Table 7.2 – SMB-00 Parts List
Piece
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
34
35
36
37
38
39
41
42
43
44
46
51
56
57
59
63
64
65
SMB/SB Installation and Maintenance Manual
Quantity Description
1 Housing
1 Limit Switch Compartment Cover
1 Spring Cartridge Cap
1 Drive Sleeve
1 Declutch Lever
1 Declutch Fork
1 Worm Gear
1 Stem Nut
1 Tripper Lever
1 Locknut
1 Geared Limit Drive Hypoid Gear
1 Tripper Adjustment Arm Pin
1 Clutch Key
1 Clutch Fork Roller
1 Clutch Roller Pin
1 Worm Shaft
1 Worm Shaft Gear
1 Worm
1 Motor Pinion
1 Tripper Adjustment Arm
1 Seal Retainer Plate
1 Terminal Bracket
1 Tripper Cam
1 Spring Cartridge Cap Cover
1 Tripper #1
1 Tripper #2
1 Clutch Ring
1 Worm Gear Spacer
1 Locknut
1 Bearing Spacer
1 Torque Limit Sleeve
1 Declutch Shaft
1 Worm Shaft Bearing Cap
1 Cam Spacer
1 Bearing Cartridge
1 Thrust Washer
1 Thrust Washer
1 Tripper Lever Spacer
1 Dowel Pin
1 Clutch Compression Spring
1 Tripper Spring
1 Belleville Springs
1 Bearing Shims
1 Spring Cartridge Cap Gasket
1 Limit Switch Compartment Cover Gasket
1 Motor Adapter Gasket
1 Roller Bearing Cup
1 Upper Roller Bearing Cone
1 Roller Bearing Cup
