- Page 1 32 TFT LCD TV INSTRUCTION MANUAL MODEL: LTV-3201...
-
Page 2: Table Of Contents
Please read all the safety and operating instructions carefully before you begin. This is an IEC safety class I product and must be grounded for safety. IMPORTANT SAFETY INSTRUCTION... PREFACE... WARNING AND CAUTIONS... SPECIFICATIONS... INSTALLATION TV ASSEMBLY DRAWINGS... FRONT..BACK... -
Page 3: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION 1.Read these instructions. 2.Keep these instructions. 3.Heed all warnings. 4.Follow all instructions. 5.Do not use this apparatus near water. 6.Clean only with dry cloth. 7.Do not block any ventilation openings. Install in accordance with the manufacturers instructions. 8.Do not install near any heat sources such as radiators, heat registers,stoves, or other apparatus (including Amplifiers) that produce heat. -
Page 4: Important Safety Instruction
CAUTION TO REDUCE THE RISK OF ELECT RIC SHOCK,DO NOT REMOVE COVER (OR BACK).NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. T h e s y m b o l i n d i c a t e s t h a t d a n g e r o u s v o l t a g e c o n s t i t u t i n g a r i s k o f e l e c t r i c s h o c k i s p r e s e n t w i t h i n t h i s u n i t . -
Page 5: Preface
PREFACE Thank you very much for purchasing this TV. To enjoy your set to the full from the very beginning, read this manual carefully and keep it handy for ready reference. INSTALLATION Locate the TV in the room where light does not strike the screen Total darkness or a reflection on the picture screen can cause eyestrain. -
Page 6: Warning And Cautions
WARNINGS AND CAUTIONS Caution Carry the set requires two or more people. Caution Do not drop or push objects into the television cabinet slots or openings. Never spill any kind of liquid on the television receiver. Caution Do not insert anything in the ventilation holes. If metal or something flammable enters, it may result in fire or electric shock. - Page 7 WARNINGS AND CAUTIONS Caution Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall. Caution Do not place your television on an unstable cart , stand , shelf or table.
-
Page 8: Warning And Cautions
Take care not to connect many appliances to the same mains socket as this could result in fire or elecric shock. Do not place objects on this unit. it may damage the screen surface. High voltages are used in the operation of this television receiver. -
Page 9: Specifications
SPECIFICATONS Model LTV-3201 LCD panel 32 INCHES TFT LCD Television system NTSCM PAL-4.43MHz-50Hz AV system SECAM-4.29MHz-50Hz NTSC-4.43MHz-60Hz PAL-3.58MHz-60Hz Channel coverage VHF-L: 46.25~163.25MHz VHF-H: 158.25~466.25MHz UHF: 461.25~865.25MHz Analog RGB mode 640X480/ 60Hz, 800X600/ 60Hz, 1024X768/ 60Hz,1280X768/60Hz Y Pb/Cb Pr/Cr mode 480P,576P,720P,1080i... -
Page 10: Tv Assembly Drawings
Hang the TV on the wall Step1: Disassemble the pedestal. Step2: Install part A on the wall. Step3: Hang the TV on the wall. Note: 1.Installation of the display unit on the wall should be carried out by qualified servicemen. Improper installation may render the unit unsafe in the event of an earthquake.etc. -
Page 11: Installation
INSTALLATION FRONT KEYS: 1.CH+: channel up select, it is equivalent 2.CH-: channel down select, it is equivalent 3.VOL+: volume up adjust, it is equivalent 4.VOL-: volume down adjust, it is equivalent 5.MENU: to enter into menu operation. 6.AUTO/EXIT: automatically adjust picture/exit OSD. 7.POWER/ SIGNAL SELECT: press the key at least 5 seconds to turn off the set (standby). -
Page 12: Back
INSTALLATION BACK Power Input Software upgrade SCALE 1.000 Stop output after standby for 3 minutes Power switch VIDEO output is fixed TV signal AUDIO output is fixed MONO signal VIDEO output and Audio output VIDEO input and Audio input YC Input HDTV Audio Input DVI Input Analog RGB Input... - Page 13 INSTALLATION STEPS: 1. Connect Video Cable a. Make sure both the TV and computer are powered-OFF. b. Connect the video cable to the computer. 2. Connect the Audio cable. 3. Connect power cord 4. Power-ON Computer Power-ON the TV first, then Power-ON the computer. This sequence is very important.
