USER'S MANUAL
EMMOM
Monta 2019
EMMO
Kamen
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kamen 2020 and is the answer not in the manual?

Questions and answers

Related Manuals for EMMO Kamen 2020

Summary of Contents for EMMO Kamen 2020

  • Page 1 USER’S MANUAL EMMOM Monta 2019 EMMO Kamen...
  • Page 2 © 2020 Emmo Inc. All rights reserved. No texts, details, or illustrations from this manual may be reproduced or distributed, or become the subject of unauthorized use for commercial purposes. Should you discover any errors,...

  • Page 3: Table Of Contents

    MENU About EMMO --------------------------------------------------- Rules and Regulations of Riding an E-Bike --------- Parts Overview ------------------------------------------------ Switches ---------------------------------------------------------- Throttle ----------------------------------------------------------- Lights & Signals ----------------------------------------------- Speedometer --------------------------------------------------- Audio System ------------------------------------------------- Side Kickstand ----------------------------------------------- Rear View Mirrors --------------------------------------------- How to turn on the bike with the key...

  • Page 4: About Emmo

    ABOUT EMMO Established in 2009, Emmo Inc. is a proud Canadian venture that is focused on creating a more sustainable future by providing high quality electric bicycles. We offer a wide variety of e-bikes that are suitable for leading a greener, and more stylish, way of living. Emmo e-bikes are priced competitively with other green solutions.

  • Page 5: Rules And Regulations Of Riding An E-Bike

    RULES and REGULATIONS of riding an e-bike According to Canada’s Motor Vehicle Safety Regulations ( MVSR ). A qualified e-bike (defined as Power Assist Bicycle) must meet the following requirements: • The e-bike must have operable pedals • Upper wattage limit for the motor is 500W. •...

  • Page 6: Parts Overview

    1. PARTS OVERVIEW...
  • Page 7 1. PARTS OVERVIEW...

  • Page 8: Switches

    2. SWITCHES The switch housings on the handlebar hold these switches that control the lights, signals, horn and etc..
  • Page 9 2. SWITCHES...

  • Page 10: Throttle

    3. THROTTLE The throttle controls the speed of the e-bike. As shown below, twist the throttle towards you to operate. With the help of the speed mode switch, you can also change the speed setting. Warning: • DO NOT turn the throttle if you are not ready to ride.

  • Page 11: Lights & Signals

    4. LIGHTS & SIGNALS The headlight assembly has different operation modes - daytime running light, high beam, and low beam to accommodate your needs under different conditions.
  • Page 12 4. LIGHTS & SIGNALS Tail light and brake light play an important role in signaling people behind. With the help of the turn- ing signal lights, it is also easier for other road users to anticipate your intended route. The tail lights become brighter when the brake is applied. Tuning signal light will flash when turned on.

  • Page 13: Speedometer

    5. SPEEDOMETER The speedometer let you know the working status of the bike. It provides information including the current speed, total travel distance, battery strength, and speed mode (3=high speed mode, 2=me- dium speed mode, 1=low speed mode). Speedometer Funtion Explanation...

  • Page 14: Audio System

    6. AUDIO SYSTEM The built-in audio system has two modes - MP3 player and FM radio. Press once to turn on the radio system. The MP3 mode is set by default. You can pair yblue- tooth device with the built-in MP3 player (named Electric bike) and play the music. Press the button again to switch to FM radio mode.

  • Page 15: Side Kickstand

    7. SIDE KICKSTAND A kill switch is integrated into the side kickstand. As a safety feature, when the side stand is kicked down, the motor power will be cut off. • Side Kickstand Kill Switch • Put the bike on the side kickstand •...

  • Page 16: Rear View Mirrors

    8. REAR VIEW MIRRORS Rear view mirrors make it safer for you to check the traffic condition behind you. Please make sure the rear view mirrors are adjusted and secured properly. Check the rear view mirrors and your blind spots before you make a turn or overtake other vehicles. •...
  • Page 17 8. REAR VIEW MIRRORS -Adjustment • Tool needed: a 14mm wrench. • In order to adjust the mirror, the nut that • The nut is covered by the plastic cap. Lift up fixed the mirror should be loosened first. the cap to expose the nut. •...

  • Page 18: How To Turn On The Bike With The Key

    9. HOW TO TURN ON THE BIKE via key ignition With the key, you can turn on/off the bike and lock the steering (refer to Page 20). • The ignition is located in the triple tree plate, centre of the handlebar. •...

