Parts supplied:
Important
• Please unwrap the bath and check it carefully to ensure it has not been damaged in handling or transport.
• Please check that all parts have been supplied.
• Assemble bath on a mat to protect against damage to bath surface.
• Please do not remove the old fixture before you unpack and inspect the new unit.
• Store the bath in a safe place until you begin installation to avoid damage.
• Any installation should be carried out by a qualified tradesman with knowledge of statutory plumbing requirements in your area.
1x
• This product requires a two person lift – use proper lifting techniques.
• This installation guide does not include details of waste connection; final decision about installation of waste connection should be taken by a suitably qualified person.
Care and Maintenance
Repairing a scratch: If any scratches occur during installation these can be removed by rubbing with a 800 grit waterproof abrasive paper and water.
4x
For best results limit sanding to the smallest possible area around the scratch.
It may be possible to polish very fine scratches away without using abrasive papers: scrubbing gently with a soft brush or plastic pad
(not metal scouring pad) and a mildly abrasive cream cleaner. Afterwards scrub the whole area with plenty of clean water.
Everyday cleaning
We recommend a non-abrasive bathroom cleaner.
1x
Never use cleaners / bleach products specifically manufactured for WC bowl cleaning as they may damage your bath. In addition to these we strongly
recommend that applying hair colouring is also not used over the bath as it may de-colour the natural stone.
1
Under floor access required for plumbing of bath waste.
Do NOT overtighten the waste as this may cause long term damage to the bath. We recommend to use a torque wrench to tighten the waste by using a
torque force between 25 Nm and 50Nm.
2
to drainage
Waste connection is dependant on the site situation; final
decision about installation of waste connection should be
taken by a suitably qualified person.
1 - 2
Natural Stone Baths
Please place your bath
identification number
here and keep this
paperwork in a safe
place as you will
need this if a problem
occurs with your product.
3
Slot
Overflow
channel
When fitting the waste, ensure the
slotted side faces the overflow channel.
Manufacturers
Identification Number
XXXXXXXXXXX
In the event of after
sales requirements
please quote this
number.
B
Advertisement
Table of Contents
Related Manuals for Arcade ARC21
Summary of Contents for Arcade ARC21
- Page 1 Natural Stone Baths Parts supplied: Please place your bath Important Manufacturers identification number Identification Number • Please unwrap the bath and check it carefully to ensure it has not been damaged in handling or transport. here and keep this XXXXXXXXXXX paperwork in a safe •...
- Page 2 Place the bath on two wooden blocks over the waste connections. Connect the waste. Fill the bath with water Place the wedges in position. The wedges can now be disposed of. 2 - 2...
- Page 3 Natural Stone Authentication Congratulations on choosing a Natural Stone product. Our products contain natural stone being a natural product there may be very slight variations in the finish in certain light conditions. This adds to the uniqueness of our products with each one having its own individual character a welcome rarity these days.
