Summary of Contents for Astone RUMBA 2000
- Page 2 IMPORTANT SAFEGUARDS · Keep the product and all its parts and accessories out of the reach of small children. · Make sure not to let water into the product. · Do not leave the unit exposed to direct sunlight for long periods. ·...
-
Page 3: Table Of Contents
Table of contents MAIN FEATURES ... 4 PRODUCT SPECIFICATIONS ... 4 ACCESSORIES ... 4 1) PLAYER OVERVIEW ... 5 2) THE LCD DISPLAY ... 5 3) DISPLAY & BASIC OPERATION ... 6 Button Function Define Turning the Player On 4) MAIN MENU ... 6 Playing Music (Support MP3/WMA files) Lyrics Synchronization Playing Music... -
Page 4: Main Features
Main Features • Plays audio files in MP3, WMA, ADPCM WAV formats. • Support four operating modes : Music, Record, Voice, FM (optional). • Portable USB Flash disk function. • Support memory size 64/128/256/512MB. • Seven color backlight: Cyan, Green, Purple, Red, Blue, White, Yellow. •... -
Page 5: Player Overview
1) PLAYER OVERVIEW Neck strap hole Earphone jack Volume up ( + ) Volume down ( - ) Hold switch Power ON / OFF / Play / Stop / Pause Button LCD display Microphone (build in the player) Next track / Fast forward button Menu button 11. -
Page 6: Pause
3) DISPLAY & BASIC OPERATION Button Function Define “ ” : Power on / play / pause / stop / : power on, power off, play, pause, stop. “ MENU” : Switch menu mode “ ” : Next track/Fast forward button “... -
Page 7: Playing Music (Support Mp3/Wma Files)
Playing Music (Support MP3/WMA files) Include play, pause, stop, lyric display, volume adjust, delete file, rewind, previous, A-B repeat / playback, repeat mode etc. Lyrics Synchronization The Player is capable of showing lyric on the display simultaneously while playing a song. The Player support LRC V2.0 format, if there is a lyric file in the same directory and the lyric file name is the same as audio file name, lyrics will be displayed. -
Page 8: Stop
Stop When an audio file is being played, press “ Adjusting Volume Press “ + ”or “ - ” to adjust volume. Press “ - ” to decrease and “ + ” to increase volume. Hold By locking the buttons you may avoid pressing any button on the player by accident. In any status of power on, slide “... -
Page 9: Playing Music
Using the Record Function When an audio file is being paused or is stopped, short press “ MENU ” to enter main menu. Press “ ”or “ ” to select “ Record ”, press “ MENU ” to start record, press “ pause record, and press “... -
Page 10: Display The Player Information
You will be asked if you are sure to delete it. Press the “ MENU ” or “ ” to NO or YES. Press “ + ” or “ - ” to return to the “ Delete Music ” or “ Delete Voice ” submenu and press “ ”... -
Page 11: Fm Tuner Mode
3). Tuning preset radio station If you want to preset one radio station, press“ MENU ” to select “Store”, press “ Store 98.4 M P 10 4). Record radio When listening to FM radio, press “ MENU ” to select “REC”, press “ Press “... -
Page 12: System Setup
5) SYSTEM SETUP Setting up Equalizer Mode When an audio file is being paused or is stopped, short press “ MENU ” to enter “ MENU ” -> “ Settings ” -> “ EQ Set ”, the menu items as shown in the lower figure. 1). -
Page 13: A) Source
Setting up Backlight Time When an audio file is being paused or is stopped, short press “MENU” to enter “MENU” -> “Settings” -> “Backlight”, press “ 0-60 seconds. Press “MENU” to confirm and press “ If no other keys are pressed within the select time the background light will automatically go off. Setting up Display Backlight When an audio file is being paused or is stopped, short press “... -
Page 14: Selecting Display Language
” to select menu items, press “ MENU ” to select submenu. 3). GBK 7). English&EUR ” to select one language, and press “ MENU ” to confirm. 4). BIG5 8). Exit ” for 5 seconds, the message ‘ ASTONE’... -
Page 15: Pc Driver And Utility Installation (For Windows98/Se Only)
If connect the player to PC before setting up the device driver will invoke ‘Add New Hardware Wizard’ of Windows 98/98SE. The player driver and utility may not fully setup using the ‘Add New Hardware Wizard’! A) Download the utility from www.astone.com.au. B) Click [Setup] to install the driver / utility. -
Page 16: Usb Connection
F) After completing the installation, please click check box [Yes, I want to restart my computer now] and click [Finish] to restart your computer. (Windows98) Note: There is no driver required for Windows2000/XP (Plug and Play). 8) USB Connection You could transmit files through USB port of your PC. A) Make sure your PC support USB devices and you have installed the driver (Windows98/98SE). -
Page 17: Update The Firmware
G) A removable disk icon copy and delete files on the player by Drag and Drop in the removable disk. When the transfer is finished, following the below pictures to stop this USB Mass Storage Device using the Safe Removal icon, then you can take out the player safely. Note: StepG is no exists in Windows98/98SE, you can take out the player directly. -
Page 18: About The Format Data Area Option
Selected: Update the firmware and format the storage. When finish, please format the Removable disk with format tool of Windows.This selection is suggested. Note: You can download the new version firmware from www.astone.com.au, then copy it to the setup directory “C:\Program Files\SignaTel\MSCN” before update firmware. -
Page 19: Fqa And Troubleshooting Tips
FQA and Troubleshooting Tips Why am I unable to install the installation software to my operating system? • Please note that Windows95 is unable to support USB interface properly. Please upgrade your system to Windows98 (Version 2.0,4.10.2222 A), 2000, ME, or XP. •... - Page 20 91-8DA4-02...
