Document—
Power Supply
Replacement—All
Microprocessor
Controlled Machines
®
Except the CBW
PELLERIN MILNOR CORPORATION
POST OFFICE BOX 400, KENNER, LOUISIANA 70063 - 0400, U.S.A.
Advertisement
Related Manuals for Milnor 08PSS3401N
Summary of Contents for Milnor 08PSS3401N
- Page 1 • Access Date: 20020314 • Depth: detail • Applicability: CUU • Language Code: ENG01, Purpose: publication, Format: 1colA Document— Power Supply Replacement—All Microprocessor Controlled Machines ® Except the CBW PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063 - 0400, U.S.A.
- Page 2 The resistor is used only on certain machines. It must be installed across the new power supply's 5 volt DC output conductors, as shown in Figure 2, on any applicable machine. Please verify that all components listed in the kit parts list were supplied. Contact the Milnor Parts Department if any items are missing.
- Page 3 Make certain that a good connection is established between the ground trace on the power supply board and the machine chassis, as shown in Figure 1. If the new power supply is not a direct match for the old, contact the Milnor factory. —Various mounting brackets are supplied with Kit 08PSS3401N (for Older Machines) 1.2.
-
Page 4: Electrical Connections
Notice 3 : The wire carrying -12VDC from the power supply is not used on washer-extractors with the Milnor System 7 control, or those with model numbers ending in C4A or M4A. • When this wire is not used, terminate it with a wire nut to prevent shorting. - Page 5 , or E-P Plus washer-extractor, install the regulating resistor, as shown in Figure 2. Again, splice the leads of the resistor as close as possible to the connector on the power supply side. The resistor is not polarity- sensitive. PELLERIN MILNOR CORPORATION...
