When nished adjusting
the strap's length, replace
and center the strap pad.
Excess strap length can be
cut with scissors.
