Atlas ASP-MG24 Brochure & Specs

ASP-MG24 / ASP-MG24TDB
•
•
•
•
•
•
•
•
ASP-MG24
•
•
•
•
•
•
•
•
•
•
ASP-MG24
equalizers. This model features 4 built-in digital noise generators and two analog inputs specifically suited for paging
input sources. These inputs can be configured for mic or line level.
The
loudspeaker processing for the most popular Atlas Sound loudspeaker systems.
The
to independent white / pink noise generators with adjustable ramp-up time to allow gradual acclimation to masking
levels. Two additional inputs are available for mic or line sources to allow paging and/or music sources to be blended
with the masking sources to any of the 4 outputs. This 6 x 4 mix matrix provides the following configuration options
for sound masking systems:
1. 1, 2, 3, or 4 Channel Masking
2. Dual Two Channel Masking
3. Single Channel Paging
4. Dual Channel Paging (From Single Page Input Source)
5. 1, 2, 3, or 4 Channel Mixed Paging & Masking
6. Dual Channel Mixed Paging & Masking
Dedicated
with dynamic control is available for each of the two mic/line inputs. Any mix of all 6 inputs may be easily matrixed to
the 4 output DSP blocks for additional parametric equalization, delay, and limiting (if required).
Factoring in all features, a very complex 4-zone sound masking system can be easily configured with 2 external music
or page sources.
For loudspeaker control functionality, the
range. Other configurations include full range plus sub operation with Atlas Sound
Series
delay, and dynamic control.
Computer interface is simplified by USB or RS-232 connection (no awkward USB to Serial adaptors required!).
External UL / ULC Listed international voltage power supply is included.
ASP-MG24TDB
ASP-MT24TDB
all 4 masking inputs for holiday and weekend scheduling. This powerful scheduling tool insures maximum speech
privacy in facilities that may be more or less densely occupied during various times of the day or days of the week.
Ethernet control functionality is also incorporated into this model to provide control of multiple units (up to 32) via a
standard network switch and also allows remote access and monitoring via LAN.
74
Sound Masking Generator / Speaker Processor
Four White / Pink Noise Generators & 2 Mic / Line Inputs with 4-Channel DSP Processor
Generator Spectral Purity (±0.1 dB @ 0Hz – 20 kHz)
Precision Pink Noise Filtering (-3 dB per octave low-pass)
Extended "Non-Apparent" Repeat Time of Noise (200 Minutes)
Combined ⁄ -Octave & Parametric Equalization per Channel
1
3
Selectable High & Low Frequency Shelving Filters per Channel
High Pass Filter & Low Pass Filter with Variable Frequency & Slope per Channel
Leveling, Compression, Limiting, & Soft-Gating per Channel for use with Paging Input
Output Delay, with Distance / Delay Calculation, per Channel
Independent Matrixes for Channel-To-Channel Mixing
Variable Noise, Input, and Output Levels with Software Metering
Thirty Non-Volatile Memory Presets Store / Recall Settings
Balanced Inputs & Outputs
Programming Software Included
No Manual controls on Front Panel, to Prevent Tampering
Remote Control via USB, RS-232, Ethernet & Accessory Control Panel
Incorporates AES recommended grounding practices
UL / ULC Listed External Power Supply
represents the latest technology in digital signal processing (DSP) engines for sound masking generator/
ASP-MG24 advances sound masking control to a whole new level while providing the secondary benefit of
ASP-MG24 is a 1 RU, 6 input x 4 output DSP configurable by a very intuitive set-up GUI. Four inputs are tied
⁄ octave filter sets are available for each of the 4 generator outputs, 8 band parametric EQ blocks along
1
3
surface mount speakers, or
incorporates all the features of the standard model with the addition of time / date level control of
Model Computer Processor
Interface
ASP-MG24
USB & RS-232 32-bit
(40-bit extended)
ASP-MG24TDB
USB, RS-232, 32-bit
& Ethernet (40-bit extended)
ASP-MG24 may be configured in 2 input x 4 output mode for stereo full
AH Series stadium horns for complete control of crossover types, equalization,
Dynamic Power Supply
Range
115 dB 115V 20 watts
(unweighted) UL External Power Supply
115 dB 115V 20 watts
(unweighted) UL External Power Supply
ceiling speakers,
FAP Series
Dimensions
Height: 1 RU (1.75" 44 mm)
Width: 19" (483 mm)
Depth: 8" (203 mm)
Height: 1 RU (1.75" 44 mm)
Width: 19" (483 mm)
Depth: 8" (203 mm)
AtlasSound.com AtlasSound.com
SM
