- Page 1 TPP-750 User Manual RPS Tankless Pressure Pump™...
- Page 4 With the RPS Tankless Pressure Pump™ system you'll get smooth continuous steady reliable water pressure without the need for AC power or the utility grid. The solar charged battery bank powers a centrifugal booster pump that varies its speed and power based...
-
Page 5: Priming Your Pump
TPP PLUMBING OPTIONS Your Tankless Pressure Pump can You can also draw water up from a plumb directly from your storage tank to pond, shallow well or cistern (up to your main line. It will auto-adjust speed 15ft) but you must maintain prime with to maintain pressure. - Page 6 TPP PUMP DIMENSIONS Inlet 1.25" FNPT Power Range 750 - 1500w Outlet 1" FNPT Suction Up to 4M, 15ft (wetted) Acceptable pH 5 - 8, Water (No Fuel) Max Current 8 Amps Temp. Range 0 - 40°C, 32 - 104°F Box Size 394 x 260 x 330mm Max Liquid Temp 90°C, 194°F Weight 10kg, 22lbs...
-
Page 7: Installation Details
Batteries - Unless you already bought a TPP system that included the appropriate number of RPS 55Ah 12V Deep Cycle GEL batteries, customers will need to supply their own battery bank. RPS recommends 12V AGM / sealed lead acid batteries that are designed for maintenance free operation. - Page 8 WIRING YOUR SOLAR PANELS TP-750- TP-750- TP-750- You will link your solar panels together and connect to the controller by clipping MC4 connectors together. Each MC4 connector is either a male end or female end (see Note: If using your own image).
-
Page 9: Battery Wiring
BATTERY WIRING 24V ONLY RPS recommends AGM / sealed lead acid batteries that are designed for several maintenance free years of operation. They should also be stored in a dry location protected from the elements. To prevent significant voltage drop, the batteries should be located as close to the Controller as possible. -
Page 10: Controller Display
CONTROLLER DISPLAY 220V AC INPUT (Only if Required) Your Controller is designed to take solar power and charge your 24v battery bank. As an optional backup, it is also setup to accept 220V AC to both charge your batteries and run your pump directly if desired. There is a 3 prong outlet and a pigtail in your kit that allows for the wiring of 220v line power connector. -
Page 11: Controller Modes
CONTROLLER MODES MODE to select the working mode: 1. NORMAL (most common) Increases the water pressure or draws water up from below pump and pressurizes. This is the normal booster pump application. 1.0 - 2.0 Low Pressure 2.0 - 3.0 Medium Pressure 3.0 - 4.0 High Pressure Note: Pump shutoff will become unstable if LOCK / UNLOCK Hold + and -... -
Page 12: Controller Troubleshooting
CONTROLLER TROUBLESHOOTING Your Controller is not waterproof and should be located in a dry dust-free location, protected from the sun and the elements and pests such as mice. moths and bugs. Mice love to chew wires and spiders and moths will build nests wherever they can find room. -
Page 13: Pump Troubleshooting
Startup fault Hard Reset, Contact RPS to check for impeller obstructions Motor communication error Check for damage to motor wires, Hard Reset, Contact RPS Not used n/a, Hard Reset Display communication Hard Reset, Contact RPS... - Page 14 WARRANTY: Rural Power Systems Inc extends to the original consumer purchaser a limited warranty against defects in material and workmanship for a period of twelve months from the date of purchase. This warranty covers the pump, controller, and solar panels. Rural Power Systems Inc will repair or replace any defective part or parts of the product free of charge within the first twelve months of purchase.
- Page 15 NOTES: ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________...
- Page 16 RPS Solar Pumps 40250 County Rd 27 Woodland CA 95776 888-637-4493 Call or Text...
