Astone ALLURE 2 Manual

Ase 2 series digital audio player

Advertisement

Quick Links

Contents
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
ALLURE Series ASE 2
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
2
2
2
4
5
7
8
8
9
9
9
10
12
14
16
16
16
17
17
18
18
20
21
21
23
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALLURE 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Astone ALLURE 2

  • Page 1: Table Of Contents

    Contents Legal Disclaimer • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Important notices •...
  • Page 2: Legal Disclaimer

    2. Astone will not be held liable for any loss, accident or miss use caused by incorrectly following these instructions. At the same time Astone will not be held responsible for damages caused by misinterpretation.
  • Page 3 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4: Warning

    4. Warning Electrical equipment may be hazardous if misused. Operation of this product, or similar products, must always be supervised by an adult. Do not allow children access to the interior of any electrical product and do not permit them to handle any cables. Permanent hearing loss may occur if earphones are used at high volume.
  • Page 5: Product Information

    5. Product information Thank you for purchasing this Astone digital audio player which has built in MP3/WMA digital music player, FM tuner, line-in/mic recording and recording FM features, equipped with OLED display, A-B repeat, 9 types of EQ too. The following items are included:...
  • Page 6 Unique features: Multi-codec Player: Support MP3, WMA, DRM9 and WAV format etc. Display: OLED graphic display FM tuner: 87.5MHz-108MHz, 14 channels auto preset and frequency memory setting. Headphones/earphones cord antenna. 9 EQ (Equalizing patterns): Normal, Rock, JAZZ, Classic, POP, D- Bass, Jive, Vocal, Dance Multi-playing mode: Repeat, Repeat all, Shuffle, Shuffle repeat and intro Supported operation systems: No driver is required for Window 2000 or later version, Mac OS 10X...
  • Page 7: Location Of Controls

    6. Location of controls: Mini USB jack Hold Earphone/Line in jack Earphone/FM jack OLED display Play/Stop Vol. up Vol. down Menu Page 7 ALLURE Series ASE 2...
  • Page 8: Display Configuration

    7. Display configuration OLED Window Playback mode Playing info Artist / song title Volume 8. Charging the Battery This MP3 player is equipped with a rechargeable Ni-MH battery. 1. Place the player on a flat surface. 2. Take out the USB charging cable and connect it to the mini USB jack of the player.
  • Page 9: Basic Operation

    9. Basic Operation Listening to Music 1. Connect the earphones to the earphone/line in jack. 2. Slide the HOLD switch to “OFF” left. 3. Turn the player on by pressing and hold the Play/Stop button. 4. Press the Menu key and select “Music” menu. 5.
  • Page 10: Music Menu

    12. Music menu Music menu is playing back songs from the player. Playback mode Playing info Artist / song title / information Volume ALLURE Series ASE 2 The order of song / total songs Play time File format Equalizer Battery indicator Visualization of audio signal Page 10...
  • Page 11 Control of buttons Button Play/Stop Button Menu Vol + key Vol - Key Hold A-B repeating To repeat a section of a song, press the “Menu” key while playing “A” will appear in the display. Press the “Menu” key again to set point “B”. The specific section you selected will be repeated continuously.
  • Page 12: Voice Menu

    13. Voice menu Voice menu is playing back voice message /FM radio recordings/ Line in recordings from the player. Switch the Menu key ►► forward or ◄◄ backward to select voice message /FM radio recordings/ Line in recordings. Press “Play/Stop” button to play and stop by pressing the button again. The recorded file will be saved as a WAV file, if no file, it will show “No Files”...
  • Page 13 Control of buttons Button Play/Stop Button Menu Vol + key Vol - Key Hold A-B repeating To repeat a section of a voice message /FM radio recordings/ Line in recordings, press the “Menu” key while playing “A” will appear in the display. Press the “Menu” key again to set point “B”. The specific section you selected will be repeated continuously.
  • Page 14: Fm Tuning Menu

    14. FM Tuning Menu Radio menu is for a function to listen the FM radio. Push the Menu key for different modes: Radio, Scan, Store, Record, Exit. Radio mode Listen to the radio station, use Menu key ►► forward or ◄◄ backward for searching station. Scan mode Auto scan and memory the strongest stations up to 27 stations can be memorized.
  • Page 15 Control of buttons Button Play/Stop Button Menu Vol + key Vol - Key ALLURE Series ASE 2 Action Scan mode: Auto scan for Store mode: memory Press Record mode: recording FM radio, press again for pause Exit mode: return to playback Long Press Enter mode: Radio, Scan, Press Store, Record, Exit...
  • Page 16: Record Menu

    15. Record Menu Record menu is for the function of message recording. Control of buttons Button Play/Stop Button Menu 16. Setting Menu Setting menu is a function of EQ, Play mode, Screen saver, Power set, Record set, Languages setup. EQ mode: Press Menu key to enter, switch ◄◄ backward or ►► forward to select the EQ: Normal, Rock, Jazz, Classic, POP, D-Base, Jive, Vocal or Dance.
  • Page 17: Play Mode

    Play mode: Press Menu key to enter, switch backward ◄◄ or ►► forward to Play mode, press Menu key again to enter Play mode, switch ◄◄ backward or ►► forward for selecting Normal, Repeat One or Repeat All. Exit the setting press the Play/Stop button. Screen Saver mode: Press Menu key to enter, switch ◄◄...
  • Page 18: Power Set Mode

    Power set mode: Press Menu key to enter, switch ◄◄ backward or ►► forward to Power set mode. Auto-off the player disable or in 2 minutes, 5 minutes or 10 minutes when player not in operation. Exit the setting press the Play/Stop button.
  • Page 19 Source Encode Channel Device Sample Bit Rate Mode Source Encode Channel Device Sample Bit Rate Mode ALLURE Series ASE 2 IMAD MSAD Mono Mono 8 KHz 8 KHz Song/ Song/ Album Album LINE IN IMAD MSAD Mono/ Mono/ Stereo Stereo 8/ 11/ 16/ 8/ 11/ 16/ 22/ 32 22/ 32...
  • Page 20: Languages Set Mode

    Languages mode Press Menu key to enter, switch ◄◄ backward or ►► forward to Languages mode Setup the system and display languages between: Delete mode: Press Menu key to enter, switch ◄◄ backward or ►► forward to delete mode Deleting file from Music or Voice folders, switch Menu key ►► forward or ◄◄...
  • Page 21: Info Mode

    Info mode: Press Menu key to enter, switch ◄◄ backward or ►► forward to Info mode. It shows the firmware version (VER); built in memory (INT) and showing available memory for storage (FREE). Exit It will exit setting and back to play back music. 17. Connecting to computer Connect the player to PC using the USB cable to download/upload files to/from PC.
  • Page 22 A “Removable Disk” window will automatically pop up on your PC. To add more files and songs to your player simply drag and drop MP3, WMA, WAV or data files anywhere on your computer into the “Removable Disk” window. During files transferring, “Reading” message appears and it will disappear after data transfer or stop.
  • Page 23: Trouble Shooting

    18. Trouble Shooting Guide Symptom Player will not turn on No buttons work Turn off few second after switching On No sound Cannot playback MP3 songs Characters in display are corrupted No play time display The computer is not recognizing the player ALLURE Series ASE 2 Solution Battery is weak or not installed properly, recharge the battery and...
  • Page 24 Uploading or downloading not stable Player in malfunction Power FM reception The memory show at Info mode is less than listed ALLURE Series ASE 2 Please check the compatibility of the PC or try with another PC. Switch off to reset the player or reset the unit by press the both Vol + and Vol –...
