  6. Instructions for use and maintenance manual

Dynatech SD-BOX Instructions For Use And Maintenance Manual

Unintended car movement control system
Hide thumbs Also See for SD-BOX:
Table of Contents

Advertisement

Quick Links

SISTEMA DE CONTROL DEL MOVIMIENTO
INCONTROLADO DE LA CABINA
UNINTENDED CAR MOVEMENT CONTROL SYSTEM
SYSTÈME DE CONTRÔLE DU MOUVEMENT
INCONTRÔLÉ DE LA CABINE
KONTROLLSYSTEM FÜR UNBEABSICHTIGTE
FAHRKORBBEWEGUNGEN
SD-BOX
INSTRUCCIONES DE USO Y MANUTENCIÓN/
INSTRUCTIONS FOR USE AND MAINTENANCE/
INSTRUCTIONS D'USAGE ET ENTRETIEN/
GEBRAUCHS- UND WARTUNGSANLEITUNG/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD-BOX and is the answer not in the manual?

Questions and answers

Related Manuals for Dynatech SD-BOX

Summary of Contents for Dynatech SD-BOX

  • Page 1 INCONTROLADO DE LA CABINA UNINTENDED CAR MOVEMENT CONTROL SYSTEM SYSTÈME DE CONTRÔLE DU MOUVEMENT INCONTRÔLÉ DE LA CABINE KONTROLLSYSTEM FÜR UNBEABSICHTIGTE FAHRKORBBEWEGUNGEN SD-BOX INSTRUCCIONES DE USO Y MANUTENCIÓN/ INSTRUCTIONS FOR USE AND MAINTENANCE/ INSTRUCTIONS D’USAGE ET ENTRETIEN/ GEBRAUCHS- UND WARTUNGSANLEITUNG/...

  • Page 3: Table Of Contents

    8.1. BATTERIES ....................... - 27 - - 2 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...

  • Page 4: Introduction

    If batteries are used as an auxiliary power supply, an external charger between the batteries and the SD-BOX must not be connected under any circumstances. The SD- BOX is capable of charging the batteries itself. Do not connect a charger between the batteries and SD-BOX, it may Important burn.

  • Page 5: Risks And Safety Warnings

    3.2. EXCLUSION OF LIABILITY DYNATECH DYNAMICS & TECHNOLOGY, SL will not be held responsible for damages caused by not observing any of the points in this document. Strictly prohibited: Intervening on any component within the box.

  • Page 6: Main Features

    Dynatech is not responsible for the use of batteries other than the Ni-Cd type. 1A protection fuse is required If the SD-BOX is placed in locations 2000-4000m above sea level, the maximum voltage at the door input is limited to 160V...

  • Page 7: General Description

    “MANUAL RESCUE/BYPASS” button again or by pressing the “RESET” button. The maximum duration of this mode when the SD-BOX is powered by batteries is 10 minutes, whereupon it automatically returns to a resting state. As many rescues as necessary can be performed by pressing the button again as long as the battery has enough charge.
  • Page 8 FAILURE CONFIG.: Indicates the FAILURE output relay setting: “Off” indicates the SD-BOX will act on the relay if it detects any fault or error, and “on” indicates the SD-BOX will act on the relay according to the coil status. FAILURE output is a non-safety related signal.

  • Page 9: Operation Description

    4.5. DESCRIPTION OF FAULTS Once an error has occurred, the SD-BOX will inform the user through the LEDs and the display showing the status in which the error occurred and will remain in safe mode until it is restarted. A list of possible failures that can occur during the operation of the SD-BOX, with their possible causes and solutions, appear in the following table.
  • Page 10 Check the Check the coil connection on terminals 42-43 by loosening them and checking the continuity of the circuit from the SD-Box to the overspeed governor coil (for Dynatech parking systems, the resistance between terminals must be 42-52 Ω).
  • Page 11 - 10 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 12 Contact Dynatech read/write error OPENS - 11 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 13 COIL DE- ENERGISES - 12 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...

  • Page 14: Assembly

    The various connection terminals operate at different voltages, e.g. some are at 24 V and others at 230 V . If the 230V is connected to a 24V input, the SD-BOX will be destroyed. DC/AC Protect the box and connection terminals from dust and humidity.
  • Page 15 Diagram 1: Main electrical connections - 14 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 16 LEVEL2. Optional installation inputs In addition to the physical MANUAL RESCUE and RESET buttons, the SD-BOX can be used for the optional inputs discussed below for a manual rescue or remote reset from the control panel or another controller.
  • Page 17 The batteries must be connected for proper operation. - 16 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...

  • Page 18: Electrical Diagrams

    49 INPUT. Doors, 0 V - 17 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 19 . If there is voltage, the motor is running. - 18 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 20 Figure 2: Internal relays electrical connection - 19 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...

  • Page 21: Operating Requirements

    SETTING THE COIL DE-ENERGISATION WAIT TIME WITH THE CAR AT LEVEL The SD-BOX coil de-energisation wait time can be modified when the car is at floor level without moving it. The default value is 10 minutes but can be changed in the range from 1 second to 10 minutes.
  • Page 22 LEVEL2 INDUCTOR/μSWITCH COIL STATUS - 21 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 23 - 22 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 24 Check the SD-BOX recovers its normal operating status. The maximum time for the “MANUAL RESCUE/BYPASS” status with battery power is 10 minutes. After this time, the SD-BOX automatically returns to a state of rest. - 23 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer...
  • Page 25 Check the overspeed governor is unlocked before the car moves and the safety gear is disengaged. - 24 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...
  • Page 26 See “4.5 DESCRIPTION OF FAULTS”. - 25 - Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/...

  • Page 27: Maintenance

    7.3. STORAGE CONDITIONS AND USEFUL LIFE The SD-BOX should be stored in a cool, dry place protected from excessive light. It should never be exposed to bad weather conditions. Storage temperature: 5-40ºC Storage humidity: 15-85% The SD-BOX must remain clean to be clearly identified.

  • Page 28: Options

    The LED charge indicator will stay ON when performing a fast charge and will turn OFF when the battery is fully charged. The SD-BOX will perform a periodic test to check the status of the batteries if it detects they are damaged, whereupon the BATTERY FAILURE LED will light up.