  • Page 19: How To Turn On The Bike With The Remote

    9. HOW TO TURN ON THE BIKE via remote Reminder: • If the alarm system is on, please cancel the alarm before you turn on the bike.

  • Page 20: How To Lock The Steering

    10. HOW TO LOCK THE STEERING For the safety of your bike, it is highly recommended to lock the steering when you park your bike in public spaces. • Turn the ignition off. • To lock the steering, turn the handlebar to the left.
  • Page 21 10. HOW TO LOCK THE STEERING • Remove the key when the steering is • The steering cannot be turned when locked. locked.

  • Page 22: How To Turn On/Off The Circuit Breaker

    11. CIRCUIT BREAKER location & instructions Located in the storage compartment under the seat, the circuit breaker is the main switch of the bike. When it is turned off, the battery will be disconnected from the system and you will not able to use the bike, nor will you be able to charge the bike.
  • Page 23 11. CIRCUIT BREAKER location & instructions • The circuit breaker is located on the wall • Under the seat, there is a hook and a of the under-seat compartment (marked seat lock pin, which are both important to in red). secure the seat onto the bike.
  • Page 24 • Pay attention to the location of the seat lock pin under the seat. That is the push- ing point when you lock the seat. Warning: • The wires inserted into circuit breaker could have high voltage output. DO NOT touch any bare wires. If you have any concern, contact your EMMO dealer for assistance.

  • Page 25: How To Charge

    12. HOW TO CHARGE Charge the battery before the battery strength drops down to 20%. Before charging the bike, make sure you are using a compatible charger*. Failure to use a compatible charger will lead to danger. • There are two cables coming out from the charger. One cable goes to the charging port on the bike, and the other goes to the regular 110V wall outlet.
  • Page 26 12. HOW TO CHARGE • The charging port is below the front of the • To charge the bike, open the charging port seat. lid and plug in the charger. • Once fully charged*, unplug the charger • Plug the charger into a regular 110V wall from the wall outlet first and then unplug it outlet.

  • Page 27: How To Ride

    13. HOW TO RIDE THE BIKE • Kick the side kickstand up(refer to page 15). • Sit on the bike. Put on the helmet or any protective equipment required. • With your feet still on the floor, turn the bike on (refer to page 19). •...

  • Page 28: Safety Instructions

    14. SAFETY INSTRUCTIONS To ensure the safety of you and others, • Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are unwell. • Please make sure you are familiar with your local bylaw regarding e-bikes. •...

  • Page 29: Maintenance

    15. MAINTENANCE Regular maintenance is required to keep the bike in its best working conditions. CLEAN Please use clean water and neutral detergent to clean the bike. Use soft cloths or sponges to clean the surfaces. Please do not use metal brushes, sandpaper or any other abrasive material to avoid scratches or physical damage.

  • Page 30: E-Bike Registration Form

    Invoice Number: __________________________ Store Location: _______________________________________________ Customer Name: __________________________ Address: ___________________________________________________ Phone Number: ____________________________ E-mail:______________________________ Survey: How did you find out about Emmo Inc.? (Please select the options that apply) □ Returning Customer □Family/Friend □Passing by Store □Kijiji □TERA □Google □Yelp...

  • Page 31: Appendix 1

    APPENDIX 1 How to Charge a Lithium E-Bike Most of the time, a lithium e-bike share the same look as a regular Gel Lead-Acid one. However, you will notice that the lithium battery is smaller in size and lighter in weight. The lithium charger is also different from ordinary Gel Lead-Acid chargers.
  • Page 32 Particularly, the lithium battery may be removable for the model. The lithium battery is located in the comparment behind the front wheel. Follow the following instructions to get access to the battery pack. • The battery compartment lid is on the •...
  • Page 33 • Disconnect the battery discharging port • Plug the charger directly to the battery and from the bike, and remove the battery start charging. from the bike. Reminder: • After putting the lithium battery back into the bike, remember to connect the dis- charging port with the bike.

  • Page 34: Appendix 2 (Charger Indicators)

    APPENDIX 2 Charger Indicators Usually, there is only one indiactor on Gel Lead-Acid chargers. The indicator has only two colors - Red and Green. Red light means that the charger is charging the bike, while green light can show up when the battery is fully charged or when the charger is not connected to the bike properly.
  • Page 35 72V / 4.5A Lithium Charger Indicators...