-
Page 14: Antenna
INSTALLATION ANTENNA -12-... -
Page 15: Av Equipment Assessories
INSTRUCTION AV EQUIPMENT This TV provides 2 group of AV input terminal including one S-Video and one group of YCbCr terminal for connection to VCR,DVD or other video equipment. To enjoy the high quality picture. Please refer to the owner s manual of the equipment to be connected as well. You can use the AV input terminals on TV set rear as follows. -
Page 16: Battery Installation (Remote Control Unit)
Insert Batteries Into the Remote Control 1. Remove the battery cover. 2. Insert the 2 AAA 1.5V batteries,ensurecorrect polarity (+ or -) 3. Replace the battery cover. Replace with new batteries when the TV set begins to show the following symptoms: Operation is unsteady, erratic or when TV set shows no response to the remote control. -
Page 17: Remote Control Description
REMOTE CONTROL DESCRIPTION 1.POWER (STAND BY) BUTTON ( Press this button to turn on or turn off (Standby mode).Press Power Button, picture and sound will appear on within a few seconds. 2.PROGRAM SELECTION BUTTON (0-9 BUTTONS) Push the number for your desired program and the program indicator will be displayed on the screen. 1.To input a one-digit number(0-9):press 2.To input a two-digit number(10-99):press channel number.For example, you need channel 25, please input... - Page 18 4.CH+/- BUTTON (TV top control key) 1.Press the CH+/- button to select the program forwards. 2.Press the CH+/- button to select the program backwards. (Use these two buttons for Page Up/Down to increase/decrease page number in TELETEXT mode,option) 5.MENU BUTTON (TV top control key) Use "MENU"...
-
Page 19: Remote Control Description
REMOTE CONTROL DESCRIPTION 18.V-Chip BUTTON Press this button to setup V-Chip. 19.FREEZE BUTTON Press this button to hold the current video picture, Press the button twice to cancel. 13:15 CH 9 I 20.SYSTEM BUTTON Press this button to select TV/IRC/HRC/STD format at NTSC TV signal. Signal Current time TV channel and soundformat... -
Page 20: Operation Instructions
TURN ON/OFF 1. Insert the AC plug into a conveniently located AC outlet (100-240VAC,50/60Hz). 2. Turn on the on/off switch 3. Press the to select the signals *Remark: If no input signal, then a blue background appears. 4. Press menu and the menu will display, continue press select the language menu, press Note: The item of selected is highlight when press <Left>... -
Page 21: Picture Setting Sound
OPERATION INSTRUCTIONS PICTURE SETTING The PICTURE SETTING menu allows you to alter the picture adjustments. Press the item you want to alter.Press Film Mode---If the signal source is film mode, please select ON, the menu will be best displayed.If the signal source is not film mode, please select OFF. -
Page 22: Closed Caption
CLOSED CAPTION Closed caption is an information service transmitted by most TV stations. Press you want to alter. The CC Mode contain CC1/CC2/Text1/ Text2/XDS/CC3/CC4/ Text3/ Text4 ,press or to select the item you wish to watch. A.Some TV programs may not be broadcast with closed caption signals, and therefore , the TV will not be able to display captions. -
Page 23: Operaton Instructions
OPERATON INSTRUCTIONS CAUTION MESSAGES: TV RATING AND MOVIE RATING TV RATING Rating Allow TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA 1.Press to select the item you want to alter,then press 2.if you want alter the TV V-Chip Set up... password, press or to select the bit of password, press press to select Ok or Cancel,press menu confirm your input. -
Page 24: Setup
Canadia English Lanugage Ratings: E:Exempt. C:Children. C8+:Children 8 years and older. G:General programming,suitable for all audiences. PG:Perenal guidance. 18+:Adult programming. Canadian French Lanuage Ratings: E:Exempt G:Children 8ans+: Children 8 years and older 13ans+:Children 13 years and older 16ans+:Viewers 16 years and older 18ans+:Adult programming CANADIAN ENGLIAH RATING Rating... -
Page 25: Setup
OPERATION INSTRUCTIONS Smart Cinema 14:9 Sleep Setting --- press to enter the menu ,it is equivalent to the Sleep button. Current Clock --- press or to select the item you want to alter, press Turn Off Time --- press or to select the turn off time Turn On Channel --- press or to select the channel of the set auto turn on . -
Page 26: Channel Setting
CHANNEL SETTING 1. Press menu to select the follow menu. Press or Color System TV/CATV Current Program Add/Erase Auto Search Fine Tune <Left> or <Right> key to change 2.TV/CATV--- press or to select the format(AIR,STD.IRC.HRC) of NTSC signal.STD/IRC/HRC is identified automatically at CATV. 3.Current program---press 4.Add/Erase --- press or to select add or erase the current channel. -
Page 27: Analog Rgb And Dvi Picture Setting Picture Position
OPERATION INSTRUCTIONS ANALOG RGB AND DVI Following modes are strongly suggested for set up mode. RESOLUTION 640x480 800x600 1024x768 1280x768 PICTURE SETTING Press to select the item you want to alter, then press PICTURE SETTING Brightness Contrast Phase Frequency 1312 USER_R USER_G USER_B... -
Page 28: Troubleshooting Guide
TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSE The AC power cord is not connected No power The switch is switch off TV station experiencing problems Picture setting is not adjusted Possible local interference Double images or ghosting Poor/no Only snow and noise appears on the picture Screen No color on color programme... -
Page 29: Personal Computer
TROUBLESHOOTING GUIDE PERSONAL COMPUTER The NO INPUT SIGNAL message appears on the screen No picture If the OUT OF SCANRANGE message appears on the screen Pictureis fuzzy If the set don’t turn on when you turn o n AC Power, please turn off AC power an d wait a moment, then turn on AC power.
