HydroAir MICROLITE 20-1930 Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Available languages

Available languages

Table of Contents

Specifications

Rated voltage:
Rated power:
Current connection:
Installation depth:
Important
The underwaterlight may be used only in connection with a level sensor which ensures that the light
cannot be switched on unless the front of the lamp is under water. The underwater light requires
external potentiel equalization.

Installation

1.
Drill a 36 mm hole in the tub.
2.
Mount the sealing o-ring (14) and add, if necessary, silicone. Pass the body (01) through the
hole from the inside of the tub.
3.
Place the gasket (13) (from backside) around the body (01) and apply a little silicone.
4.
Mount the nut (11) from backside and fasten it tightly on the body (01).
5.
Fix the nut (11) to the body (01) with the pointed screw (12).
6.
Fix the lamp (01) to the tub with the pointed screw (12).
7.
Fasten the P.G. screw (15) to the body (01).
8.
Place the bulb (03) in the ceramic socket (02) and push it into the body (01).
9.
Place the o-ring (04) in front of the bulb (03) and place the frontglass (05) in its proper place.
Hold the frontglass (05) while screwing the escutcheon (07) carefully on to the body (01).
10.
Fix the escutcheon (07) to the lamp (01) with the pointed screw (06).
11.
Connect the cable (16) to the low-voltage side of the safety transformer.
12.
Carry out external potential equalization via the bolt (10) on the nut (11).

Replacement of low-voltage halogen bulb

This may be done only when the tub is empty. Do not touch inside the bulb
1.
Loosen the pointed screw (06) that fixes the escutcheon (07) to the body (01).
2.
Unscrew the escutcheon (07), and remove the front glass (05) and the o-ring (04).
3.
Pull the bulb (03) out of the light body (01), and carefully remove it from the ceramic socket
(02).
4.
Place a new bulb (03) in the ceramic socket (02), and push it back into the body (01).
5.
Place a new o-ring (04) in the recess, position the front glass (05) in the right place, and hold it
in place while fastening the escutcheon (07).
MICROLITE 20-1930
12V
35W
HydroAir transformer, article no. 20-0753, 20-0754 & 20-0755
Maximum 1 m
49-20-1930 – www.balboawatergroup.com – July 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MICROLITE 20-1930 and is the answer not in the manual?

Questions and answers

Related Manuals for HydroAir MICROLITE 20-1930

Summary of Contents for HydroAir MICROLITE 20-1930

  • Page 1 MICROLITE 20-1930 Specifications Rated voltage: Rated power: Current connection: HydroAir transformer, article no. 20-0753, 20-0754 & 20-0755 Installation depth: Maximum 1 m Important The underwaterlight may be used only in connection with a level sensor which ensures that the light cannot be switched on unless the front of the lamp is under water.
  • Page 2 MICROLITE 20-1930 Pieces Description Part number Body 44-1928 Socket 40-1927 Bulb 40-0767A O-ring Ø34 x 4 mm 20-0934 Frontglass Ø39 mm 41-1923 Pointed screw 50-5304 Escutcheon 21-1925-x Tooth washer 50-3502 Washer 50-3516 Bolt 50-0510 44-1922 Pointed screw 50-5516 PE foam gasket 40-1924 O-ring Ø36 x 2.5 mm...
  • Page 3 MICROLITE 20-1930 Spezifikationen Nennspannung: Nennleistung: Stromanschluss: HydroAir Transformer Art. Nr. 20-0753, 20-0754 & 20-0755 Einbautiefe: Max. 1 m Achtung Die Unterwasserlampe ist nur in Verbindung mit einem Wasserstandsfühler, der sicherstellt, dass das Licht nur eingeschaltet wird, wenn die Lampenfront unter Wasser ist, anzuwenden. Ein externer Potentialausgleich ist für die Unterwasserlampe vorgesehen.
  • Page 4 MICROLITE 20-1930 Zahl Bezeichnung Artikel Nr. Lampengehäuse 44-1928 Keramiksockel 40-1927 Birne 40-0767A O-ring Ø34 x 4 mm 20-0934 Abdeckglas Ø39 mm 41-1923 Reistockschraube 50-5304 Abdeckung 21-1925-x Zahnscheibe 50-3502 Unterlegscheibe 50-3516 Maschinenschraube 50-0510 Mutter 44-1922 Reistockschraube 50-5516 PE Dichtung 40-1924 O-ring Ø36 x 2.5 mm...
  • Page 5 Spécifications Tension indiquée sur la plaque: Puissance indiquée sur la plaque: 35W Branchement électrique: Transformateur HydroAir, type 20-0753, 20-0754 & 20-0755 Profondeur d'installation: 1 mètre au maximum Important N'utilisez le projecteur immergé qu'avec une sonde de niveau assurant que le projecteur ne puisse être allumé...
  • Page 6 MICROLITE 20-1930 Nom. Descriptif Article no. Corps de projecteur 44-1928 Douille céramique 40-1927 Ampoule 40-0767A Joint Ø34 x 4 mm 20-0934 Verre de protection Ø39 mm 41-1923 Vis pointeau 50-5304 Cache 21-1925-x Rondelle crantée 50-3502 Rondelle plate 50-3516 Boulon 50-0510...
  • Page 7 Mærkespænding: 12V. Mærkeeffekt: 35W. Strømtilslutning: HydroAir transformer, vare nr. 20-0753, 20-0754 & 20-0755 Indbygningsdybde: Maximum 1 m. Vigtigt Undervandslampen må kun anvendes i forbindelse med niveausensor, der sikrer at lyset ikke kan tændes, med mindre fronten på lampen er under vand. Undervandslampen skal eksternt potentialudlignes.
  • Page 8 MICROLITE 20-1930 Stk. Beskrivelse Varenr. Lampehus 44-1928 Keramikfatning 40-1927 Pære 40-0767A O-ring Ø34 x 4 mm 20-0934 Frontglas Ø39 mm 41-1923 Pinolskrue 50-5304 Afdækning 21-1925-x Tandskive 50-3502 Spændskive 50-3516 Bolt 50-0510 Møtrik 44-1922 Pinolskrue 50-5516 PE pakning 40-1924 O-ring Ø36 x 2.5 mm...
