Before installing this option, a TECHNICALLY QUALIFIED INDIVIDUAL, who is familiar with this type of
equipment and hazards involved, should READ this ENTIRE INSTRUCTION SHEET.
DESCRIPTION
The RS-232C/485 Interface Card CM086 (Figure 1) is mounted on the Control Board of the GPD 505 to
input/output various signals from external devices by means of RS-485 serial communication.
RECEIVING
All equipment is tested against defect at the factory. Report any damages or shortages evident when the
equipment is received to the commercial carrier who transported the equipment.
INSTALLATION AND WIRING
Hazardous voltage can cause severe injury or death. Lock all power sources feeding
Drive in "OFF" position.
1.
Disconnect all electrical power to Drive.
2.
Remove Drive front cover. Check that "CHARGE" indicator lamp inside Drive is off.
3.
Verify voltage has been disconnected by using a voltmeter to check for voltage at incoming power terminals
(L1, L2, L3).
The option card uses CMOS IC chips. If proper electrostatic discharge (ESD)
protective procedure is not used when handling the card, the ICs may be damaged,
resulting in erratic performance of the drive.
4.
Refer to Figure 2. Position the option card on four mounting spacers on the Control Board of the Drive.
Gently press the card into place until its four mounting holes click into place on the the spacers.
5.
Plug the 2CN cable from the option card into connector 2CN of the Control Board.
6.
Connect the grounding lead wire from the CM086 card to the grounding terminal on the Control Board.
CHANGE RECORD
Integral Mounting Option
RS-232C/485 Interface Card
Model No. CM086
WARNING
CAUTION
For GPD 505 Adjustable
Frequency Drives
DWG. NO. 02Y00025-0409
SHEET NO. 1 OF 5
REL. 03/22/96
( m - df )
Advertisement
Related Manuals for YASKAWA CM086
Summary of Contents for YASKAWA CM086
- Page 1 READ this ENTIRE INSTRUCTION SHEET. DESCRIPTION The RS-232C/485 Interface Card CM086 (Figure 1) is mounted on the Control Board of the GPD 505 to input/output various signals from external devices by means of RS-485 serial communication.
- Page 2 E (G) on Control Board) Terminal TC2 Terminal (for connecting selecting termination block TC1 shielded sheath) resistor, R11) Figure 1. RS-232C/485 Interface Card CM086 Table 1. Terminal Functions of CM086 Terminal Block Functions Symbol S/R (+) RS-485 input/output (+) Output to host device or to S/R (–)
- Page 3 Figure 2. Installation of the RS-232C/RS-485 Interface Card CM086 Wiring. Refer to Figure 3 and Tables 1 & 2. Make wire connections between the CM086 card and the external (host) device with which the Drive will be communicating, using shielded twisted pair wire. If multiple Drives (with RS-485 Interface cards) are to be connected to the same external device, they must be connected in series –...
- Page 4 PROPER SETTING OF SWITCH S1. CONTROL CM086 OPTION CARD S/R(+) S/R(–) Termination resistor SHIELD Figure 3. CM086 Interconnection Diagram DWG. NO. 02Y00025-0409 SHEET NO. 4 OF 5 REL. 03/22/96 ( m - df ) Refer to Sheet 1 for latest change.
- Page 5 Adjustments. If only one Drive is connected to the external device, switch S1 on the CM086 card in the Drive should be set to the "ON" position to insert termination resistor R11 on the card between the RS-485 (+) and (–) lines. If multiple Drives are connected to the same external device, S1 must be set to the "OFF" position in all but the LAST Drive in the daisy-chain, in that drive only, S1 should be set to "ON".
