Hope R4+ Instruction Manual

INSTRUCTION MANUAL
IMPORTANT INFORMATION
We strongly advise you read the following recommendations in order
to prevent injury or damage to the lighting system.
NOTE: The battery is supplied only half charged. Please ensure that you
fully charge the battery before first use (see 'Battery Charging' section).
WARNING
›› This lighting system will withstand harsh wet weather conditions.
However, it is not designed to be submersed in water. If the light is fitted
to a bike, please ensure that the light unit is removed from the bike before
washing - particularly if using a high pressure jet wash.
›› Do not look directly at the beam, permanent eye damage could result.
Consider other people when mounting the light on the head to avoid
dazzling them.
›› Keep this light away from children.
›› This light unit can get hot when in use in maximum power mode.
This is normal and should not be mistaken as a malfunction.
Please use with caution.
›› Unlike unregulated LED lighting systems, this light unit will shut down
suddenly after a period of time in low battery mode without any dimming
of the light. Please bear this in mind when using at night.
›› Only use the battery charger that is supplied with the lighting system.
Use of any other battery charger may result in explosion and serious injury.
›› Do not short-circuit the charging terminals. This can cause the battery
to overheat and could result in fire or explosion.
›› The battery charger is designed for indoor use only and should not come
into contact with water.
›› The battery charger contains dangerous voltages and the cover
should not be removed. Any attempt to open the charger will invalidate
the warranty.
›› This light unit conforms to the requirements of EC directive 2004/108/EC
for electromagnetic compatibility.
DISPOSAL
When the equipment has reached the end of its life please dispose
of the components in accordance with your local waste regulations.
Lamps and batteries should be recycled where possible and not
disposed of with regular waste.
RECHARGEABLE LI-ION LED LIGHTING SYSTEM
HLNR4ST - Standard (1 x 4 cell)
HLNR4EP - Lightweight (1 x 2 cell)
Li-Ion
Light Source: 4 x Cree XM-L2 LEDs
Light Output: 1500 Measured lumens
2000 Generated lumens
Beam: 4 x Spot (+/- 10°)
FWHM: 21°
Mounting: QR bayonet style handlebar mount, helmet mount
or head harness
Battery: Li-Ion ES battery with fuel gauge
2 cell: Nominal capacity 3200mAh
Minimum capacity 3100mAh
4 cell: Nominal capacity 6400mAh
Minimum capacity 6200mAh
Charge Time: 2 cell: 3.5 hours
4 cell: 7.5 hours
Weight: 426g (Lamp unit and 4 cell battery)
Power Levels: 6 (Two sequences of three), including flash
Burn Time: 2 hours 30 minutes - 35:00 hours
WARRANTY
All Hope Technology lighting systems are covered for two years from original
date of purchase against manufacturer defects in material and workmanship.
Proof of purchase is required. Product must be returned to the original retailer
to process any warranty claim. This warranty does not cover any damage
caused through mis-use or failing to comply by the recommendations given
in this manual. This warranty does not affect your statutory rights.
CONTENTS
R2 lamp unit
1:
2: QR bayonet handlebar clamp
3: 31.8 handlebar spacer (Thick)
4: 35.0 handlebar spacer (Thin)
5: Helmet mount
6: QR bayonet mount adapter
7: Extension cable
8: Head harness
9: Battery charger
10: Battery strap
11a: Rechargeable 4 cell ES battery pack
11b: Rechargeable C cell ES battery pack
