RF INTERLINK BASEPLATE.
FOR LIFESAVER 5800 SERIES
SMOKE ALARMS.
MODEL LIFWMB2
The PSA LIFESAVER LIFWMB2 is a smoke alarm
baseplate with built in RF interlink module.
Installed on a LIFESAVER 5800 Series mains powered
smoke alarm, it is capable of wirelessly interlinking
with other LIFESAVER 5800 series smoke alarms.
When one smoke alarm sounds, it will activate other
smoke alarms in the same RF interlink network.
The PSA LIFESAVER LIFWMB2 RF interlink protocol is
compatible with the LIFESAVER LIF10YPEW battery
operated smoke alarm with wireless interlink.
FEATURES:
• RF baseplate to interlink LIFESAVER 5800 series
smoke alarms wirelessly, Gen 2.
• When a smoke alarm triggers, it activates
other smoke alarms wirelessly in the network
• Wirelessly interlink up to 24 units
• Fully monitored and supervised wireless network
• Approved and Certified to AS/NZS4268:2017
• Compatible with LIFESAVER 10 year wireless
smoke alarm LIF10YPEW
*Refer to Installation and User Manual for further information and programming.
Due to PSA commitment to continual product improvement, specification may change without notice.
F I R E • S E C U R I T Y
1300 772 776 enquiry@psaproducts.com.au
psaproducts.com.au
SPECIFICATIONS
ACCESSORIES
• I N T E R C O M S
Model
Operation interconnect up to 24 units
Power
RF Frequency
RF Range
Temperature Range
Humidity Range Up to 95% relative humidity (RH)
Warranty 5 years - manufacturer's warranty
Compliance
Manufactured to ISO9001 Standard
Smoke Alarm 240VAC with 9V
LIF5800/2
battery backup. Photoelectric.
Smoke Alarm 240VAC with lithium
LIF5800RL/2
battery backup. Photoelectric.
Smoke Alarm 10 Year battery operated
LIF10YPEW
with RF interlink. Photoelectric.
LIFWMB2
From smoke alarm
918MHz
100m line of sight
30m indoors
0˚C to 45˚C
AS/NZS 4268:2017
AS/NZS 60950.1:2015
RCM.
