Automatic Installation - Dateq SPL6 Manual

Configuration
20

Automatic installation

Through the automatic installation process the basic sound level settings for
the SPL6 can be made. On starting the installation the different popup
windows will guide the installation.
Make sure popup blockers in your browser are disabled before starting.
The limiter will automatically set all audio values during the installation process. Before starting the
complete audio system must be connected and powered on. It is best to use an audio-source with
less dynamics to perform the installation; this makes it easier for the computer to calculate the
levels. Select the menu-item 'Automatic install'. The software will perform a step-by-step
installation:
Set the output-level to nominal. This means that all the green LEDs on the VU-meter light up,
•
and every now and then some red light will blink,
Set the output level of the amplifiers to the maximum,
•
Enter the maximum dB values,
•
The limiter will adjust the output-volume, until the requested sound level is acquired. In the
•
meantime read the sound level at the level-meter in the room,
After some time the actual audio-level in the room will be asked. This is to compensate the
•
microphone offset value.
The limiter is now calibrated. Check the settings by raising the volume of the mixer till the
'REDUCE' LED on the front panel lights up. The limiter will automatically lower the volume.
All the settings can be changed manually, if necessary.
