- Page 1 Instructions for assembly and HYBRID ELIPSE SERIES Hybrid E Tisa Konstruktion HB Edition 1.2020 SF...
- Page 2 Dear customer, TISA Konstruktion only offer high quality products with pleasing design and reliable operation, For us, safety and high manufacturing standards are the most important and we ensure a long life product with high efficiency and good heating economy. Even the best stoves require good handling and regulare care, based on information and know-how.
- Page 3 CONTENS General............pages 4-5 -manufacturer s assurance-planning application -Planning application -guarantee -chimney -distance from combustible surfaces -load-bearing structure -fireplace base -what is included -envirinmental approval -transport ap attachments -receipt of goods -cool hands -outdoor air connection -fan Assembly............pages 6-7 -the right location -order of assembly for top connection -ball/plummet stop -connection to existing masonry chimney...
- Page 4 GENERAL Structural support Manufacturor’s assurance A stove with a chimney does not normally require This product has been manufactured in special foundations and can be placed on an accordance with the type approval ordinary floor supported by wooden rafters. If you documentation, of which the instructions for are uncertain, contact a chimney sweep for assembly, use and maintenance form an intrinsic...
- Page 5 The stove is delivered like this Receiving of goods The product may have been damaged in transport, although this may not be apparent from the external packaging. It is important that you inspect the stove carefully and report any damage to the transport company within seven days.you should note visible damage immediately on the delivery note,in connection with receipt of...
- Page 6 ASSEMBLY The right location When you are deciding where the stove is to be placed, it is important to soled a central location in your house in order to ensure even distribution of heat. If you are also planning to install a chimney, it is an ad-vantage if the chimney exit point is as close to the roof ridge as possible, since this entails both aesthetic and cost benefits If there is...
- Page 7 Remove the lid from the back of the stove. Hybrid E in black or gray Connection to an existing masonry FittheRuecollarfromthetoptothebackofthestove. Fit the Rue collar from the top to the back of the stove. chimney The stove is approved for a rear connection to a chimney with a ½...
- Page 8 DATA Design specifications black, gray Color Glass, ceramic withstands 750°C Door 4 or 5 mm steel sheet Grate cast iron Hearth lining vermeculite The hearth is approved for a chimney with a ½ brick connection (350°C), and the stove is designed for a chimney drought of at least 12 pa, as provided by a chimney with a minimum length of 3.5 meters and a cross-section of 150-200 (diam.
- Page 9 How to open the door Output control Open the door by pulling the handle towards you 1 pellet handle 2 handle wood stove, 2 handles open, closed 1.2 handle is pulled out, the oven works on the pellet Ash disposal & grate control The stove has a grate and an ash tray.
-
Page 10: Installation
Compliance Hybrid E complies with the EN13240 and EN14785 European standards and is thereby approved for installation and use in Europe. At the same time, the manufacturing process is subject to external quality control. DoP (Declaration of Performance) can be downloaded at www.sveaflame.se Hybrid E adheres to the following directives: EMC DIRECTIVE 2014 30 EU, LVD DIRECTIVE 2014 35 EU, 2006 42 Machinery Directive. - Page 11 Configuration of the app 1.Connect the stove to power outlet 2.Download the Svea Flame app from either Google Play (Android) or App Store (Apple). 3.Follow the instructions in the app's guide or from our 4 HEAT instruction manual 4.The serial number for operation (8 digits) and password for the app (6 digits) can be found on the label inside the bottom front door.
- Page 12 Chimney The diameter of the flue must be at least 150 mm,, and we recommend a minimum flue height of 3,5 m, measured from the stove flue-connection point. Follow the chimney supplier’s assembly instructions carefully. If you intend to fit your stove to an existing masonry chimney, it should first be inspected by a chimney sweep to check that it is in good order.
- Page 13 The key factors for satisfactory operation of your new stove are proper installation and compliance with the user instructions. If you use the stove in the right manner, it will last for many years. The best heating results are achieved if you use split birch logs (or most other types of deciduous wood), since they burn more steadily than coniferous logs.
- Page 14 Lighting the fire with pellets You can only use Ø6 mm pellets with a maximum length of 40 mm –type EN plus quality A1. We recommend that you use pellets of a good quality –and preferably bright pellets instead of dark pellets.
- Page 16 Electrical connection Hybrid E comes with approx. 1.5 meter of cord with an Euro plug,that should be connected to a 230V / 50Hz outlet. The cord must be positioned so it is not in contact with hot surfaces or pointed objects. Consumption of electrical power Power consumption during operation is: Pel.
-
Page 17: Important Note
IMPORTANT NOTE: INITIAL LOADING AND FIRST IGNITION OF PELLET STOVE During initial start of pellet stove it is very important to be aware of the fact that Spiral feeder (transporter of pellet from storage too burning pot ), is empty. If you want to speed up the transport of pellets further, please check the table below. -
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE The stove requires a simple yet constant cleaning to guarantee top efficiency and proper functioning. Constant maintenance by a qualified technician is recommended (but not necessary) . The stove should be cleaned before the cold season because it can sometimes get clogged during the summer (by nests for example) preventing exhaust fumes to flow regularly. - Page 19 Engine and fan position The drawing below shows the position of the motor and the fan. Pos 1 ... Engine 1 is used to transport pellets from the warehouse to the motor 2 Pos 2 ... Engine 2 is used to transport pellets to the fireplace Pos 3 ...
