- Page 1 Arrow wM-Bus radio module Code INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE Translation of the original instructions. Before installing and using the device, carefully read this manual and store it together with the product. Code 5000072C - 04/2020 - R1...
-
Page 2: Table Of Contents
Symbols used in this manual Warranty and relative meaning Conditions of sale and warranty The conditions of sale and warranty are avail- able on the website www.maddalena.it. WARNING! Indicates particularly important infor- Warranty limitations mation. Maddalena S.p.A. declines all responsibili-... -
Page 3: General Information
– The device must be used as defined electronic devices. by Maddalena S.p.A., that holds no – This device is not for use by persons responsibility for damage to per- with reduced physical or mental ca-... -
Page 4: Restrictions
1.2 Restrictions 1.3 Device description Arrow is a compact radio module for Maddalena MVM, MVM Plus C and WMAP PROHIBITED Evo cold water meters that allows for re- – Modify and/or attempt to repair the motely measuring, transmitting and read- product. -
Page 5: Usage Limits
Arrow 1.5 Structure 1970008728 Arrow 20000004 Maddalena S.p.A. Via G.B. Maddalena, 2/4 P/N 1.ETRMD.1303 33040 Povoletto (UD), Italy 1 Cover 1 Serial number of the meter 2 Antenna 2 Model... -
Page 6: Technical Specifications
1.7 Technical specifications Features Description Sensor Inductive (two-way) Compatible meters MVM, MVM PlusC, WMAP Evo Sensor resolution Depends on the meter model to which it is connected. Tampering, electronic fraud, backflow, presumed leak, Alarms maximum flow, inverted meter Configuration Via radio using configuration kit Power supply Lithium-ion battery Battery lifespan... -
Page 7: Installation
Installation PROHIBITED Packaging material must be prop- 2.1 Receipt of the product erly disposed of and kept out of children’s reach as it may repre- Arrow modules are supplied in two dif- sent a hazard. Disposal must be ferent formats: performed in line with applicable Single package, already fitted on meter laws. - Page 8 – Attach the Arrow (2) module to the – Lower the module and offset it. adaptor (3). – Attach the adaptor (4) to the relevant housing. – Attach the eyelet (5) to the catch (6) and realign the module.
- Page 9 WMAP Evo WARNING! – If present, remove the protective cover (1) Do not apply pressure to force of the meter and clean the surface near the eyelet in. the pointer. – Fasten the module using the screw (7) and apply the anti-fraud seal (8). –...
- Page 10 – Attach the adaptor (4) to the relevant – Attach the eyelet (5) to the catch (6) and housing. realign the module. WARNING! Do not apply pressure to force the eyelet in. – Lower the module and offset it. – Fasten the module using the screw (7) and apply the anti-fraud seal (8).
-
Page 11: Use
3.2 Activating the radio module The Arrow module is deactivated by The fully operational phase involves remote default, therefore it will not transmit nor meter reading via the radio modules. Each count. radio module transmits the reading with a To activate the module: insert the red acti- settable frequency (default: reading trans- vation key in the appropriate slot and keep mitted every 16 seconds). -
Page 12: Programming On Initial Installation Of The Module
3.3 Programming on initial installation of the module The Arrow module is supplied with a se- ries of set-up data already set to the default values. If necessary, during initial installation, once the module has been activated, the follow- ing values can be modified: –... -
Page 13: Maintenance
Maintenance 4.2 Cleaning No particular cleaning procedures are required. However, the installation area 4.1 Battery should be kept clean and periodic checks The radio module is equipped with a 3.0 V should be performed to ensure the re- lithium manganese battery that is not re- quired environmental conditions are met. - Page 16 Tel. +39 0432 634811 www maddalena it Maddalena S.p.A. reserves the right to change its products at any time and without prior notice, with the aim of improving them and without compromising primary features. All the graphic illustrations and/or photographs appearing in this document can be represented with optional accessories that vary in relation to the country where the device is used.
